Summary of Contents for Extreme Networks NG300
- Page 1 Sentriant NG Installation Guide Extreme Networks, Inc. 3585 Monroe Street Santa Clara, California 95051 (888) 257-3000 (408) 579-2800 http://www.extremenetworks.com Published: January 2008 Part number: 100288-00 Rev. 01...
- Page 2 ServiceWatch, Summit, SummitStack, Triumph, Unified Access Architecture, Unified Access RF Manager, UniStack, the Extreme Networks logo, the Alpine logo, the BlackDiamond logo, the Extreme Turbodrive logo, the Summit logos, the Powered by ExtremeXOS logo, and the Color Purple, among others, are trademarks or registered trademarks of Extreme Networks, Inc.
-
Page 3: Table Of Contents
Table of Contents Preface... 5 About this Guide ...5 Organization of this Guide...5 Conventions...5 Related Publications ...6 Chapter 1: About the Sentriant NG Appliance ... 7 Chassis Overview...7 Front Panel Features ...7 Back Panel Features...8 LED Operation ...8 Chapter 2: Site Preparation and Unpacking ... 9 Site Requirements for the Sentriant NG Appliance ...9 Rack Ventilation Requirements...9 Unpacking the Sentriant NG Appliance ...10... - Page 4 Table of Contents Appendix B: Technical Specifications ... 31 Specifications...31 FCC Class A Notice ...33 User Information ...33 ICES-003 Class A Notice ...34 Index ... 35 Sentriant NG Installation Guide...
-
Page 5: Preface
Appendix A, “Safety Information” ● Appendix B, “Technical Specifications” ● Conventions Table 1 Table 2 list conventions used in Extreme Networks customer documentation. Table 1: Notice Icons Icon Notice Type Alerts you to... Note Important information, helpful suggestions, or reference material. -
Page 6: Related Publications
Sentriant NG Manager User Guide ● ● Sentriant Rules Guide Documentation for Extreme Networks products is available from the Extreme Networks website at the following location: http://www.extremenetworks.com/services/documentation Description This typeface represents information as it appears on the screen, command syntax, or text you enter on a command line. -
Page 7: Chapter 1: About The Sentriant Ng Appliance
● that will be monitored by the Sentriant NG appliance. USB ports—Used for technical support only. Do not insert any device into these ports unless ● instructed by an Extreme Networks technician. Sentriant NG Installation Guide Ethernet Serial console port... -
Page 8: Back Panel Features
About the Sentriant NG Appliance Back Panel Features Figure 2 shows the back panel of the Sentriant NG appliance. Figure 2: Back Panel Features AC power connector The back panel of the Sentriant NG appliance has the following features: AC power connector ●... -
Page 9: Chapter 2: Site Preparation And Unpacking
Site Preparation and Unpacking This chapter includes the following sections: Site Requirements for the Sentriant NG Appliance on page 9 ● Unpacking the Sentriant NG Appliance on page 10 ● Site Requirements for the Sentriant NG Appliance The Sentriant NG appliance can be rack-mounted in a standard 19-inch rack. Be sure to locate the system away from heat sources and in an area that provides unobstructed air flow to the chassis cooling vents. -
Page 10: Unpacking The Sentriant Ng Appliance
Do not unpack the Sentriant NG appliance until you are ready to install it. Storing the chassis in its shipping container helps protect it from accidental damage. Package Contents When you unpack the shipping container, confirm that you received the following items: Extreme Networks Sentriant NG appliance ● Bracket mounting kit: ●... -
Page 11: Chapter 3: Installing The Sentriant Ng Appliance
Installing the Sentriant NG Appliance This chapter includes the following sections: Overview on page 11 ● Required Tools and Equipment on page 12 ● Attaching the Mounting Brackets on page 12 ● Installing the Sentriant NG Appliance in a Rack on page 13 ●... -
Page 12: Required Tools And Equipment
Installing the Sentriant NG Appliance Required Tools and Equipment You need the following items to install the Sentriant NG appliance: Mounting bracket kit (provided with the Sentriant NG appliance): ● Eight #6-32 x 1/4-inch Phillips screws ■ Two rack-mounting brackets ■... -
Page 13: Installing The Sentriant Ng Appliance In A Rack
Installing the Sentriant NG Appliance in a Rack CAUTION The Sentriant NG appliance weighs approximately 40 pounds (18 kilograms). Lifting the Sentriant NG appliance and attaching it to the rack is a two-person job. To install the Sentriant NG appliance in a rack: 1 Determine the mounting location for the Sentriant NG appliance. -
Page 14: Connecting Cables
Management port ● Category 5 or equivalent UTP cable Connect a appliance to an available 10/100/1000BASE-T I/O port on an Extreme Networks I/O module or switch. Detection/mitigation port ● Connect two category 5 or equivalent UTP cables from detection/mitigation ports 1 and 2 on the Sentriant NG appliance to two open 10/100/1000BASE-T I/O ports on an Extreme Networks switch. - Page 15 Sentriant NG Installation Guide...
