Lenovo ideapad
120S
Hardware
Maintenance
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDEAPAD 120S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lenovo IDEAPAD 120S

Summary of Contents for Lenovo IDEAPAD 120S

  • Page 1 Lenovo ideapad 120S Hardware Maintenance Manual...
  • Page 2 “Notices” on page 81. • This manual applies to the following models: Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP. The illustrations used in this manual are for Lenovo ideapad 120S-14IAP unless otherwise stated. First Edition (June. 2017) © Copyright Lenovo 2017. All rights reserved.

  • Page 3: Table Of Contents

    Power-on password ..........24 Hard-disk password ..........24 Administrator password ........24 Power management ........25 Putting the computer to sleep or shutting it down ..........25 Putting your computer to sleep ......25 Shutting down the computer ......25 Lenovo ideapad 120S-11IAP/ Lenovo ideapad 120S-14IAP ...... 26 Specifications ..........26 Status indicators ........... 28 Fn key combinations/Hotkeys....... 29 FRU replacement notices ......30 Screw notices ..........30 Removing and replacing an FRU ....31 1010 Base cover ..........32 1020 Hard disk drive...

  • Page 4: About This Manual

    • The product-specific section includes service, reference, and product-specific parts information. Important: This manual is intended only for trained servicers who are familiar with Lenovo products. Use this manual to troubleshoot problems effectively. Before servicing a Lenovo product, make sure to read all the information under “Safety information” on page 1 and “Important service information” on page 16.

  • Page 5: Safety Information

    Safety information Safety information This chapter presents the following safety information that you need to get familiar with before you service a Lenovo ideapad 120S-11IAP/ Lenovo ideapad 120S-14IAP computer: • “General safety” on page 2 • “Electrical safety” on page 3 • “Safety inspection guide” on page 5 • “Handling devices that are sensitive to electrostatic discharge” on page 6 • “Grounding requirements” on page 6 • “Safety notices: multilingual translations” on page 7 • “Laser compliance statement” on page 14...

  • Page 6: General Safety

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual General safety Follow these rules below to ensure general safety: • Observe a good housekeeping in the area where the machines are put during and after the maintenance. • When lifting any heavy object: 1. Make sure that you can stand safely without slipping. 2. Distribute the weight of the object equally between your feet. 3. Use a slow lifting force. Never move suddenly or twist when you attempt to lift it. 4. Lift it by standing or pushing up with your leg muscles; this action could avoid the strain from the muscles in your back. Do not attempt to lift any object that weighs more than 16 kg (35 lb) or that you think is too heavy for you. • Do not perform any action that causes hazards to the customer, or that makes the machine unsafe.

  • Page 7: Electrical Safety

    Safety information Electrical safety Observe the following rules when working on electrical equipments. Important: Use only approved tools and test equipments. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents. Many customers have rubber floor mats near their machines that contain small conductive fibers to decrease electrostatic discharges.
  • Page 8 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual • Always look carefully for possible hazards in your work area. Examples of these hazards are moist floors, nongrounded power extension cables, power surges, and missing safety grounds. • Do not touch live electrical circuits with the reflective surface of a plastic dental mirror. The surface is conductive; such touching can cause personal injury and machine damage. • Do not service the following parts with the power on when they are removed from their normal operating places in a machine: – Power supply units – Pumps – Blowers and fans – Motor generators and similar units. (This practice ensures correct grounding of the units.) • If an electrical accident occurs:...

  • Page 9: Safety Inspection Guide

    The power cord should be the type specified in the parts list. c. Insulation must not be frayed or worn. 4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage. 8. Check for worn, frayed, or pinched cables.

  • Page 10: Handling Devices That Are Sensitive To Electrostatic Discharge

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Handling devices that are sensitive to electrostatic discharge Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between objects. Protect against ESD damage by equalizing the charge so that the machine, the part, the work mat, and the person handling the part are all at the same charge. Notes: 1. Use product-specific ESD procedures when they exceed the requirements noted here.

