- Page 1 MultiHaul™ TG Wireless 60 GHz L2 SDN Mesh for Multi-Gigabit Ethernet Installation, Operation and Maintenance Manual MHTG-I&O-01, Issue A03 February 2021...
- Page 2 Trademarks Siklu, the Siklu logo, and MultiHaul™ are all trademarks of Siklu Communication Ltd. All other product names and trademarks mentioned in this document are trademarks or registered trademarks of their respective companies. Copyrights Copyright © 2021 Siklu Communication Ltd. All rights reserved.
-
Page 3: Table Of Contents
4.10.1 Node Checks ..............................29 4.10.2 TU Checks ..............................29 This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. - Page 4 4.2 Configuring Management IPv4 Address \ Default Gateway ................. 32 This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved.
-
Page 5: Introduction
1. Introduction 1. Introduction 1.1 Scope This document describes how to install, configure, operate and maintain the MultiHaul™ TG, Siklu’s Wireless 60 GHz L2 SDN Mesh for Multi-Gigabit Ethernet. 1.2 Applicable Products and Releases • MultiHaul™ TG Node N366 •... -
Page 6: List Of Abbreviations
Small Form Factor Small Form-Factor Pluggable Terminal Unit Ultraviolet This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 7: Safety And Regulatory Notices
Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Siklu Communication Ltd) could void the user's authority to operate the equipment. 2.3 Canada Regulatory Statements This Class B digital apparatus complies with Canadian ICES-003. -
Page 8: Eu Regulatory Notes
Siklu Communication Ltd and its resellers or distributors are not liable for injury, damage or violation of regulations associated with the installation of outdoor units or antennas. -
Page 9: Multihaul™ Tg Overview
MultiHaul™ TG N366 - a compact multi-sector unit deployed as a L2 SDN mesh node with built-in self-backhaul. Nodes can connect to additional N366 nodes to build a resilient wireless backbone across the served area, or to a network POP via either a fiber connection or a Siklu EtherHaul™ link with up to 10 Gbps FD. •... - Page 10 Additional information is provided in this manual, as well as in the N366 and T26x datasheets and product descriptions. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved.
-
Page 11: Installing The Multihaul™ Tg Units
• Directly on a wall using the AX-MK-WM accessory, ordered separately from Siklu or your reseller. Do not mount a MultiHaul™ TG unit on a structure that is temporary or easily moved. Doing so may result in poor service or equipment damage. -
Page 12: Cabling Requirements
Improper electrical grounding can result in excessive electromagnetic interference or electrical discharge. Siklu will not be held responsible for any malfunction or damage if the unit is not properly grounded. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior... -
Page 13: Node Orientation
Sector 1 is the reference sector for node orientation. Make sure you obtain the azimuth for sector 1 from your or Siklu's Planning Team before installing, and align sector 1 along this planned azimuth, as described Section 4.5 - Mounting and Aligning the MultiHaul™ TG Node on a Pole, Step 7. -
Page 14: Mounting And Aligning The Multihaul™ Tg Node On A Pole
3. If all four sectors have a clear field of view and are not blocked by the pole, tighten the self-locking bands. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. - Page 15 5. Slide the node into the mounting bracket. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved.
- Page 16 The node is now mounted on the pole. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved.
- Page 17 8. Once sector 1 faces the target azimuth, tighten the self-locking bands if required to secure the bracket to the mounting pole. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved.
-
Page 18: Mounting The Multihaul™ Tg Node On A Wall
The node can be mounted on a wall using the AX-MK-WM accessory and four wall-mount screws (not provided), as shown in the following figure: Order the AX-MK-WM accessory separately from Siklu or your reseller. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior... -
Page 19: Mounting And Aligning The Multihaul™ Tg Tu On A Pole Or Wall
: ±35° (25° electronically and 10° mechanical adjustment, achieved through the elevation lock bolts). This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 20: Connecting Cables
Radiological Health) registered if deploying in the USA. For future use This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 21: Connecting The Cables To The Multihaul™ Tg Tu
The provided protective all-weather shells fit cables from 3.5 mm to 9.0 mm in diameter. In some installations, the cables to the units are protected inside a 3/4" flexible conduit. Siklu provides an adapter to maintain the Ingress Protection (IP) rating of the installation by matching the all-wather shell termination to a Liquid Tight Adaptor (LTA) of your choice. -
Page 22: Grounding Multihaul™ Tg Units
16 AWG grounding cable minimum or according to local electrical code. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 23: Installing Lightning Surge Protectors On Cables
PoE through the Ethernet cable connected to ETH1. • Direct DC (input range: 36÷57 Vdc) by using an RJ45-DC adapter that can be purchased from Siklu or your reseller (P/N EH-PoE-DC-adaptor). In this case, port ETH1 will be used for power only. -
Page 24: Unit Leds
On - 1 GbE link. Orange • No Link (carrier). This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 25: Link Up Verification
You can use the GUI or CLI for advanced configuration of the units, monitoring their status and troubleshooting. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 26: Resetting The Unit
10 second or more press - reset to factory default. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 27: Management Concepts
After you type your username, the prompt changes to [username]@[unit ip address]: This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. -
Page 28: Configuring Management Ipv4 Address \ Default Gateway
To set management IPv4 addresses and a default gateway, type the following commands: This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. - Page 29 { ip 31.168.34.110; prefix-length 29; default-gateway 31.168.34.105; This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved.
