  • Page 1 User Guide PS27QHDCR 27” QHD Color LCD Monitor...
  • Page 2 Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/en/support Visit us at the web: www.barco.com Printed in Italy...

  • Page 3: Table Of Contents

    Technical specifications ..................33 K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 4 Table of contents K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 5: Welcome

    1. Welcome! 1. WELCOME! Introduction The PS27QHDCR monitor is a 27” color LCD monitor to be used in a system for diagnostic and interven- tional X-ray applications. Type of equipment: movable (on a table) Intended location: outside of patient area (e.g. Control Rooms)
  • Page 6 DVI 1 Single Link input (Not used, covered by 100 - 240 VAC mains power input (IEC C14) plastic dust protection) DisplayPort 1.1 input DVI 2 Dual Link input +5 VDC, 500 mA power output USB-B 2.0 upstream connector USB-A 2.0 downstream connector K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 7: Monitor Installation

    AWG18 size (according to national Regulation re- quirements regarding maximum admitted cable length). Use the included M4 screw to attach the wire to the protective earth pin. Image 2-2 K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 8 1. Slide the 4 position clips on top of the cable cover in the matching fixation holes at the back of the monitor. 2. Attach the cable cover by pushing the bottom into the monitor until you hear a “click” sound at both ends of the cover. K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 9: Stand Installation By Vesa Interface

    Image 2-6 Stand installation by VESA interface About The PS27QHDCR monitor is provided with a validated stand. If a different stand is needed in the final application, the monitor VESA interface (VESA 100 mm standard) could be used. ARNING If a different stand will be used, it has to be validated in the final application.
  • Page 10 6 mm and that the unthreaded distance to the outer surface of the plastic back cover is 7.8 mm. Image 2-9 K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 11: Daily Operation

    3. Daily operation 3. DAILY OPERATION On/Off switching About The PS27QHDCR monitor automatically turns on as soon as the power cord is connected to the mains plug. The monitor requires at maximum 30 seconds to power-up. Status LED About During start-up, the monitor performs a self-test and sync-test before going into normal operation mode.

  • Page 12: Brightness Adjustment

    When brightness is at 100%, by keeping the Up / Brightness increase key ( ) pressed for at least 3 seconds, the brightness is forced to the MAX brightness mode, which adds up 20 cd/m² to the default stabilized brightness value. Press the Menu / Enter key ( ) to exit the MAX brightness mode. K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 13: Advanced Operation

    4. Advanced operation 4. ADVANCED OPERATION OSD menu structure Below is an overview of the PS27QHDCR OSD menu structure. Detailed info about the different menus and settings is available in the next sections. Info Settings Model: PSXXXHDXR OSD Position Serial Number...

  • Page 14: Monitor Info

    1. Bring up the OSD main menu. 2. Navigate to the Image > Source menu. 3. Select one of the available input image sources. Source DVI2 Info Aspect Ratio Full Screen Color Temperature Calibrated Display Function Native Image Settings Image 4-3 K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 15: Aspect Ratio

    Calibrated: Corresponds to a color temperature of 6800 Kelvin (D68). To select a color temperature 1. Bring up the OSD main menu. 2. Navigate to the Image > Color Temperature menu. 3. Select one of the available color temperature settings. K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 16: Display Function

    1. Bring up the OSD main menu. 2. Navigate to the Image > Display function menu. 3. Select one of the available display functions. Source DVI2 Info Aspect Ratio Full Screen Color Temperature Calibrated Display Function Native Image Settings Image 4-6 K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 17: Osd Menu Position

    2. Navigate to the Settings > OSD Timeout menu. 3. Select one of the available time-out values. OSD Position Center Info OSD Timeout 240 sec. OSD Lock Factory Reset Image DVI1 5V DVI2 5V Settings 5V Output Back Illumination Image 4-8 K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 18: Osd Lock

    OSD menu time-out: 15 sec. • OSD lock: On • Power (5V) over DVI1: Off • Power (5V) over DVI2: PIN 14 ON • +5 VDC power output: On • Back illumination: On Brightness setting: 100% K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 19: Power Over Dvi

    2. Navigate to the Settings > DVI1 5V or DVI2 5V menu. 3. Select one of the available options. OSD Position Center Info OSD Timeout 240 sec. OSD Lock Factory Reset Image DVI1 5V DVI2 5V Settings 5V Output Back Illumination Image 4-11 K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 20: Vdc Power Output

