Gas
Range
Welcome.......................................... 2
ES510 Control, Self-Cleaning Oven
with Deep Well Style Cooktop
Features at a Glance ...................... 5
Setting Surface Controls ............... 7
Control Pad Features ................... 10
Setting Oven Controls ............. 11-24
Self Cleaning........................... 25-27
Questions or for Service Call:
1-800-944-9044
31
Solutions to Common Problems ........................
(U.S.)
1-800-668-4606
(Canada)
Warranty ......................... Back Page
p/n 316417132 (0706)
READ AND SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading

Summary of Contents for Electrolux ES510

  • Page 1: Table Of Contents

    Visit the Frigidaire Web Site at: http://www.frigidaire.com Range Welcome.......... 2 ES510 Control, Self-Cleaning Oven Important Safety Instructions ..3-4 with Deep Well Style Cooktop Features at a Glance ...... 5 Before Setting Oven Controls ..6 Setting Surface Controls ....7 Warming Drawer Controls ..8-9...
  • Page 2: Welcome

    Product Registration Be sure to register your product. The self-addressed PRODUCT REGISTRATION CARD should be filled in completely, signed and returned to Electrolux Home Products. Grounding Instructions Avoid fire hazard or electrical shock. Do not use an adapter plug, an extension cord, or remove grounding prong from electrical power cord.
  • Page 3: Important Safety Instructions

    Important Safety Instructions Read all instructions before using this appliance. Save these instructions for future reference. This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given. This symbol will help alert you to situations that may cause serious bodily harm, death or property damage. This symbol will help alert you to situations that may cause bodily injury or property damage.
  • Page 4 Important Safety Instructions • Glazed Cooking Utensils—Only certain types of glass, glass/ • Do Not Leave Children Alone—Children should not be left ceramic, ceramic, earthenware, or other glazed utensils are alone or unattended in the area where appliance is in use. suitable for cooktop service without breaking due to the They should never be allowed to sit or stand on any part of the sudden change in temperature.
  • Page 5: Features At A Glance

    Features At A Glance Your Gas Range Features Include: 1. Electronic Oven Control with Kitchen Timer. 2. Warming Drawer Control & Indicator Light (some models). 3. Left Front Burner Valve & Knob. 4. Left Rear Burner Valve & Knob. 5. Center Burner Valve & Knob (some models). 6.
  • Page 6: Before Setting Oven Controls

    Before Setting Oven Controls Oven Vent Location The oven vent is located below the backguard (See Fig. 1). When the oven is on, warm air is released through this vent. This venting is necessary for proper air circulation in the oven and good baking results. DO NOT BLOCK THE VENT. Removing &...
  • Page 7: Setting Surface Controls

    Setting Surface Controls Setting Surface Controls Do not place plastic Your range may be equipped with different sized surface burners. The ability to items such as salt and pepper heat food quicker and in larger volumes increases as the burner size increases. shakers, spoon holders or plastic wrappings on top of the range when The SIMMER burner (some models) is best used for simmering delicate food...
  • Page 8: Warming Drawer Controls

    Setting Surface Controls Care of the Griddle Before first use: • Wash Griddle in hot soapy water. Rinse and then dry completely. After each use: • Store in a dry place. • After each use, clean with hot soapy water. •...
  • Page 9 Setting Warming Drawer Controls Removing & Replacing the Warming Drawer To Set the Warming Drawer Control Warming Drawer Recommended The control is used to select the temperature of the Warming Drawer. It is Food Settings Table located on the control panel. To set the control, push in and turn the knob to the desired setting.
  • Page 10: Control Pad Features

    Control Pad Features READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various features and functions of the oven as described below. Detailed instructions for each feature and function follow later in this Use & Care Guide. OVEN LIGHT—Use BAKE—Use to...
  • Page 11: Setting Oven Controls