  • Page 11: Safety Notices: Multilingual Translations

    Safety information Safety notices: multilingual translations The safety notices in this section are provided in English, French, German, Hebrew, Italian, Japanese, and Spanish. Safety notice 1 Before the computer is powered on after FRU replacement, make sure all screws, springs, and other small parts are in place and are not left loose inside the computer.
  • Page 12 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Safety notice 2 DANGER Some standby batteries contain a small amount of nickel and cadmium. Do not disassemble a standby battery, recharge it, throw it into fire or water, or short- circuit it. Dispose of the battery as required by local ordinances or regulations.
  • Page 13 Safety information Safety notice 3 DANGER The battery pack contains small amounts of nickel. Do not disassemble it, throw it into fire or water, or short-circuit it. Dispose of the battery pack as required by local ordinances or regulations. Use only the battery in the appropriate parts listing when replacing the battery pack.
  • Page 14 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Safety notice 4 DANGER The lithium battery can cause a fire, an explosion, or a severe burn. Do not recharge it, remove its polarized connector, disassemble it, heat it above 100°C (212°F), incinerate it, or expose its cell contents to water. Dispose of the battery as required by local ordinances or regulations.
  • Page 15 Safety information Safety notice 5 If the LCD breaks and the fluid from inside the LCD gets into your eyes or on your hands, immediately wash the affected areas with water at least for 15 minutes. Seek medical care if any symptoms caused by the fluid are present after washing. Si le panneau d’affichage à...
  • Page 16 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Safety notice 6 DANGER To avoid shock, do not remove the plastic cover that protects the lower part of the inverter card. Afin d’éviter tout risque de choc électrique, ne retirez pas le cache en plastique protégeant la partie inférieure de la carte d’alimentation.
  • Page 17 Safety information Safety notice 8 DANGER Before removing any FRU, turn off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Avant de retirer une unité remplaçable en clientèle, mettez le système hors tension, débranchez tous les cordons d’alimentation des socles de prise de courant, retirez la batterie et déconnectez tous les cordons d’interface.

  • Page 18: Laser Compliance Statement

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Laser compliance statement Some models of Lenovo computer are equipped from the factory with an optical storage device such as a CD-ROM drive or a DVD-ROM drive. Such devices are also sold separately as options. If one of these drives is installed, it is certified in the U.S. to conform to the requirements of the Department of Health and Human Services 21 Code of Federal Regulations (DHHS 21 CFR) Subchapter J for Class 1 laser products. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 and CENELEC EN 60 825 for Class 1 laser products.
  • Page 19 Safety information A CD-ROM drive, a DVD-ROM drive, or any other storage device installed may contain an embedded Class 3A or Class 3B laser diode. Note the following: DANGER Emits visible and invisible laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam. Radiação por raio laser ao abrir. Não olhe fixo no feixe de luz, não olhe diretamente por meio de instrumentos óticos e evite exposição direta com o feixe de luz.

  • Page 20: Important Service Information

    Strategy for replacing FRUs Before replacing parts: Make sure that all software fixes, drivers, and BIOS downloads are installed before replacing any FRUs listed in this manual. After a system board is replaced, ensure that the latest BIOS is loaded to the system board before completing the service action. To download software fixes, drivers, and BIOS, follow the steps below: 1. Go to http://support.lenovo.com. 2. Enter the serial number or select a product or use Lenovo smart downloading. 3. Select the BIOS/Driver/Applications and download. 4. Follow the directions on the screen and install the necessary software.

  • Page 21: Strategy For Replacing A Hard Disk Drive

    Important service information Use the following strategy to prevent unnecessary expense for replacing and servicing FRUs: • If you are instructed to replace an FRU, but the replacement does not solve the problem, reinstall the original FRU before you continue. • Some computers have both a processor board and a system board. If you are instructed to replace either of them, and replacing one of them does not solve the problem, reinstall that board, and then replace the other one. • If an adapter or a device consists of more than one FRU, any of the FRUs may be the cause of the error. Before replacing the adapter or device, remove the FRUs one by one to see if the symptoms change. Replace only the FRU that changed the symptoms. Attention: The setup configuration on the computer you are servicing may have been customized. Running Automatic Configuration may alter the settings. Note the current configuration settings (using the View Configuration option); then, when service has been completed, verify that those settings remain in effect.

  • Page 22: Important Information About Replacing Rohs Compliant Frus

    Note: RoHS and non-RoHS FRU part numbers with the same fit and function are identified with unique FRU part numbers. Lenovo plans to transit to RoHS compliance well before the implementation date and expects its suppliers to be ready to support Lenovo’s requirements and schedule in the EU. Products sold in 2005 and 2006 will contain some RoHS compliant FRUs. The following statement pertains to these products and any product Lenovo produces containing RoHS compliant FRUs.

  • Page 23: General Checkout

    General checkout General checkout This chapter presents the following information: • “What to do first” on page 20 • “Power system checkout” on page 21 Before you go to the checkout, make sure to read the following important notes: Important notes: • Only certified trained personnel can service the computer. • Before replacing any FRU, read the entire page on removing and replacing FRUs. • Carefully remove screws for reuse when replacing FRUs. • Be extremely careful during such write operations as copying, saving, or formatting. Drives in the computer that you are servicing sequence might have been altered.