- Page 16 Installing the Sentriant NG Appliance Sentriant NG Installation Guide...
-
Page 17: Chapter 4: Start-Up And Initial Configuration
● Requirements Before the Initial Setup You must configure a read-only port and a VLAN read-write port on the Extreme Networks switch before performing the initial setup of the Sentriant NG appliance. The read-write port must be mirrored to the read-only port. The VLAN read-write port must be tagged to all VLANs being protected by the Sentriant NG appliance. -
Page 18: Navigating In The Text User Interface
Start-Up and Initial Configuration Navigating in the Text User Interface Use the tab keys, the arrow keys, and the spacebar to navigate between fields or to select a command option in a configuration screen. Press [Enter] to execute a command option. NOTE The screen shots that illustrate the initial configuration sequence are intended as examples only. - Page 19 The Extreme Networks Sentriant Welcome screen is displayed. 3 Use the tab key to select <Next> and press [Enter] to continue. 4 The Extreme Networks End User License Agreement is displayed. Read the entire license agreement. If you agree, select <Accept> and press [Enter] to continue.
- Page 20 Start-Up and Initial Configuration 5 The Host IP Configuration screen is displayed. When you configure the IP address for a Sentriant NG appliance, this address is assigned as the management IP address. Workstations running Sentriant NG Manager will use this address to connect to the Sentriant NG appliance.
- Page 21 Enter passwords for the admin, support, and root accounts. Passwords must have eight or more characters and include a capital letter, a number, and a special character such as @ or #. You will need to verify passwords for each account. Record the passwords.
- Page 22 Start-Up and Initial Configuration 8 Select <Finish> and press [Enter] to continue. The Installation status screen is displayed while the database is initialized. 9 When initialization is complete, the screen displays <OK>. Select <Finish> and press [Enter] to close the text user interface. At this point the Sentriant NG appliance is detecting and monitoring network segments.
-
Page 23: Installing The Sentriant Ng Manager Software
Installing the Sentriant NG Manager Software You must install the Sentriant NG Manager software either from the CD shipped with your Sentriant NG appliance, or by downloading the Sentriant NG Manager software from the Extreme Networks website. To install the Sentriant NG Manager: 1 Insert the CD and follow the on-screen instructions for installing the Sentriant NG Manager. -
Page 24: Using The Online Help System
Sentriant NG Manager can be started in demonstration mode for training and to review the software. If you double-click three times on the Extreme Logo, the Sentriant NG Manager does not connect to a Sentriant NG appliance and runs locally. You can run demonstration mode either with or without training data. -
Page 25: Appendix A: Safety Information
Safety Information WARNING! Read the following safety information thoroughly before installing Extreme Networks products. Failure to follow this safety information can lead to personal injury or damage to the equipment. Only trained service personnel should perform service to Extreme Networks switches and their components. -
Page 26: Maintenance Safety
EMC regulations. The chassis cover should only be removed by Extreme Networks personnel. There are no customer ● serviceable components in this system. Repairs to the system must be performed by an Extreme Networks factory service technician. -
Page 27: Battery Replacement And Disposal
Battery Replacement and Disposal The lithium battery in this equipment is not user-replaceable. It must be replaced by qualified Extreme Service personnel only. Contact your Extreme Service personnel for product replacement. Do not attempt to replace the battery. If these instructions are disregarded and replacement of these batteries is attempted, the following guidelines must be followed to avoid danger of explosion: Replace with the same or equivalent battery type as recommended by the battery manufacturer. - Page 28 Sicherheitshinweise WARNUNG! Vor der Installation der Produkte von Extreme Networks sind die nachfolgenden Sicherheitshinweise aufmerksam zu lesen. Die Nichtbeachtung dieser Sicherheitshinweise kann zu Verletzungen oder Schäden an der Ausrüstung führen. Installation, Wartung und Ausbau eines Switch, einer Grundplatte oder einer seiner Komponenten dürfen nur von geschultem und qualifiziertem Servicepersonal durchgeführt werden! Geschulte und...
