Panasonic NN-SD277SR Operating Instructions Manual
Over the range microwave oven
Hide thumbs
Also See for NN-SD277SR:
- Operating instructions manual (64 pages) ,
- Service manual (40 pages)
Table of Contents
Advertisement
Safety Information
Precautions ................................................Inside cover
Important Safety Instructions .................................1-2
Installation and Grounding Instructions ...............3-4
Safety Precautions......................................................5
Operation
Control Panel ................................................................8
Function Features .........................................................9
Child Safety Lock ..........................................................9
Setting the Clock.........................................................10
Selecting Light On/Night/Off........................................10
Selecting Turntable On/Off..........................................10
Selecting Fan High/Low/Off ........................................10
Selecting Super/Turbo/Off...........................................10
Selecting Auto Off 1/3/5/10 .........................................10
Selecting Power & Cook Time.....................................11
Quick Min Feature .......................................................11
Keep Warm Feature ....................................................11
Popcorn Feature .........................................................12
More/Less Feature ......................................................12
Inverter Turbo Defrost Feature....................................13
Defrosting Tips & Techniques ................................13-14
Sensor Reheat Feature...............................................15
Sensor Cook Feature ..................................................15
Sensor Cook Chart .....................................................16
Microwave Recipes .....................................................17
For assistance, please call:
contact us via the web at:
http://www.panasonic.com/contactinfo
For microwave oven safety reference, please visit FDA's webpage at:
www.fda.gov/cdrh/consumer/microwave.html
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
1-800-211-PANA(7262)
Operating Instructions
Over The Range Microwave Oven
Models: NN-SD277SR/SD277BR/SD277WR
Operation
....................................................................................18
How to Use Shelf ........................................................19
Microwave Shortcuts..............................................20-21
Food Characteristics ...................................................22
Cooking Techniques...............................................22-23
Quick Guide to Operation ...........................................29
Maintenance
Care and Cleaning of Your Microwave Oven ........24-26
Accessory Purchases..................................................24
Cleaning Vent Grille (Oven Air Vent)...........................25
Installing Vent Grille ....................................................25
Charcoal Filter Attachment/Replacement ...................25
Cleaning Grease Filters ..............................................26
Installing Grease Filters ..............................................26
Cooktop/Night Light Replacement ..............................26
Oven Light Replacement ............................................26
Before Requesting Service .........................................27
Cookware Guide ...........................................................6
Oven Components Diagram .........................................7
Specifications ..............................................................30
User's Record .............................................................30
