SAP-FDRV96EH
SAP-FDRV126EH
SAP-FDRV186EH
COOL/DRY/HEAT Model
This air conditioner uses
the new refrigerant R410A.
Pub.
OI-37.4196.145.0
© SANYO 2009
INSTRUCTION MANUAL
Inverter-Controlled Split System Air Conditioner
MANUAL DE INSTRUCCIONES
Acondicionador de aire de dos unidades
controlado por invertidor
Climatiseur de type séparé contrôlé par inverseur
BEDIENUNGSANLEITUNG
Splitsystem-Klimagerät mit Inverter-Steuerung
ISTRUZIONI PER L'USO
Condizionatore d'aria con sistema separato
controllato dall'invertitore
MANUAL DE INSTRUÇÕES
Aparelho de ar condicionado do sistema split com
ΕΓΕΙΡΙ∆ΙO O∆ΗΓΙΩΝ
Save These Instructions!
Guarde estas instrucciones
Conserver ce mode d'emploi
Bewahren Sie bitte diese
Bedienungsanleitung auf.
Conservate queste istruzioni
Guarde estas instruções
MODE D'EMPLOI
inversor controlado
EG
ES
F
D
I
P
GR
Advertisement
Table of Contents
Related Manuals for Sanyo SAP-FDRV96EH
Summary of Contents for Sanyo SAP-FDRV96EH
- Page 1 MANUAL DE INSTRUÇÕES Aparelho de ar condicionado do sistema split com inversor controlado ΕΓΕΙΡΙ∆ΙO O∆ΗΓΙΩΝ Save These Instructions! Guarde estas instrucciones Conserver ce mode d’emploi Bewahren Sie bitte diese Bedienungsanleitung auf. Conservate queste istruzioni Guarde estas instruções Pub. OI-37.4196.145.0 © SANYO 2009...
-
Page 2: Table Of Contents
01_SAP-KRV186EH_EN.fm Page 2 We dnesday, February 13, 2008 1:12 PM FEATURES This air conditioner is an inverter type unit that automatically adjusts capability as appropriate. Details on these functions are provided below; refer to these descriptions when using the air conditioner. •... -
Page 3: Product Information
01_SAP-KRV186EH_EN.fm Page 3 We dnesday, February 13, 2008 1:12 PM PRODUCT INFORMATION ELECTRICAL REQUIREMENTS If you have problems or questions concerning your Air Conditioner, you will need the following information. 1. All wiring must conform to the local electrical codes. Model and serial numbers are on the nameplate on the Consult your dealer or a qualified electrician for bottom of the cabinet. -
Page 4: Names Of Parts
01_SAP-KRV186EH_EN.fm Page 4 We dnesday, February 13, 2008 1:12 PM NAMES OF PARTS UNIT DISPLAY AND OPERATION BUTTON INDOOR UNIT Air intake LED CLEAN lamp Air outlet TIMER lamp OPERATION lamp INDOOR UNIT Air outlet Remote control unit REMOTE Refrigerant tubes CONTROL OPERATION receiver... - Page 5 01_SAP-KRV186EH_EN.fm Page 5 Wednesday, February 13, 2008 1:12 PM REMOTE CONTROL UNIT (DISPLAY) Displayed when transmitting data Displayed when indoor unit sensor is in use Displayed when setting temperature Displayed when temperature is shown Displayed when setting timer Displayed when the time display is set to 12-hour time.
- Page 6 01̲SAP-KRV186EH̲EN.fm Page 6 We dnesday, February 13, 2008 1:12 PM REMOTE CONTROL UNIT Transmitter When you press the buttons on the remote control unit, the mark appears in the display to transmit the setting changes to the receiver in the air conditioner. Display Information on the operating conditions is displayed while the remote control unit is switched on.