  • Page 24: What To Do First

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual What to do first When you do return an FRU, you must include the following information in the parts exchange form or parts return form that you attach to it: 1. Name and phone number of servicer 2. Date of service 3. Date on which the machine failed 4. Date of purchase 5. Procedure index and page number in which the failing FRU was detected 6. Failing FRU name and part number 7. Machine type, model number, and serial number 8. Customer’s name and address Note for warranty: During the warranty period, the customer may be...

  • Page 25: Power System Checkout

    • If the computer does not charge during operation, go to “Checking operational charging”. To check the AC adapter, follow the steps below: 1. Unplug the AC adapter cable from the computer. 2. Measure the output voltage at the plug of the AC adapter cable. See the following figure: Voltage (V DC) Note: Output voltage for the AC adapter pin No. 2 may differ from the one you are servicing. 3. If the voltage is not correct, replace the AC adapter. 4. If the voltage is acceptable, do the following: • Replace the system board. • If the problem persists, go to “Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP” on page 26. Note: Noise from the AC adapter does not always indicate a defect.

  • Page 26: Checking Operational Charging

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Checking operational charging To check whether the battery charges properly during operation, use a discharged battery pack or a battery pack that has less than 50% of the total power remaining when installed in the computer. Perform operational charging. If the battery status indicator or icon does not light on, remove the battery pack and let it return to room temperature. Reinstall the battery pack. If the charge indicator or icon is still off, replace the battery pack. If the charge indicator still does not light on, replace the system board. Then reinstall the battery pack. If it is still not charged, go to the next section. Checking the battery pack Battery charging does not start until the Power Meter shows that less than 95% of the total power remains; under this condition the battery pack can charge to...

  • Page 27: Related Service Information

    This chapter presents the following information: • “Restoring the factory contents by using recovery system” on page 23 • “Passwords” on page 24 • “Power management” on page 25 Restoring the factory contents by using recovery system Restore of factory default The Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP computers come with pre-installed recovery system. In order to save application files and the initial backed up files of the system, the hard disk in a Lenovo computer includes a hidden partition when it is shipped. If you need to restore the system to the point of your first boot up, just enter the recovery system. For details of the Recovery system, see the User Guide for Recovery system . Note: This will delete all the new data on the system partition (C drive), which is not recoverable.

  • Page 28: Passwords

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Passwords As many as three passwords may be needed for any Lenovo computer: the power-on password (POP), the hard disk password (HDP), and the administrator password. If any of these passwords has been set, a prompt for it appears on the screen whenever the computer is turned on. The computer does not start until the password is entered.

  • Page 29: Power Management

    Related service information Power management Note: Power management modes are not supported for APM operating system. Putting the computer to sleep or shutting it down When you have finished working with your computer, you can put it to sleep or shut it down. Putting your computer to sleep If you will be away from your computer for only a short time, put the computer to sleep. When the computer is in sleep mode, you can quickly wake it to resume use, bypassing the startup process. To put the computer to sleep, do one of the following: • Close the display lid. • Press the Power button. → Sleep. • Open the start menu, and then select Power Attention: Wait until the power indicator light starts blinking (indicating that the computer is in sleep mode) before you move your computer. Moving your computer while the hard disk is spinning can damage the hard disk, causing loss of data.

  • Page 30: Lenovo Ideapad 120S-11Iap/Lenovo Ideapad 120S-14Iap

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP This chapter presents the following product-specific service references and product-specific parts information: • “Specifications” on page 26 • “Status indicators” on page 28 • “Fn key combinations/Hotkeys” on page 29 • “FRU replacement notices” on page 30 • “Removing and replacing an FRU” on page 31 • “Locations” on page 62 • “Parts list” on page 65 Specifications The following table lists the specifications of the Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP: Table 1.
  • Page 31 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Table 1. Specifications (continued) Feature Description Audio • 1 W speaker × 2 • Microphone x 2, Combined with camera Bluetooth • Combined with wifi card wireless Keyboard • 6 rows Lenovo Keyboard Integrated • 0.3 M camera Battery • Li-ion battery pack, 2 cells, 28 Wh / 32 Wh AC adapter • 20 V DC 45 W Pre-installed operating • Windows 10 system...

