Important Precautions
This unit has been engineered and manufactured to ensure your personal
safety, however improper use may result in potential e shock or fire hazards.
In order to allow the proper operation of all safeguards incorporated in this
display, observe the following basic rules for its installation, use, and
servicing.
On Safety
Use only the power cord supplied with the unit. In case you use another power
cord, make sure that it is certified by the applicable national standards if not being
provided by the supplier. If the power cable is faulty in any way, please contact the
manufacturer or the nearest authorized repair service provider for a replacement.
The power supply cord is used as the main disconnection device. Ensure that the
socket-outlet is easily accessible after installation.
Operate the display only from a power source indicated in the specifications of
this manual or listed on the display. If you are not sure what type of power supply
you have in your home, consult with your dealer.
Overloaded AC outlets and extension cords are dangerous. So are frayed power
cords and broken plugs. They may result in a shock or fire hazard. Call your service
technician for replacement.
Do not Open the Display.
There are no user serviceable components inside.
There are Dangerous High Voltages inside, even when the power is OFF.
Contact your dealer if the display is not operating properly.
To Avoid Personal Injury :
Do not place the display on a sloping shelf unless properly secured.
Use only a stand recommended by the manufacturer.
To Prevent Fire or Hazards:
Always turn the display OFF if you leave the room for more than a short period
of time. Never leave the display ON when leaving the house.
Keep children from dropping or pushing objects into the display's cabinet
openings. Some internal parts carry hazardous voltages.
Do not add accessories that have not been designed for this display.
During a lightning storm or when the display is to be left unattended for an
extended period of time, unplug it from the wall outlet.
A1
Advertisement
Table of Contents
Related Manuals for LG L1510A
Summary of Contents for LG L1510A
- Page 1 Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
-
Page 2: Important Precautions
Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. -
Page 3: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand base Align the hooks on the stand base with the matching slots in the base of the monitor. -
Page 4: Using The Computer
Connecting the Display Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. Connect the power cord into a proper power outlet that is easily accessible and close to the display. NOTE This is a simplified representation of the rear view. This rear view represents a general model;... -
Page 5: Side Jacks
Connecting the Display Side Jacks *Line Out Speaker Out Jack of the PC sound card Display Headphone/Earphone Input Automatically mutes the speaker volume when the headphones are plugged in. Audio Input Connects to the *LINE OUT jack of the PC sound card. *LINE OUT A terminal used to connect to the speaker including a built-in amplifier (Amp). -
Page 6: Control Panel Functions
Control Panel Functions Front Panel Controls L1510A SOURCE MENU AUTO/SELECT L1510T SOURCE MENU AUTO/SELECT Control Function Power Button Use this button to turn the display on or off. Power (DPMS) This Indicator lights up green when the display Indicator operates normally. If the display is in DPM (Energy Saving) mode, this indicator color changes to amber. - Page 7 Control Panel Functions Control Direct Access Function CHANNEL: Use these buttons to go up and down the channel when the TV source is available. VOLUME: Use these buttons to decrease or increase the volume level. AUTO adjustment function When adjusting your display settings, always press the AUTO/SELECT button before entering the On Screen P R O C E S S I N G Display(OSD).
-
Page 8: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. - Page 9 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Using the computer Main menu Sub menu Reference BRIGHTNESS To adjust the brightness and BRIGHTNESS contrast of the screen CONTRAST CONTRAST PRESET 9300K...
-
Page 10: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment Using the VCR/DVD/TV Main menu Sub menu Reference CHANNEL MODE To select the TV channel settings CHANNEL and adjust the channel quality. AUTO CHANNEL MANUAL CHANNEL ADD/DELL CH. FINE TUNE CONTRAST To improve the clarity and VIDEO BRIGHTNESS stability of the screen... - Page 11 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. To adjust the brightness and contrast of the screen OSD Adjust Description...
- Page 12 On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description AUTO This function is suitable for analog signal TRACKING input only. This button is for the automatic adjustment of the screen position, clock AUTO and phase.
- Page 13 On Screen Display(OSD) Selection and Adjustment To adjust the PIP of the screen OSD Adjust Description This PIP (Picture-in-Picture) function allows the image from the TV, VCR or DVD to be displayed on a sub- screen while you are using a computer. PIP ON/OFF PIP SOURCE PIP SIZE...
- Page 14 On Screen Display(OSD) Selection and Adjustment To adjust the screen when using the VCR/DVD/TV To select TV channel settings and adjust the channel quality OSD Adjust Description To select the channel reception type. CHANNEL CHANNEL : AIR/CABLE MODE CHANNEL MODE CABLE AUTO CHANNEL To automatically search the available...
- Page 15 On Screen Display(OSD) Selection and Adjustment To adjust the audio function OSD Adjust Description To decrease or increase volume level. VOLUME AUDIO VOLUME MUTE Used to select mute on (means sound off) MUTE BASS and mute off (means sound on). TREBLE BALANCE STEREO...
-
Page 16: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button. -
Page 17: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is Press the AUTO/SELECT button to incorrect. automatically adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->... -
Page 18: Have You Installed The Display Driver
Troubleshooting Have you installed the display driver? Have you installed the Be sure to install the display driver from the display driver? display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lge.com. Do you see an Make sure to check if the video card supports "Unrecognized monitor,... -
Page 19: Specifications
Specifications 15 inches (38.1cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating 15 inches viewable 0.3 mm pixel pitch Horizontal Freq. 30 - 63kHz (Automatic) Sync Input Vertical Freq. 56 - 75Hz (Automatic) Input Form Separate TTL, Positive/Negative Signal Input 15 pin D-Sub Connector Video Input Input Form... -
Page 20: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 35.000 640 x 480 66.67 VESA 37.861 640 x 480 72.8 VESA 37.500 640 x 480 35.156 VESA 800 x 600... -
Page 21: Using The Remote Control
: SMALL -> LARGE -> OFF PLAY VCR Buttons STOP P/STILL These buttons are available for LG VCR remote controls only. Refer to the Owner’s Manual for your VCR . LIGHT VIEW This function optimizes the brightness, contrast or color value LIGHT VIEW... -
Page 22: Preparing The Remote Control
Using the Remote Control Insert the batteries into the remote This section shows you how to use control to operate the monitor. the remote control. Preparing the Remote Operating with the Remote Control Control Open the battery cover. Point the remote control at the remote sensor and press the buttons. -
Page 23: Connection Of External Equipment
Connection of external equipment Connecting the VCR/DVD Connect the each audio/video output jack of the VCR/DVD to the corresponding input port as shown on the Display. If you connect the S-Video input port to external equipment, you can have an improved definition image. -
Page 24: Watching Tv- Optional
(a) TV tuner pack (Optional): L1510T model includes TV tuner pack. For L1510A models, TV tuner can be purchased as an option from the LGE monitor dealers. Connect the power cord into a proper power outlet that is easily accessible and...
