- Page 1 © 2020 RE-1050 10’x10’ Hybrid Display 10’ 10’ Plan View Perspective View SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
- Page 2 © 2020 General Information General Setup Instructions - Read entire setup instruction manual prior to WARNING unpacking parts and pieces. - The setup instructions are created specifically for this configuration. - Setup instructions are laid out sequentially in steps, including exploded views with detailed explanation for assembly.
- Page 3 © 2020 SEG Graphic Installation Graphic Removal Corner A Corner B Corner D Corner C Step 1 Step 2 Step 3 It is important to first insert To remove the graphic from Insert corner A. Turn edge of Repeat Step 1 for opposite Once all corners are inserted, graphic into each alternate the frame, locate the fabric...
- Page 4 © 2020 CEI110 Frame Assembly Corner Connection Corner Bracket Assembly 1) Slide TWO-PIECE TS RV 2 L-bracket into Upper Interior Center Slot of extrusion so that two Horizontal set screws are inside groove. Tighten two set screws to secure. Upper Slide verticals over Horizontal 2) Slide one...
- Page 5 © 2020 RE-1050 10’x10’ Hybrid Display Item Qty. Description Base Plate 2/2A 56” CEI110 Horizontal Extrusion 3/3A 56” CEI110 Horizontal Extrusion 4/4A 95” CEI110 Vertical Extrusion 5/5A 95” CEI110 Vertical Extrusion Steps: Completed Assembly 1) Assemble extrusions [2] thru [5A] as shown.