  • Page 32: Status Indicators

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Status indicators The system status indicators below show the computer status: Table 2. Status indicators AC power Indicator Symbol Meaning adapter status status The computer is in sleep mode or turned off; the battery has more than 20% charge. Disconnected The battery has between 5% and 20% Solid amber charge. Fast blinking The battery has between 1% and 5% amber charge. The battery is being charged. When Slow blinking battery charge reaches 20%, the amber blinking color changes to white. The battery has between 20% and Slow blinking 80% charge and is still charging. When...

  • Page 33: Fn Key Combinations/Hotkeys

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Fn key combinations/Hotkeys The following table shows the function of each combination of Fn with a function key. Table 3. Fn key combinations Fn + PrtSc: Activates the insert function. Fn + B: Activates the break function. Fn + P: Activates the pause function. Fn + C: Enables/disables the scroll lock.

  • Page 34: Fru Replacement Notices

    Hardware Maintenance Manual FRU replacement notices This section presents notices related to removing and replacing parts. Read this section carefully before replacing any FRU. Screw notices Loose screws can cause a reliability problem. In the Lenovo computer, this problem is addressed with special nylon-coated screws that have the following characteristics: • They maintain tight connections. • They do not easily come loose, even with shock or vibration. • They are harder to tighten.

  • Page 35: Removing And Replacing An Fru

    Before touching it, establish personal grounding by touching a ground point with one hand or using an electrostatic discharge (ESD) strap (P/N 6405959) to remove potential shock reasons. Notes: • This manual applies to the following models: Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP. • The illustrations used in this manual are for Lenovo ideapad 120S-14IAP unless otherwise stated.

  • Page 36: 1010 Base Cover

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual 1010 Base cover Figure 1. Removal steps of base cover Remove the screws 1 from the bottom. Step Screw (quantity) Color Torque M2.0 × 5.0 mm, Torx-head, nylok-coated (10) Silver Lenovo ideapad 120S-14IAP: D cover + C cover 2.0±0.5 kgf*cm Lenovo ideapad 120S-11IAP: 2.0±0.2 kgf*cm Use a plastic prying tool to aid in separation shown by arrows 2 and 3. Remove the base cover 4.
  • Page 37 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Note: Applying labels to the base cover If you see the following labels on base cover, it needs to be peeled off from the old base cover, and put on the new base cover. Rating label Rating label Windows label Office label US/CA/TW/ISRAEL BT WL label Malaysia label TW vision warning label Kenya label KCC label Indonesia SDPPI label Indonesia label Argentina WL label Argentina Adapter label SouthAfrica WL label For some models, you also need to apply one or two FCC labels. Check the old base cover; if it has one or two FCC labels, find duplicates of them in the label kit and apply them to the new base cover. For the location of each label, refer to the following figures: for PRC for WW...

  • Page 38: 1020 Hard Disk Drive (Lenovo Ideapad 120S-11Iap (With Hdd))

    • Before removing the drive, suggest the customer to backup all the information on it if possible. • Never remove the drive while the system is operating or is in suspend mode. Figure 2. Removal steps of hard disk drive (Lenovo ideapad 120S-11IAP (with HDD)) Unplug the battery connector in the direction shown by arrow 1. Remove the screws 2, then remove the hard disk drive in the direction shown by arrow 3.

  • Page 39: 1030 Battery Pack

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP 1030 Battery pack For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 DANGER Only use the battery specified in the parts list for your computer. Any other battery could ignite or explode. Figure 3. Removal steps of battery pack...
  • Page 40 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Figure 3. Removal steps of battery pack (continued) Detach the battery pack connector in the direction shown by arrow 4, then remove the screws 5. Remove the battery pack in the direction shown by arrow 6.
  • Page 41 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 3. Removal steps of battery pack (continued) Unplug the battery connector in the direction shown by arrow 2, then remove the screws 3. Remove the battery pack in the direction shown by arrow 4. Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (5) Silver 2.0±0.2 kgf*cm Battery + C cover When installing: Make sure that the battery connector is attached firmly. Lenovo ideapad 120S-11IAP (with HDD) Remove the screws 1, then remove the battery pack in the direction shown by arrow 2. Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (3) Silver 2.0±0.2 kgf*cm...

