Model No. PFTL71505.0
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for ProForm CROSSWALK CALIBER ELITE PFTL71505.0
Summary of Contents for ProForm CROSSWALK CALIBER ELITE PFTL71505.0
- Page 1 Mon.–Fri., 6 a.m.–6 p.m. MST ON THE WEB: www.proformservice.com CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.proform.com this equipment. Save this manual new products, prizes, for future reference. fitness tips, and much more!
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. .Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the center of this manual. PROFORM is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
(See on page 10. To purchase a surge suppressor, ASSEMBLY on page 6, and HOW TO FOLD see your local PROFORM dealer or call the AND MOVE THE TREADMILL on page 23.) toll-free telephone number on the front cover... - Page 4 21. When folding or moving the treadmill, make tenance and adjustment procedures de- sure that the storage latch is fully closed. scribed in this manual. Never remove the motor hood unless instructed to do so by an 22. Inspect and properly tighten all parts of the authorized service representative.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new PROFORM ® CROSS- manual. To help us assist you, note the product model WALK CALIBER ELITE treadmill. The CROSSWALK number and serial number before calling. The model CALIBER ELITE treadmill offers an impressive array of number of the treadmill is PFTL71505.0. -
Page 6: Assembly
ASSEMBLY To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 7 2. Attach a Wheel (66) to the base of the Uprights (69) with a Wheel Bolt (64) and a Nut (13) as shown. Do not overtighten the Bolt; the Wheel should turn freely. With the help of a second person, carefully tip the tread- mill onto its other side.
- Page 8 5. If there is a board between the Uprights (69), remove the board and the two bolts. Discard the board and the bolts. Identify the Right Handrail (72), which has a large hole in the left side. Remove the wire tie securing the Upright Wire (42) inside of the right Upright (69).
- Page 9 8. Set the Console Base (47) on the Handrails ( 71, 72). Attach the Console Base with four 3/4” Screws (2). Start all four Screws before tightening them; do not over- tighten the Screws. See the lower drawing. Make sure that the Upright Wire (42) is routed below the two indicated round posts (A).
-
Page 10: Operation And Adjustment
Grounded Outlet Box the right). To purchase a surge suppressor, see Adapter your local PROFORM dealer or call the toll-free Surge Suppressor telephone number on the front cover of this man- ual and order part number 146148, or see your local electronics store. - Page 11 CONSOLE DIAGRAM Note: If there is a sheet of clear plastic Clip on the console, peel off the plastic. FEATURES OF THE CONSOLE you can connect the treadmill to your portable stereo, home stereo, computer, or VCR and play special The treadmill console offers an impressive array of iFIT.com MP3, CD, and video programs (iFIT.com MP3 features designed to make each workout more effective...
- Page 12 HOW TO TURN ON THE POWER Press the Start button to start the walking belt. Plug in the power cord When the Start button is (see page 10). Next, lo- pressed, the walking Reset cate the reset/off circuit belt will begin to move at Position breaker on the treadmill 1 mph.
- Page 13 The upper left corner Measure your heart rate if desired. of the display will show the approximate Note: Before number of calories using the you have burned dur- handgrip ing your workout. pulse sensor, Note: When the calorie goal program is selected, remove the Contacts the display will show the number of calories still to...
- Page 14 When the first period is completed, all speed set- HOW TO USE A SPEED & INCLINE PROGRAM tings will move one column to the left . The speed setting for the second period will then be shown in Insert the key into the console. the flashing Current Period column and the tread- mill will automatically adjust to the speed and in- See HOW TO TURN ON THE POWER on page...
- Page 15 The upper left corner of the display will show the HOW TO USE A DISTANCE PROGRAM number of meters still to be run. When only 20 meters remain, the display will flash and a series Insert the key into the console. of tones will sound.
- Page 16 be recalculated—the higher the calorie goal is, or HOW TO USE THE CALORIE GOAL PROGRAM the lower the speed setting is, the longer the pro- gram will last. Insert the key into the console. Press the Start button to start the program. See HOW TO TURN ON THE POWER on page A moment after the button is pressed, the walking belt will begin to move at 2.5 mph (or the speed...
- Page 17 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO USE IFIT.COM PROGRAMS Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 1/8” LINE OUT jack, see instruction B. If your To use iFIT.com MP3 or CD programs, the treadmill stereo has only a PHONES jack, see instruction C.
- Page 18 HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, A. Plug one end of a long 1/8” to 1/8” stereo audio see instruction A below. If the LINE OUT jack is cable (available at electronics stores) into the input being used, see instruction B.
- Page 19 HOW TO CONNECT YOUR VCR HOW TO USE AN IFIT.COM MP3, CD, OR VIDEO PROGRAM Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV To use an iFIT.com MP3, CD, or video program, the with a built-in VCR, see instruction B.
- Page 20 If the speed or incline settings are too high or too • Make sure that the audio cable is properly low, you can manually override the settings at any connected. time by pressing the Speed or Incline buttons on • If you are using a portable CD player and the the console.
- Page 21 Hold the handrails, step onto the walking belt, and HOW TO USE AN IFIT.COM PROGRAM begin walking. During the program, an electronic DIRECTLY FROM OUR WEB SITE “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change. CAUTION: Always listen for the “chirp”...
- Page 22 THE INFORMATION MODE/DEMO MODE HOW TO USE THE UPPER BODY ARMS As you walk on the treadmill, you can hold the The console features an information mode that keeps handrails or use the upper body arms. To exercise track of treadmill usage information and allows you to your arms, shoulders, and back for a total body work- select a system of measurement.
-
Page 23: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be- come permanently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill. - Page 24 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the treadmill with your right hand as shown. Pull the latch knob to the left and hold it. Pivot the frame down until it is past the latch pin. Latch Knob Frame 2.
-
Page 25: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 26 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.
-
Page 27: Conditioning Guidelines
CONDITIONING GUIDELINES begin to use stored fat calories for energy. If your goal WARNING: is to burn fat, adjust the speed and incline of the tread- Before beginning this mill until your heart rate is near the lowest number in or any exercise program, consult your physi- your training zone. - Page 28 PART LIST—Model No. PFTL71505.0 R1205A No. Qty. Description No. Qty. Description No. Qty. Description Hood Extension Leg Nut Ground Screw 3/4” Screw Console Base Extension Leg Bolt Motor Belt 1/2” Screw Allen Wrench Motor Tension Bolt Wire Clamp Handrail Star Washer 3/8”...
- Page 29 EXPLODED DRAWING—Model No. PFTL71505.0 R1205A...
-
Page 30: Ordering Replacement Parts
• the MODEL NUMBER of the product (PFTL71505.0) • the NAME of the product (PROFORM CROSSWALK CALIBER ELITE treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER and DESCRIPTION of the part(s) (see the EXPLODED DRAWING and the PART LIST in...