- Page 29 Die Nichtbeachtung dieser Anweisungen kann zu Schäden an der Ausrüstung oder sogar zu einem Verstoß gegen die erforderlichen Sicherheitsbestimmungen und EMV-Vorschriften führen. Die Abdeckung der Grundplatte darf nur durch Personal von Extreme Networks entfernt werden. ● Das System enthält keine vom Kunden zu wartenden Komponenten. Reparaturen am System sind von einem Extreme Networks Servicetechniker durchzuführen.
- Page 30 Safety Information Verlegen von Kabeln: Kabel so verlegen, dass keine Schäden entstehen oder Unfälle, z. B. durch ● Stolpern, verursacht werden können. Bei einer Installation in einem Gestell darauf achten, dass schwere Geräte unten im Gestell eingebaut ● werden, um Gefahren durch Umkippen zu vermeiden. Austauschen und Entsorgen von Batterien Austauschen der Lithium-Batterie: Die Batterie kann nicht vom Anwender ausgetauscht werden.
-
Page 31: Appendix B: Technical Specifications
Technical Specifications This appendix includes the following sections: Specifications on page 31 ● FCC Class A Notice on page 33 ● ICES-003 Class A Notice on page 34 ● Specifications Table 2 provides technical specifications for the Sentriant NG appliance. Table 2: Sentriant NG Appliance Technical Specifications Physical Specifications Chassis dimensions... - Page 32 Technical Specifications Table 2: Sentriant NG Appliance Technical Specifications (Continued) EMI/EMC Standards North American EMC for ITE European EMC for ITE International EMC for ITE Country-specific Environmental Specifications Standards Operating conditions FCC 47 CFR Part 15, Subpart B, Class A (see page ICES-003, Class A (see “ICES-003 Class A Notice”...
-
Page 33: Fcc Class A Notice
Resolve Radio/TV Interference Problems helpful. This booklet was prepared by the Federal Communications Commission. It is available from the U.S. Government Printing Office. Washington, DC 20402, Stock Number 004-000-00345-4. The party responsible for product compliance: Extreme Networks 3585 Monroe Street Santa Clara Ca 95051 USA WARNING! Provided with this product is a detachable power supply cord with IEC320 style terminations for use in the US. -
Page 34: Ices-003 Class A Notice
Technical Specifications ICES-003 Class A Notice This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Sentriant NG Installation Guide... -
Page 35: Index
9 End User License Agreement screen, 19 environmental requirements, 9 environmental specifications, 32 ESD protection, 26 Extreme Networks website, 23 FCC Class A notice, 33 front panel, 7 German safety information, 28 Sentriant NG Installation Guide Host IP Configuration screen, 20... - Page 36 Index console, 7 detection/mitigation, 7, 14 I/O, 7 management, 7, 14 serial, 14, 17 power connecting, 13 turning on, 18 power connector, 8 power cord selection, 25 power safety, 25 power specifications, 31 power switch, 8 pre-setup requirements, 17 rack installation procedure, 13 safety notices, 11 rack ventilation, 9...