  • Page 42: 1040 Solid State Disk (Lenovo Ideapad 120S-14Iap/ Lenovo Ideapad 120S-11Iap (Without Hdd))

    Hardware Maintenance Manual 1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD)) For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1030 Battery pack” on page 35 Figure 4. Removal steps of solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD)) Remove the screw 1. Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (1)

  • Page 43: 1050 Pci Express Mini Card For Wireless Lan

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP 1050 PCI Express Mini Card for wireless LAN For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 Important: The preinstalled WLAN module may only be replaced with a Lenovo approved module in order to comply with FCC and IC regulations. Refer to “Table 5. Parts list—Overall” on page 69 for Lenovo part numbers for the approved modules. Figure 5. Removal steps of PCI Express Mini Card for wireless LAN Disconnect the two wireless LAN cables (black, grey) 1, and then remove the screw 2. In step 1, unplug the jacks by using the removal tool antenna RF connector (P/N: 08K7159), or pick up the connectors with your fingers and gently unplug them in the direction shown by the arrows.
  • Page 44 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Figure 5. Removal steps of PCI Express Mini Card for wireless LAN (continued) Remove the card in the direction shown by arrow 3. When installing: • In models with a wireless LAN card that has two antenna connectors, plug the black cable (1st) (MAIN) into the jack labeled MAIN, and the white cable (2nd) (AUX) into the jack labeled AUX on the card. • In models with a wireless LAN card that has three antenna connectors, plug the black cable (1st) (MAIN) into the jack labeled 1, the grey cable (3rd) into the jack labeled 3, and the white cable (2nd) (AUX) into the jack labeled 2 on the card.

  • Page 45: 1060 Usb Board

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP 1060 USB board For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 Figure 6. Removal steps of USB board Lenovo ideapad 120S-14IAP Unplug the speakers connector in the direction shown by arrow 1. Remove the screws 2. Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (3) Silver 1.8±0.5 kgf*cm USB board + C cover Remove the USB board 3.
  • Page 46 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Figure 6. Removal steps of IO board (continued) Lenovo ideapad 120S-11IAP Disconnect the speakers and USB board connects in the direction shown by arrows 1, 2 and 3. Remove the screws 4. Step Screw (quantity) Color Torque Silver M2.0 × 2.5 mm, Phillips head, nylok-coated (3) 2.0±0.2 kgf*cm USB board + C cover Remove the USB board 5. When installing: Make sure that the connectors are attached firmly.

  • Page 47: 1070 Speaker

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP 1070 Speaker For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 Figure 7. Removal step of speaker Unplug the speaker connectors in the direction shown by arrows 1. Release the speakers cable from the cable guides. Remove the screws 2. Remove the two speakers 3. Step Screw (quantity) Color Torque M2.0 × 2.0 mm, Phillips head, nylok-coated (4) Black Lenovo ideapad 120S-14IAP: Speakers + C cover 1.8±0.5 kgf*cm Lenovo ideapad 120S-11IAP: 2.0±0.2 kgf*cm When installing: Make sure that the connectors are attached firmly and route the cable along the cable guides.

  • Page 48: 1080 Touchpad Module

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual 1080 Touchpad module For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD))” on page 38 Figure 8. Removal steps of touchpad module Lenovo ideapad 120S-14IAP Disconnect the connector in the directions shown by arrows 1 and 2. Peel off the adhesive tape 3 first, and then 4.
  • Page 49 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 8. Removal steps of touchpad module (continued) Remove the screws 5. Step Screw (quantity) Color Torque M2.0 × 2.0 mm, Phillips head, nylok-coated (3) Black 1.8±0.5 kgf*cm TP bracter + C cover Remove the touchpad module 6. When installing: Make sure that the connector is attached firmly.
  • Page 50 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Figure 8. Removal steps of touchpad module (continued) Lenovo ideapad 120S-11IAP Disconnect the connector in the directions shown by arrows 1 and 2. Open the adhesive tape 3. Remove the screws 4. Step Screw (quantity) Color Torque M1.6 × 1.8 mm, Phillips head, nylok-coated (3) Silver 1.0±0.2 kgf*cm TP bracter + C cover...
  • Page 51 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 8. Removal steps of touchpad module (continued) Remove the touchpad module 5. When installing: Make sure that the connector is attached firmly.

  • Page 52: 1090 Battery Bracket (Lenovo Ideapad 120S-14Iap)

    1090 Battery bracket (Lenovo ideapad 120S-14IAP) For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1050 PCI Express Mini Card for wireless LAN” on page 39 Figure 9. Removal steps of battery bracket (Lenovo ideapad 120S-14IAP) Disconnect the connectors in the directions shown by arrows 1, 2 and 3. Release the cable from the cable guides. Remove the screws 4. Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (6)

  • Page 53: 1100 System Board

    • If you put a system board down, make sure to put it only on a padded surface such as an ESD mat or conductive corrugated material. For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD))” on page 38 • “1050 PCI Express Mini Card for wireless LAN” on page 39 • “1060 USB board” on page 41 Figure 10. Removal steps of system board Detach the connectors (touchpad connector, KB backlight connector, Speakers connector, USB board connector and EDP cable connector) in the directions shown by arrows 1, 2, 3 and 4. Remove the screws 5.
  • Page 54 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Figure 10. Removal steps of system board (continued) Lenovo ideapad 120S-11IAP (without HDD) Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (8) Black 2.0±0.2 kgf*cm MB + C cover Lenovo ideapad 120S-11IAP (with HDD) Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (7)
  • Page 55 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 10. Removal steps of system board (continued) Remove the system board in the direction shown by arrow 6. Unplug the RTC battery connector in the direction shown by arrow 7. Disconnect the system board connect in the directions shown by arrows 8 and 9.

