AV32X10EUS
AV28X10EUS
AV28X10EKS
AV28X10EIS

SPECIFICATIONS

Item
Dimensions ( W× × × × H× × × × D )
Mass
TV RF System
Colour System
Stereo System
Teletext System
Receiving Frequency
Intermediate Frequency
Colour Sub Carrier Freq.
Power Input
Power Consumption
Aerial Input Term
Picture Tube
High Voltage
Speaker
Audio Output
EXT-1/EXT-2/EXT-3 (IN/OUT)
EXT-4 (Input)
AUDIO OUT (Variable)
Headphone jack
Remote Control Unit
Design & specifications are subject to change without notice
2
AV32X10EUS / AV28X10EUS
(32") : 85.5cm × 55.0cm × 56.8cm
(28") : 78.0cm × 50.9cm × 49.9cm
(32") : 54.2kg / (28") : 40.2kg
CCIR ( B/G, D/K, L, L',I)
PAL / SECAM / NTSC (Only in EXT mode)
A2 (B/G, D/K) / NICAM (B/G, I, D/K, L)
Fastext (UK system) / TOP (German system)
WST(world standard system)
VHF : 47MHz ～ 470MHz
UHF : 470MHz ～ 862MHz
! French cable TV channel of broadcast frequencies
116 ～ 172MHz & 220 ～ 469MHz
VIF Carrier : 38.9MHz(B/G, D/K, I, L) / 33.95MHz (L')
SIF Carrier : 33.4MHz(5.5MHz : B/G)
32.9MHz(6.0MHz : I )
32.4MHz(6.5MHz : L, D/K)
40.45MHz (6.5MHz : L')
PAL : 4.43MHz
SECAM : 4.40625MHz / 4.25MHz
NTSC : 3.58MHz / 4.43MHz
AC 220V ～ 240V , 50Hz
189W(Max) 183W(Max)
(32") (28")
140W(Avg) 127W(Avg)
75 Ω unbalanced, Coaxial
(32") : Viewable area 76cm ( measured diagonally)
(28") : Viewable area 66cm ( measured diagonally)
+
1.0kV
31.0kV (at zero beam current)
-1.5kV
16cm × 4cm, Oval type × 2
7.5W + 7.5W
21-pin Euro connector (SCART socket) × 3
Video : Vp-p 75 Ω (RCA pin jack)
Audio(L/R) : 500mVrms(-4dBs), High Impedance (RCA pin jack)
Y : 1Vp-p POSITIVE (Negative sync Provided, when terminated with 75 Ω )
S / Video
C : 0.3Vp-p (Burst signal, when terminated with 75 Ω )
0 ～ 1Vrms, Low Impedance (RCA pin jack × 2)
Stereo mini jack ( φ 3.5mm )
RM-C54 (AAA/R03 dry cell battery × 2)
No.51780
Content
AV28X10EKS / AV28X10EIS
78.0cm × 50.9cm × 49.9cm
40.2kg
CCIR ( I )
PAL / NTSC (Only in EXT mode)
NICAM ( I )
Fastext (UK system)
WST(world standard system)
VHF : 47MHz ～ 470MHz ( EI model )
UHF : 470MHz ～ 862MHz ( EK / EI model )
VIF Carrier : 38.9MHz
SIF Carrier : 32.9MHz (6.0MHz )
PAL : 4.43MHz
NTSC : 3.58MHz / 4.43MHz
183W(Max) , 127W(Avg)
Viewable area 66cm ( measured diagonally)
RM-C55 (AAA/R03 dry cell battery × 2)
.
