Step 15: Connect the wires
● Before connecting, make sure the wires are clean.
● Connect the wires to Nest Hello. It doesn't matter which terminal
you connect a wire to. Make sure the wires point down, not up,
so any excess can be tucked back into the wall.
● If the wires are too short, use the wire extenders that are
included in the box.
Step 16: Mount the doorbell
● To attach Nest Hello, simply slide the top of the doorbell into the
backplate. Then press until the doorbell clicks into place.
● If it doesn't seat properly or you don't hear a click, re-check that
you've fully tucked any excess wire back into the hole.
● If you ever need to remove Nest Hello, push the included release
tool (or a thumbtack) into the hole on the bottom to release it.
Step 17: Switch the power on
Go to the home's breaker or fuse box and turn on the power to
the doorbell and chime.
Step 18: Check that Hello is on
Nest Hello will take a few seconds to turn on. You'll hear a chime and the light ring should start pulsing
blue. If it's not, select "No, it's not blue" in the app and it will help you troubleshoot.