  • Page 56: 1110 Upper Case

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual 1110 Upper case For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD))” on page 38 • “1050 PCI Express Mini Card for wireless LAN” on page 39 • “1060 USB board” on page 41 • “1070 Speaker” on page 43 • “1080 Touchpad module” on page 44 • “1090 Battery bracket (Lenovo ideapad 120S-14IAP)” on page 48 • “1100 System board” on page 49 Figure 11.
  • Page 57 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 11. Removal steps of upper case (continued) Open the hinge in the direction shown by arrows 2. Rotate the upper case in the direction shown by arrow 3. Then remove the upper case from LCD unit.

  • Page 58: 1120 Lcd Unit

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual 1120 LCD unit For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD))” on page 38 • “1050 PCI Express Mini Card for wireless LAN” on page 39 • “1060 USB board” on page 41 • “1070 Speaker” on page 43 • “1080 Touchpad module” on page 44 • “1090 Battery bracket (Lenovo ideapad 120S-14IAP)” on page 48 • “1100 System board” on page 49 • “1110 Upper case” on page 52...
  • Page 59 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 12. Removal steps of LCD unit (continued) Remove the screws 6. Step Screw (quantity) Color Torque M2.0 × 2.5 mm, Phillips head, nylok-coated (4) Silver 1.8±0.5 kgf*cm LCD + A cover (Lenovo ideapad 120S-14IAP) M2.0 × 2.0 mm, Phillips head, nylok-coated (4) Silver 2.0±0.2 kgf*cm LCD + A cover (Lenovo ideapad 120S-11IAP) Lift the LCD panel slightly 7. Lift the EDP cable latch in the direction shown by arrow 8. Unplug the LVDS cable in the direction shown by arrow 9. Then remove the LCD panel. When installing: Make sure that the metal connector is attached firmly.

  • Page 60: 1130 Lcd Hinges

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual 1130 LCD hinges For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD))” on page 38 • “1050 PCI Express Mini Card for wireless LAN” on page 39 • “1060 USB board” on page 41 • “1070 Speaker” on page 43 • “1080 Touchpad module” on page 44 • “1090 Battery bracket (Lenovo ideapad 120S-14IAP)” on page 48 • “1100 System board” on page 49 • “1110 Upper case” on page 52...
  • Page 61 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 13. Removal steps of LCD hinges (continued) Release the two hinges in the direction shown by arrows 3. Lenovo ideapad 120S-11IAP Remove the screws 1. Step Screw (quantity) Color Torque M2.0 × 2.0 mm, Phillips head, nylok-coated (8) Black 2.0±0.2 kgf*cm Hinge + A cover...
  • Page 62 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Figure 13. Removal steps of LCD hinges (continued) Release the two hinges in the direction shown by arrows 2.

  • Page 63: 1140 Integrated Camera

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP 1140 Integrated camera For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD))” on page 38 • “1050 PCI Express Mini Card for wireless LAN” on page 39 • “1060 USB board” on page 41 • “1070 Speaker” on page 43 • “1080 Touchpad module” on page 44 • “1090 Battery bracket (Lenovo ideapad 120S-14IAP)” on page 48 • “1100 System board” on page 49 • “1110 Upper case” on page 52 • “1120 LCD unit” on page 54...

  • Page 64: 1150 Antenna Assembly And Lvds Caple

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual 1150 Antenna assembly and LVDS caple For access, remove these FRUs in order: • “1010 Base cover” on page 32 • “1020 Hard disk drive (Lenovo ideapad 120S-11IAP (with HDD))” on page 34 • “1030 Battery pack” on page 35 • “1040 Solid state disk (Lenovo ideapad 120S-14IAP/ Lenovo ideapad 120S-11IAP (without HDD))” on page 38 • “1050 PCI Express Mini Card for wireless LAN” on page 39 • “1060 USB board” on page 41 • “1070 Speaker” on page 43 • “1080 Touchpad module” on page 44 • “1090 Battery bracket (Lenovo ideapad 120S-14IAP)” on page 48 • “1100 System board” on page 49...
  • Page 65 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Figure 15. Removal steps of antenna assembly and LVDS caple (continued) Remove the LVDS cable 4.

