Everex StepNote XT5000T Specifications

Everex recommends Windows Vista™ Home Premium
®
Everex StepNote XT5000T Detailed Product Specification
StepNote XT5000T, Genuine Windows Vista™ Home Premium, AMD Turion™ 64 X2 Dual-Core Mobile Technology TL-50, 1GB DDR2 SDRAM, 100GB SATA HDD, DVD-
ROM/DVD+/-RW with Double Layer support, 17" WXGA+ Widescreen Display with DiamondBrite Technology, NVIDIA
standard limited warranty, UPC: 853031001436

Operating System

• Genuine Windows Vista™ Home Premium
Processor
• AMD Turion™ 64 X2 Dual-Core Mobile Technology TL-50
(512KB L2 Cache, 1.6GHz)
Chipset
• Northbridge: NVIDIA C51D
• Southbridge: NVIDIA MCP51
Memory
• Configured with 1GB DDR2 533MHz SDRAM
• Total Slots: 2 SO-DIMM
• Maximum Capacity: 4GB
Hard Disk Drive
• Configured with 1 100GB Hard Disk Drive
•
Bus: Serial-ATA (SATA-150)
• Rotation: 5400RPM
• Height: 9.5mm
• Total Available HDD Slots: 2, with RAID 0/1 options
(additional settings and software may be required)

Optical Disk Drive

• DVD-ROM/DVD+/-RW with Double Layer support
(Maximum speed and compatibility: 4X DVD+R DL, 4X
DVD-R DL, 6X DVD-RW, 8X DVD+RW, 8X DVD+R, 8X
DVD-R, 8X DVD-ROM, 16X CD-RW, 24X CD-R, 24X CD-
ROM)
Display
• 17" Diagonal WXGA Widescreen Display with DiamondBrite
Technology
• TFT Active Matrix LCD
• Native Resolution: 1440 x 900
Graphics
® ®
• NVIDIA GeForce Go 7600
• Windows Vista™ Aero Glass support
• Memory: 256MB DDR2 Dedicated Video Memory
Sound
• Built-in Stereo Speakers (2 2W) with Subwoofer (3W)
• Built-in Array Microphone
• Realtek ALC885 High-Definition Audio Codec with S/PDIF
and 7.1 channel audio support
(Analog: 24-Bits Max Resolution, 192kHz Max Sampling;
Digital: 24-Bits Max Resolution, 192kHz Max Sampling)

Input Devices

• 104-key US keyboard with Hot Keys Functions and
Dedicated Numeric Keypad
• Touchpad Pointing Device with Integrated Vertical and
Horizontal Scroll Functions
Copyright 2007. Everex and the Everex logo are trademarks of Everex Systems, Inc. All other company and product names may be trademarks of their respective companies. All specifications are subject to change without notice.
Everex StepNote XT5000T Detailed Specification-v1.0, 1/5/2007 2:32:00 PM
®
®
®
GeForce
Communications
• Soft Data Fax Modem with SmartCP
(V.92, 56kbps, actual speeds may vary)
• ® ®
NVIDIA nForce Networking Controller
(10/100/1000 Base-TX Ethernet)
• Atheros AR5005G Wireless Network Adapter 802.11b/g
Expandability
• 1 ExpressCard 54 (Also fits ExpressCard 34)
• 4-in-1 Media Card Reader
(Secure Digital, Multi Media Card, Memory Stick, Memory
Stick PRO)
Ports
• Video: 1 DVI-I output port, 1 S-Video output port
• Audio: 1 Microphone input port, 1 Headphone output port,
1 S/PDIF output port (shared with Headphone)
• Data: 1 IEEE1394 (4-pin), 3 USB 2.0 ports, 1 RJ-45 LAN
port, 1 RJ-11 Modem port
System Physical Description
• Dimensions: 15.71" (399mm) x 11.77" (299mm) x 1.3"
(33mm) front ~ 1.56" (39.5mm) rear (L x W x H)
• Weight: 8.14lbs (3.7kg) when equipped with 1 HDD
• Indicators: Power, Battery Status, Silent/Turbo Status,
HDD/ODD Status, Touchpad Status, WLAN Status, Caps
Lock Status, Num Lock Status, Scroll Lock Status
• Switches/Hotkeys: Power, Internet Browser, Silent/Turbo,
Mail, Media Player, WLAN, Audio Volume Control (Built-in
Speakers only)
• Physical Security: Provision for Kensington Lock
AC Adapter
• 90W (20V@4.5A) Auto sensing external AC Adapter (100-
240V~1.5A; 50-60Hz)
• Dimensions: 5.16" (131mm) x 2.2" (56mm) x 1.18" (30mm)
(L x W x H)
• Weight: 0.86lb (0.39kg)
• 2-Prong US Power Cord
Battery
• 6-Cell (11.1V, 4400mAh) rechargeable, removable Lithium-
Ion Battery
• Dimensions: 8.11" (206mm) x 1.97" (50mm) x 0.83"
(21mm) (L x W x H)
• Weight: 0.73lb (0.33kg)

Preinstalled Software

• CyberLink DVD Suite
• Norton Internet Security™ 2007
®
Go 7600, WLAN 802.11b/g, 1-year
Page 1 of 1
