sisel Enda EDT5411A Quick Start Manual

Please read this document carefully before using this product. The guarantee will be invalidated if the device is
damaged by not following instructions detailed in the manual. The company shall not be responsible for any damage
or losses however caused, which may be experienced as a result of the installation or use of this product.
ENDA EDT5411A DIGITAL THERMOSTAT
Thank you for choosing ENDA EDT5411A temperature controller.
54x94mm.
On-Off control.
Relay output for cooling or heating control.
Single NTC probe input.
Offset value can be entered for NTC input.
Compressor protection parameters can be entered.
In case of probe failure, output status can be set to
ON, OFF or periodic.
Upper and Lower setpoint value limits can be adjusted.
Defrosting duration and intervals can be adjusted.
6 Different warning tone selections.
Lower and upper alarm limit can be adjusted to depending
on set value.
Temperature unit can be selected °C or °F.
Digital input ;
- External alarm
- Initiate defrost
Transfer device parameter settings with ENDAKEY
- No power-up required.
RS485 ModBus protocol communication feature (optional).
CE marked according to European Norms.
Order Code : EDT5411A - - -
3
1 2
2-Output
1 - Supply Voltage
R......... 8A Relay output
230........230V AC
P......... 20A Relay output
110.........110V AC
24........24V AC/DC
CONNECTION DIAGRAM
12........12V AC/DC
SM........9-30VDC / 7-24V AC
ENDA EDT5411A is intended for installation in control panels. Make sure that the device is used
only for intended purpose. The electrical connections must be carried out by a qualified staff
and must be according to the relevant locally applicable regulations. During an installation, all of the cables that are
connected to the device must be free of electrical power. The device must be protected against inadmissible humidity,
vibrations, severe soiling and make sure that the operation temperature is not exceeded. The cables should not be
close to the power cables or components.
Please see page 4 for
Modbus Connection Diagram
Holding screw
0.4-0.5Nm
Equipment is protected throughout
by DOUBLE INSULATION.
NOTE:
Fuse
SUPPLY:
F 100 mA
Switch
250V AC
10
Line
184-253V AC
50/60Hz 4VA
11
Neutral
Fuse should
be connected
CAL
EDT5411A
3 - Modbus
RS........ RS-485 Modbus Available
(Optional / Specify at order)
Blank.... N/A
ENDA ENDA
INDUSTRIAL ELECTRONICS
EDT5411A-230-R-RS EDT5411A-230-P-RS
DIGITAL THERMOSTAT DIGITAL THERMOSTAT
8 680407 719259 8 680407 719419
230V AC +10% -20%
230V AC +10% -20%
50/60Hz 5VA
50/60Hz 5VA NTC
GND
COMPRESSOR
COM
250V AC 8A
RESISTIVE LOAD
B
COMPRESSOR
250V AC 20A
A
RESISTIVE LOAD
GND
Made in Turkey
DIG INP
SN: XXXXXXXXX
Note:
1) Mains supply cords shall meet the requirements of
IEC 60227 or IEC 60245.
230V AC
2) In accordance with the safety regulations, the power
Supply
supply switch shall bring the identification of the
relevant instrument and it should be easily
Cable size: 1,5mm²
accessible by the operator.
ENVIRONMENTAL CONDITIONS
Ambient / Storage Temperature
Relative Humidity
Protection Class
Height
KEEP AWAY device from exposed to corrosive, volatile and flammable gases or
liquids and DO NOT USE the device in similar hazardous locations.
ELECTRICAL CHARACTERISTICS
1 2 3 4 5 6 7 8 9
Supply Voltage
Power Consumption
Connection
Scale
Sensitivity
°F
°C
Accuracy
Time Accuracy
Display
EMC
Safety Requirements
ENDA
SET
EDT5411A
OUTPUTS
Relay Output
11 12 13
10 14 15 16 17 18
Life Expectancy for Relay
CONTROL
Control Type
Control Algorithm
Hysteresis
HOUSING
Housing Type
Dimensions
Weight
Enclosure Material
Avoid any liquid contact when the device is switched on.
DO NOT clean the device with solvent (thinner, gasoline, acid etc.) and / or abrasive cleaning agents.
DIMENSIONS
INDUSTRIAL ELECTRONICS
NTC
GND
COM
B
A
GND
Made in Turkey
DIG INP
SN: XXXXXXXXX
1/4
0 ... +50°C/-25 ... 70°C (without icing)
Max. humidity 80% for temperatures up to 31°C decreasing linearly to
50% relative humidity at 40°C.
According to EN60529; Front panel : IP65, Rear panel : IP20
Max. 2000m
230V AC / 110V AC +%10 -%20 50/60Hz ; 12V AC/DC ± %10 ,24V AC/DC ±%10 or 9-30V DC / 7-24V AC SMPS.
Max. 5VA
2.5mm² screw-terminal connections
-60.0 ... +150.0°C (-76.0 ... +302.0°F)
0.1°C (Can be selected as 0.1ºC or 1ºC.)
±1°C
±1%
4 Digits, 12.5mm, 7 Segment Red LED
EN 61326-1: 2013
EN 61010-1: 2010 (Pollution degree 2, overvoltage category II)
For EDT5411A-X-R ; Relay : NO+NC 250V AC,8A (resistive load),
1/2HP, 0.37KW 240V AC (inductive load)
For EDT5411A-X-P ; Relay : NO 277V AC,20A
1/2HP, 0.37KW 250V AC (inductive load)
For EDT5411A-X-R ; Without load 30.000.000 mechanical;
250V AC, 8A resistive load 100.000 electrical operation.
For EDT5411A-X-P ; Without load 10.000.000 switching;
277V AC,20A (for resistive load) 100.000 electrical operation.
Single set-point control
On-Off control
Adjustable between 1 ... 20.0 °C.
Suitable for flush -panel mounting
W54xH94xD68mm
Approx. 190g (After packing)
Self extinguishing plastics.
3 3
2
2
1 1
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Barbaros Cad. No:18 Y.Dudullu 34775
ÜMRANİYE/İSTANBUL-TURKEY
Tel : +90 216 499 46 64 Pbx. Fax : +90 216 365 74 01
url : www.enda.com.tr
(resistive load),
To mounting the device to the panel ;
1
Push the device in direction 1 , the rails
provide the key to keeping the rail.
To removing the device from rail ;
Push the rail lock in direction 2 with a
2
screwdriver and pull the device in
direction 3 . 3
ENDA TM
EDT5411-EN-01-191216