  • Page 66: Locations

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Locations Front and right-side view 1 Integrated camera 2 Built-in microphone 3 Computer display 4 Wireless LAN antennas 5 Power button 6 Touchpad 7 Novo button 8 Micro SD card slot 9 Combo audio jack j USB 3.0 port Lenovo ideapad 120S-14IAP...
  • Page 67 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Lenovo ideapad 120S-11IAP...

  • Page 68: Bottom And Left-Side View

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Bottom and left-side view 1 Speakers 2 Power status indicator Note: For the description of each indicator, see “Status indicators” on page 28. 3 Type-C port 4 HDMI port 5 USB 3.0 port 6 Battery status indicator Note: For the description of each indicator, see “Status indicators” on page 28. 7 AC power adapter jack Lenovo ideapad 120S-14IAP Lenovo ideapad 120S-11IAP...

  • Page 69: Parts List

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Parts list This section presents the following service parts: • “Overall” on page 66 • “LCD FRUs” on page 76 • “Miscellaneous parts” on page 80 • “AC adapters” on page 80 • “Screws” on page 80 Note: Each FRU is available for all types or models, unless specific types or models are specified. Attention: Do not attempt to replace an FRU on your own. If an FRU is damaged, contact a Lenovo authorized servicer or a marketing representative for replacement or repair. Only qualified technicians can inspect or repair this product.

  • Page 70: Overall

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Overall Lenovo ideapad 120S-14IAP...
  • Page 71 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Lenovo ideapad 120S-11IAP (without HDD)
  • Page 72 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Lenovo ideapad 120S-11IAP (with HDD)
  • Page 73 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Table 5. Parts list—Overall ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP a-b See “Miscellaneous parts” on page 80. LCD unit (see “LCD FRUs” on page 76.) Up Case ASM 3N 81A5 W/KB US Grey 5CB0P23700 ● Up Case ASM 3N 81A5 W/KB UK Grey 5CB0P23760 ● Up Case ASM 3N 81A5 W/KB ITA Grey 5CB0P23780 ● Up Case ASM 3N 81A5 W/KB SPA Grey 5CB0P23864 ● Up Case ASM 3N 81A5 W/KB TUR Grey 5CB0P23873 ● Up Case ASM 3N 81A5 W/KB THA Grey 5CB0P23688 ● Up Case ASM 3N 81A5 W/KB POR Grey 5CB0P23867 ●...
  • Page 74 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Table 5. Parts list—Overall (continued) ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP Up Case ASM 3N 81A5 W/KB ARA Blue 5CB0P23712 ● Up Case ASM 3N 81A5 W/KB BRA Blue 5CB0P23893 ● Up Case ASM 3N 81A5 W/KB JAP Blue 5CB0P23805 ● Up Case ASM 3N 81A5 W/KB DUT Blue 5CB0P23887 ● Up Case ASM 3N 81A5 W/KB GRE Blue 5CB0P23828 ● Up Case ASM 3N 81A5 W/KB HEB Blue 5CB0P23737 ● Up Case ASM 3N 81A5 W/KB HUN Blue 5CB0P23699 ●...
  • Page 75 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Table 5. Parts list—Overall (continued) ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP Up Case ASM 3N 81A4 W/KB FRAR Grey 5CB0P23872 ● Up Case ASM 3N 81A4 W/KB UKR Grey 5CB0P23846 ● Up Case ASM 3N 81A4 W/KB US Blue 5CB0P23733 ● Up Case ASM 3N 81A4 W/KB UK Blue 5CB0P23920 ● Up Case ASM 3N 81A4 W/KB ITA Blue 5CB0P23858 ● Up Case ASM 3N 81A4 W/KB SPA Blue 5CB0P23765 ● Up Case ASM 3N 81A4 W/KB TUR Blue 5CB0P23643 ● Up Case ASM 3N 81A4 W/KB THA Blue 5CB0P23715 ●...
  • Page 76 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Table 5. Parts list—Overall (continued) ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP Up Case ASM 3N 81A4 W/KB ARA White 5CB0P23743 ● Up Case ASM 3N 81A4 W/KB BRA White 5CB0P23874 ● Up Case ASM 3N 81A4 W/KB JAP White 5CB0P23802 ● Up Case ASM 3N 81A4 W/KB DUT White 5CB0P23852 ● Up Case ASM 3N 81A4 W/KB GRE White 5CB0P23811 ● Up Case ASM 3N 81A4 W/KB HEB White 5CB0P23797 ● Up Case ASM 3N 81A4 W/KB HUN White 5CB0P23644 ●...
  • Page 77 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Table 5. Parts list—Overall (continued) ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP Up Case ASM 3N 81A4 W/KB FRAR Pink 5CB0P23714 ● Up Case ASM 3N 81A4 W/KB UKR Pink 5CB0P23869 ● T/P 3N 81A5 W/mylar/cable Grey 5T60P23686 ● T/P 3N 81A5 W/mylar/cable Blue 5T60P23742 ● T/P 3N 81A4 W/mylar/cable Grey 5T60P23860 ● T/P 3N 81A4 W/mylar/cable Blue 5T60P23647 ● T/P 3N 81A4 W/mylar/cable White 5T60P23861 ● T/P 3N 81A4 W/mylar/cable Pink 5T60P23669 ●...
  • Page 78 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Table 5. Parts list—Overall (continued) ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP MB 3N 81A4 N3450WIN UMA R2G64G 5B20P23713 ● MB 3N 81A4 N3450WIN UMA R2G 5B20P23729 ● MB 3N 81A4 N3450WIN UMA R2G HDD 5B20P23857 ● MB 3N 81A4 N3450WIN UMA R4G32G 5B20P23825 ● MB 3N 81A4 N3450WIN UMA R4G64G 5B20P23662 ● MB 3N 81A4 N3450WIN UMA R4G 5B20P23754 ● MB 3N 81A4 N3450WIN UMA R4G HDD 5B20P23812 ●...
  • Page 79 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Table 5. Parts list—Overall (continued) ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP Lower Case 3N 81A5 Blue 5CB0P20673 ● Lower Case 3N 81A4 Grey 5CB0P20678 ● Lower Case 3N 81A4 HDD Grey 5CB0P23722 ● Lower Case 3N 81A4 Pink 5CB0P20697 ● Lower Case 3N 81A4 HDD Pink 5CB0P23683 ● Lower Case 3N 81A4 Blue 5CB0P20688 ● Lower Case 3N 81A4 HDD Blue 5CB0P23746 ● Lower Case 3N 81A4 White 5CB0P20666 ●...