- Page 7 01_SAP-KRV186EH_EN.fm Page 7 Wednesday, February 13, 2008 1:12 PM Sensor A temperature sensor inside the remote control unit senses the room temperature. ON/OFF operation button This button is for turning the air conditioner on and off. 1 HR. TIMER button (1-HOUR OFF TIMER) : When you press this button, regardless of whether the unit is operating or stopping, the unit operates for one hour and then shuts down.
-
Page 8: Using The Remote Control Unit
01_SAP-KRV186EH_EN.fm Page 8 We dnesday, February 13, 2008 1:12 PM USING THE REMOTE CONTROL UNIT HOW TO USE THE REMOTE CONTROL UNIT HOW TO INSTALL BATTERIES When using the remote control unit, always point the unit’s transmitter head directly at the air conditioner’s receiver. Air conditioner (Indoor unit) S/M switch... -
Page 9: Operation With The Remote Control Unit
01_SAP-KRV186EH_EN.fm Page 9 Wednesday, February 13, 2008 1:12 PM OPERATION WITH THE REMOTE CONTROL UNIT 1. Automatic Operation 2. Manual Operation When the remote control’s S/M switch is at the “S” (Single) position This unit automatically switches between cooling operation and heating operation according to the difference between the room temperature and the temperature setting. -
Page 10: Adjusting The Fan Speed
01_SAP-KRV186EH_EN.fm Page 10 We dnesday, February 13, 2008 1:12 PM 3. Adjusting the Fan Speed A. In Cooling and DRY Mode: ( A. Automatic fan speed When the night setback mode is selected, the air conditioner Simply set the FAN SPEED selector button to the automatically raises the temperature setting 1 °C when 30 minutes have passed after the selection was made, and then position. -
Page 11: High Power Mode
01_SAP-KRV186EH_EN.fm Page 11 We dnesday, February 13, 2008 1:12 PM 7. HIGH POWER Mode NOTE • Pressing the MODE selector button cancels LED CLEAN mode. • Do not open the front panel while the LED CLEAN lamp on the display is on. •... -
Page 12: Setting The Timer
01_SAP-KRV186EH_EN.fm Page 12 Wednesday, February 13, 2008 1:12 PM SETTING THE TIMER 3. How to set the ON time (Example) To start operation at 7:10 am. Operation Indication Press the ON TIME setting The timer indication is button once. displayed, and the present ON NOTE time is shown. -
Page 13: Using The 1-Hour Off Timer
01_SAP-K R V18 6 EH_EN.f m Page 13 W e dne s da y, Fe bruary 13, 2 008 1 :1 2 PM USING THE 1-HOUR OFF UPPER POSITION: Only the fan of the upper grille is running LOWER POSITION: 1. -
Page 14: Operation Without The Remote Control Unit
01_SAP-KRV186EH_EN.fm Page 14 We dnesday, February 13, 2008 1:12 PM CAUTION Never use solvents, or harsh CAUTION chemicals when cleaning the indoor unit. Do not wipe the plastic casing • Use the FLAP button on the remote control to adjust the using very hot water. -
Page 15: Troubleshooting
01_SAP-KRV186EH_EN.fm Page 15 We dnesday, February 13, 2008 1:12 PM Air Clean Filter Trouble Possible Cause Remedy The air clean filter removes dust and dirt from the air, and reduces odors and smoke from tobacco. Air conditioner does 1. Power failure. 1. - Page 16 End.fm Page 100 Thursday, September 18, 2008 1:49 PM...
- Page 17 End.fm Page 101 Thursday, September 18, 2008 1:49 PM...
- Page 18 End.fm Page 102 Thursday, September 18, 2008 1:49 PM...
- Page 19 End.fm Page 103 Thursday, September 18, 2008 1:49 PM Compliance with regulation 842/EC/2006 Article 7(1) requirements DO NOT VENT R410A INTO THE ATMOSPHERE: R410A IS A FLUORINATED GREENHOUSE GAS, COVERED BY THE KYOTO PROTOCOL, WITH A GLOBAL WARMING POTENTIAL (GWP) = 1975.
- Page 20 End.fm Page 103 Thursday, September 18, 2008 1:49 PM...