    Setting Oven Controls Setting the Clock The CLOCK pad is used to set the clock. The clock may be set for 12 or 24 hour time of day operation. The clock has been preset at the factory for the 12 hour operation. When the range is first plugged in, or when the power supply to the range has been interrupted, the timer in the display will flash with power failure "PF"...
  • Page 12 Setting Oven Controls Setting Continuous Bake or 12 Hour Energy Saving The TIMER ON/OFF and CLEAN pads control the Continuous Bake or 12 Hour Energy Saving features. The oven control has a factory preset built-in 12 Hour Energy Saving feature that will shut off the oven if the oven control is left on for more than 11 hours and 59 minutes.
  • Page 13 Setting Oven Controls Setting Oven Lockout Feature pad controls the Oven Lockout feature. The Oven Lockout feature automatically locks the oven door, prevents the Warming Drawer and most oven controls from being turned ON. It does not disable the clock, Kitchen Timer or the interior oven light.
  • Page 14 Setting Oven Controls Setting Silent Control Operation The START TIME and CLEAN pads control the Silent Control operation feature. The Silent Control operation feature allows the oven control to be operated without sounds or beeps whenever necessary. If desired the control can be programmed for silent operation and later returned to operating with all the normal sounds and beeps.
  • Page 15 Setting Oven Controls Setting Bake The BAKE pad controls normal baking. The oven can be programmed to bake at any temperature from 170°F to 550°F (The sample shown below is for 350°F). INSTRUCTIONS PRESS DISPLAY To set the Bake Temperature to 350°F: 1.
  • Page 16 Setting Oven Controls Setting Timed Bake The BAKE and BAKE TIME pads control the Timed Bake feature. The automatic timer of the Timed Bake feature will turn the oven OFF after cooking for the desired amount of time you selected. INSTRUCTIONS PRESS DISPLAY...
  • Page 17 Setting Oven Controls Setting Delayed Timed Bake The BAKE , BAKE TIME and START TIME pads control the Delayed Timed Bake feature. The automatic timer of the Delayed Timed Bake will turn the oven ON and OFF at the time you select in advance. INSTRUCTIONS PRESS DISPLAY...
  • Page 18 DO NOT put water or flour on the fire. Flour may be explosive and water can cause a grease fire to spread and cause personal injury. To insure proper results when broiling use ONLY Electrolux Home Products, Inc. approved Broil Pan & Insert.
  • Page 19 Setting Oven Controls Benefits of Convection Bake: —Some foods cook up to 25 to 30% faster, saving time and energy. —Multiple rack baking. —No special pans or bakeware needed. Setting Convection Bake Roasting The CONV BAKE pad controls the Convection Bake feature. Use Shelf the Convection Bake feature when cooking speed is desired.
  • Page 20 Setting Oven Controls Setting Convection Roast The CONV ROAST pad is designed to give optimum cooking performance for this feature. The Convection Roast pad combines a cook cycle with the convection fan and element to roast meats and poultry. Preheating is not necessary for meats and poultry.
  • Page 21 Setting Oven Controls To set the Convection Convert Feature CONV CONVERT pad is used to automatically convert a standard baking recipe for convection baking. When set properly, this feature is designed to display the actual converted (reduced) temperature in display. Convection Convert may ONLY be used with a Bake, Timed Bake or a Delayed Timed Bake setting.
  • Page 22 Setting Oven Controls Using the Favorite Setting Feature FAVORITE SETTING pad is used to record and recall your favorite recipe settings. This feature may store and recall from 1 to 3 different settings. The Favorite Setting feature may be used with Bake or a Timed Bake. This feature will not work with any other function including a Delayed Timed Bake setting.
  • Page 23 Setting Oven Controls Setting the Sabbath Feature (for use on the Jewish Sabbath & Holidays) BAKE TIME and START TIME pads are used to set the Sabbath feature. The Sabbath feature may only be used with the pad. The oven temperature may be set higher or lower after setting the Sabbath feature (the oven temperature adjustment feature should be used only during Jewish Holidays), however the display will not visibly show and no audible tones will be provided when a change occurs.
  • Page 24 Setting Oven Controls Setting the Sabbath Feature (cont’d) It is recommended that any oven temperature change with the Sabbath feature activated be followed with 2 presses of the START pad. This will insure the oven remains ON even if the attempt to set the oven temperature was lower or higher than the oven control can accept.
  • Page 25: Self Cleaning

    Self-Cleaning Self-Cleaning Oven A Self-Cleaning oven cleans itself with high temperatures (well above cooking temperatures) which eliminate soils completely or reduces them to a fine powdered ash you can wipe away with a damp cloth. Adhere to the following cleaning precautions: During the Self-Cleaning •...
  • Page 26 Self-Cleaning The SPEED CLEAN , CLEAN & MAXX CLEAN pads are used to start a Self-Cleaning cycle. When used with START TIME pad, a delayed Self-Cleaning cycle may also be programmed. This feature allows for any Self-Cleaning cycle times from 2 hours (using Speed Clean), 3 hours (using Clean) to 4 hours (using Maxx Clean). During the Self-Cleaning cycle, the outside of the range can become very hot to the touch.
  • Page 27: Adjusting Oven Temperature

    Self-Cleaning INSTRUCTIONS PRESS DISPLAY When the Self-Clean cycle is done: 1. The time of day,"DOOR LOCKED" and "CLEAN" icon will remain in the display. 2. Once the oven has cooled down for approximately 1 HOUR, and the "DOOR LOCKED" icon is no longer displayed, the oven door can then be opened.
  • Page 28: General Care & Cleaning

    General Care & Cleaning (Cleaning Table) Surfaces How to Clean Glass, Painted For general cleaning, use a soft cloth, clean with mild dish detergent & water or a 50/50 solution Plastic Body Parts & of vinegar & water. Follow by rinsing the area with clean water; dry & polish with a soft cloth. Control Knobs Glass cleaners may be used if sprayed on a soft cloth 1st.
  • Page 29 General Care & Cleaning Cleaning the Contoured Cooktop Well Areas, Burner Cap, Burner Head and Burner Drip Pans (some models) The contoured well areas, burner cap, burner head and burner drip pans (some models) should be routinely cleaned. Keeping the burner ports clean will prevent improper ignition and an uneven flame. Refer to the following instructions: THE COOKTOP IS NOT REMOVABLE.
  • Page 30 General Care & Cleaning Removing and Replacing the Lift-Off Oven Door The door is heavy. For safe, temporary storage, lay the door flat with the inside of the door facing down. Door Hinge To Remove Oven Door: locations with oven door 1.
  • Page 31: Before You Call

    Before You Call Solutions to Common Problems Before you call for service, review the following list. It may save you time & expense. The list includes common occurrences (shown in bold) that are not the result of defective workmanship or materials in this appliance. The possible corrections to these problems are provided with the problem listed: Range is not level - (1) Poor installation.
  • Page 32: Warranty

    This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