  • Page 80: Lcd Frus

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual LCD FRUs In Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP, there are following types of LCDs. • “14.0-in. HD LED” Lenovo ideapad 120S-14IAP...
  • Page 81 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP • “11.6-in. HD LED” Lenovo ideapad 120S-11IAP (without HDD)
  • Page 82 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Lenovo ideapad 120S-11IAP (with HDD)
  • Page 83 Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Table 6. Parts list—LCD FRUs ideapad ideapad No. FRU FRU no. 120S-11IAP 120S-14IAP Hinge Cover 3N 81A5 Grey 5CB0P20696 ● Hinge Cover 3N 81A5 Blue 5CB0P20680 ● Hinge Cover3N 81A4 Grey 5CB0P20665 ● Hinge Cover3N 81A4 Pink 5CB0P20681 ● Hinge Cover3N 81A4 Blue 5CB0P20679 ● Hinge Cover3N 81A4 White 5CB0P20691 ● LCD Bezel 3N 81A5 Black 5B30P20667 ● LCD Bezel 3N 81A4 Black 5B30P20664 ●...

  • Page 84: Miscellaneous Parts

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Miscellaneous parts Table 7. Parts list—Miscellaneous parts ideapad ideapad 120S-11IAP 120S-14IAP System miscellaneous parts: • (a) HDD Bracket 3N 81A4 L+R 5B40P23863 ● Cable miscellaneous parts: • (b) USB BD cable 3N 81A5 5C10P23879 ● • (b) USB BD cable 3N 81A4 5C10P23720 ● Note: Italicized letters in parentheses are references to the exploded view in “Overall” on page 66. AC adapters Table 8. Parts list—AC adapters...

  • Page 85: Notices

    Notices Notices Lenovo may not offer the products, services, or features discussed in this document in all countries. Consult your local Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. However, it is the...

  • Page 86: Trademarks

    Lenovo ideapad 120S-11IAP/Lenovo ideapad 120S-14IAP Hardware Maintenance Manual Trademarks The following terms are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. Lenovo ideapad Microsoft and Windows are trademarks of Microsoft Corporation in the United States, other countries, or both. Other company, products, or service names may be trademarks or service marks of others.

This manual is also suitable for:

Ideapad 120s-11iapIdeapad 120s-14iap
