    1 – INTRODUCTION This “assembly manual” for SHAN awnings has been produced by SHADELAB to supply the indications necessary for the operations of assembling the components that make up the product. Assembly must be carried out by personnel with suitable technical and professional qualifications, in accordance with the respective national laws or regulations (see Par.
  • Page 5: Necessary Equipment

    »»rawlplugs; »»spirit level; »»string. 1.3 - Before starting IMPORTANT Some components must be cut to suit the dimensions of the awning that is to be obtained (see Par. 3.3 “Table of cutting dimensions”). SHAN INSTALLATION – REV 00...
  • Page 6: Safety

    IMPORTANT SHADELAB guarantees the EC marking only for products supplied by the company itself. If any parts have to be replaced with other components not guaranteed by SHADELAB, the product guarantee will automatically become void and SHADELAB shall not answer for any malfunctions of the product.
  • Page 7: Working Environment

    If a ladder is required during installation, make sure that it is firmly placed on the ground in order to prevent it from tipping and causing serious injury to the people involved in installation operations. ATTENTION Make sure there are no people, animals and objects nearby when the awning opens and closes. SHAN INSTALLATION – REV 00...
  • Page 8: Shan Components And Diagrams

    3 - SHAN COMPONENTS AND DIAGRAMS 3.1 Tilting diagrams Dimensions of closed awning Wall mounting Arm length and inclination Wall and roof mounting with special bracket SHAN INSTALLATION – REV 00...
  • Page 9: Shan Technical Sheet

    4 - SHAN Technical sheet Fixing bracket SHAN INSTALLATION – REV 00...
  • Page 10 Shan with 2, 3, 4 arms SHAN INSTALLATION – REV 00...
  • Page 11: Installation Shan

    5 – Intallation Shan Brackets position for Shan on the wall SHAN INSTALLATION – REV 00...
  • Page 12 Brackets position for Shan on the wall SHAN INSTALLATION – REV 00...
  • Page 13 Install Shan ATTENTION: to respect the position of the awning according to the drawing. The support arm must be in correspondence of the bracket. ATTENTION: Install the awning on the brackets fixed to the wall Particular view of the bracket...
  • Page 14 ATTENTION: Ensure that there are no persons, animals or things in the vicinity while opening/clos- ing the awning. Open the awning and check that the brackets are at the arm supports. ATTENTION: The central part of the support should be within the width of the bracket SHAN INSTALLATION – REV 00...
  • Page 15 ATTENTION: Loosen the adjustment screw (see ref. 2) to increase the inclination; tighten it to decrease the inclination. ATTENTION: During adjustment, support the arm or terminal bar to simplify work. ATTENTION: This operation must be performed by inclining each arm a little at a time 13 I SHAN INSTALLATION – REV 00...
  • Page 16 Regulating the awning ATTENTION: When the arm support is very close to the side caps, remove the cap acting on the elected and block the dowel (ref 3 of fig. above) as shown in the picture SHAN INSTALLATION – REV 00...
  • Page 17 If they are not parallel, turn the pin of the arm (see ref. 1) to raise or lower it. ATTENTION:Then secure the pin by tightening the dowel (see ref. 2) 15 I SHAN INSTALLATION – REV 00...
  • Page 18 SHAN Installation manual COUPLED VERSION - INTEGRATION...
  • Page 19 The awning is supplied as shown in figure: (ref.1) Cassette profile (ref.2) Cover profile (ref.3) Saddle profile (ref.4) Terminal profile (ref.5) Bracket (rif.6) End plate (ref.8) Self-lubricating tape (ref.9) Roller tube (ref.10) Fabric – SHAN INSTALLATION REV 00...
  • Page 20: Installation Shan - Coupled Version - Integration

    Fit the cassettes onto the brackets and secure with the M8 countersunk screws (ref. 4) (allen wrench FITTING CENTRAL SUPPORT WARNING: Mount the central support and fix it with the M8x20 screws (ref.5) (allen wrench 6) on the plate positioned previously (ref.6); insert the L100 saddle profile (ref.7) on the support. – SHAN INSTALLATION REV 00...
  • Page 21 WARNING: Slide the fabric into the tube, centre, and lock it. FABRIC ROLLING WARNING: Roll up the fabric on the roller tube. WARNING: Be careful with the fabric rolling direction; the fabric must always run at the underneath (ref.8). – SHAN INSTALLATION REV 00...
  • Page 22 WARNING: Insert the tube onto the plate with pin; on the motor side, fix the roller tube support with the M6x16 screw (ref.10) onto the square nut (ref.11) inserted into the cassette (allen wrench 5). COUPLING SADDLE PROFILE WARNING: Couple the two saddle profiles using the plugs (ref. 12). – SHAN INSTALLATION REV 00...
  • Page 23 WARNING: The tapes should be applied first on the outer side (ref. 16) and then on the inside (ref. 17), making sure they adhere correctly. WARNING: In the central part, one tape must be applied on the joint (ref. 18) and one next to it on both sides. – SHAN INSTALLATION REV 00...
  • Page 24 WARNING: Insert the saddle profile along with the cover profile supports on the cassette; for projections higher than 3 m, partly unroll the fabric. WARNING: insert the M6x16 screws (ref. 19) into the corresponding square nuts (ref. 20) – SHAN INSTALLATION REV 00...
  • Page 25 WARNING: Slightly tighten the M6 dowels (ref.25) onto the cover profile supports, just enough to adjust the tightness between cover profile support and saddle profile (allen wrench 3). COUPLING COVER PROFILE WARNING: Insert the cover profile onto the pre-assembled joint and fix the M6 countersunk screws (allen wrench 5). – SHAN INSTALLATION REV 00...
  • Page 26 WARNING: Slide the terminal profiles into the fabric and the terminal bar connecting plates (ref. 30) on both sides. WARNING: Couple the profiles with the pre-assembled joints (ref. 31) tightening the M6 countersunk screws (allen wrench 5). – SHAN INSTALLATION REV 00...
  • Page 27 INSERTING GASKET AND BRUSH WARNING: Insert the gasket into the terminal bar and the brush into the cover profile; secure the latter with the self-drilling screw on both ends (ref. 34). – SHAN INSTALLATION REV 00...
  • Page 28 WARNING: After checking that the arms are aligned, and the terminal bar is centred, lock the fabric and insert the terminal bar end caps and the cassette end covers. WARNING: For the awning adjustment please refer to the standard installation manual. – SHAN INSTALLATION REV 00...