    OSD menu. To enable/disable the back illumination 1. Bring up the OSD main menu. 2. Navigate to the Settings > Back illumination menu. 3. Select On to enable or Off to disable the back illumination. K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 21 4. Advanced operation OSD Position Center Info OSD Timeout 240 sec. OSD Lock Factory Reset Image DVI1 5V DVI2 5V Settings 5V Output Back Illumination Image 4-14 K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 22 4. Advanced operation K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 23: Cleaning Your Display

    LCD. AUTION Do not apply or spray liquid directly to the display as excess liquid may cause damage to internal electronics. Instead, apply the liquid to a cleaning cloth. K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 24 5. Cleaning your display K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 25: Important Information

    Power requirements: The equipment must be powered by the AC mains voltage. • The equipment is intended for continuous operation. Transient over-voltage To fully disengage the power to the device, please disconnect the power cord from the AC inlet. K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 26 IEC 62471: 2006; EN 62471: 2008 (Photobiological Safety Of Lamps And Lamp System) FCC class B ICES-001 Level B RoHS (2011/65/EC) National Scandinavian Deviations for CL. 1.7.2: Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan" Norway: "Apparatet må tilkoples jordet stikkontakt" Sweden: "Apparaten skall anslutas till jordat uttag" K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 27: Environmental Information

    Electronic Information Products”. 零件项目(名称) 有毒有害物质或元素 Component name Hazardous substances and elements 铅 镉 汞 六价铬 多溴联苯 多溴二苯 醚 Cr6+ PBDE 印制电路配件 Printed Circuit Assemblies 液晶面板 LCD panel 外接电(线)缆 External Cables 內部线路 Internal wiring 金属外壳 Metal enclosure K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 28: Biological Hazard And Returns

    However, normal use shall exclude biological contaminated environments, to prevent spreading of infec- tions. K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 29: Regulatory Information

    Regulatory information Indications for use The PS27QHDCR is intended to be used as a tool in displaying and viewing digital images (excluding digital mammography) for review and analysis by trained medical practitioners. Caution (USA): Federal law restricts this device to sale by or on the order of a physician. (Details & exemptions are in the Code of Federal Regulations Title 21, 801 Part D).
  • Page 30 Consult the dealer or an experienced technician for help. Electromagnetic immunity The PS27QHDCR is intended for use in the electromagnetic environment specified below. The customer or the user of the PS27QHDCR should assure that it is used in such an environment. Immunity test IEC 60601-1-2...
  • Page 31 150 kHz to 80 MHz equipment should be Radiated RF 3 V/m 3 V/m used no closer to any part of the PS27QHDCR, IEC 61000-4-3 80 MHz to 2.5 GHz including cables, than the recommended separation distance calculated from the...
  • Page 32 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the PS27QHDCR is used exceeds the applicable RF compliance level above, the PS27QHDCR should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the PS27QHDCR.

  • Page 33: Explanation Of Symbols

    Indicates the device is approved according to the KC regulations Indicates the device is approved according to the BSMI regulations Indicates the USB connectors on the device Indicates the DisplayPort connectors on the device Indicates the legal manufacturer K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 34 European WEEE (Waste Electrical and Electronic Equipment) directive Indicates Direct Current (DC) Indicates Alternating Current (AC) Stand-by Equipotentiality Protective earth (ground) 5. Values for xx and yy can be found in the technical specifications paragraph. K5902097 (451920611672) PS27QHDCR 22/05/2015...

  • Page 35: Legal Disclaimer

    1 x DVI Single Link (Not used, covered by plastic dust protection) 1 x DisplayPort 1.1 USB ports 1 x upstream, 3 x downstream (USB 2.0) Power requirements (nominal) 100-240V (50-60 Hz) Power consumption < 120W (maximum) K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 36 10°C to 40°C (10°C to 35°C within specs) Storage temperature -20°C to 60°C Operating humidity 20% - 80% (non-condensing) Storage humidity 10% - 90% (non-condensing) Operation altitude 0 - 3000 m Storage altitude 0 - 3000 m K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 37 6. Important information Dimensions 648.5 mm 91.3 mm 596.7 mm Image 6-1 K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 38 6. Important information 203.0 mm 222.9 mm Image 6-2 274.3 mm 100.0 mm Image 6-3 Identification label position The product identification label is located at the back of the monitor under the cable cover as illustrated below. K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 39 6. Important information MAINS USB-B USB-A Image 6-4 K5902097 (451920611672) PS27QHDCR 22/05/2015...
  • Page 44 K5902097-01 (451920611672) May 2015 FIMI S.r.l. Saronno - Italy Barco n.v. President Kennedypark 35 8500 Kortrijk Belgium www.barco.com...
