Everex recommends Windows Vista™ Home Premium
®
Everex StepNote
VA4103M Detailed Product Specification
StepNote VA4103M, Genuine Windows Vista™ Home Basic, Intel
Layer support, 15.4" WXGA Widescreen Display with DiamondBrite Technology, VIA Chome9™ HC IGP, WLAN 802.11b/g, 1-year standard limited warranty, UPC:
853031001474
Operating System
•
Genuine Windows Vista™ Home Basic
Processor
®
®
•
Intel
Celeron
M Processor 410
(1MB L2 Cache, 1.6GHz, 533MHz)
Chipset
•
Northbridge: VIA VN896
•
Southbridge: VIA VT8237A
Memory
•
Configured with 512MB DDR2 533MHz SDRAM
•
Total Slots: 2 SO-DIMM
•
Maximum Capacity: 2GB
Hard Disk Drive
•
Size: 60GB
•
Bus: Serial-ATA (SATA-150)
•
Rotation: 5400RPM
•
Height: 9.5mm
Optical Disk Drive
•
DVD-ROM/DVD+/-RW with Double Layer support
(Maximum speed and compatibility: 4X DVD+R DL,
4X DVD-R DL, 6X DVD-RW, 8X DVD+RW, 8X
DVD+R, 8X DVD-R, 8X DVD-ROM, 24X CD-RW, 24X
CD-R, 24X CD-ROM)
Display
•
15.4" Diagonal WXGA Widescreen Display with
DiamondBrite Technology
•
TFT Active Matrix LCD
•
Native Resolution: 1280 x 800
Graphics
•
VIA Chrome9™ HC IGP
•
DirectX 9.0 Support
•
Memory: 64MB shared (default); 128MB Maximum
shared memory
Sound
•
Built-in Speaker
•
VIA VT1708A Vinyl High-Definition Audio Codec
(Analog: 24-Bits Max Resolution, 192kHz Max
Sampling; Digital: 24-Bits Max Resolution, 96kHz
Max Sampling)
Input Devices
•
86-key US keyboard with Hot Keys Functions
•
Touchpad Pointing Device with Integrated Vertical
and Horizontal Scroll Functions
Copyright 2006. Everex and the Everex logo are trademarks of Everex Systems, Inc. All other company and product names may be trademarks of their respective companies. All specifications are subject to change without notice.
Everex StepNote VA4103M Detailed Specification-v1.0, 12/27/2006 3:42:00 PM
®
®
Celeron
M Processor 410, 512MB DDR2 SDRAM, 60GB SATA HDD, DVD-ROM/DVD+/-RW with Double
Communications
•
•
•
Expandability
•
Ports
•
•
•
System Physical Description
•
•
•
•
•
AC Adapter
•
•
•
Battery
•
•
•
Preinstalled Software
•
•
Soft Data Fax Modem with SmartCP
(V.92, 56kbps, actual speeds may vary)
VIA VT6103L Rhine II Fast Ethernet Adapter
(10/100 Base-TX Ethernet)
Atheros AR5005G Wireless Network Adapter
802.11b/g
N/A
Video: 1 VGA output port
Audio: 1 Microphone input port; 1 Headphone
output port
Data: 3 USB 2.0 ports; RJ-45 LAN port; RJ-11
Modem port
Dimensions: 14.06" (357mm) x 10.67" (271mm) x
1.02" (26mm) front ~ 1.54" (39mm) rear (L x W x H)
Weight: Starting at 5.3lbs (2.41kg) depending upon
configuration
Indicators: Power, Battery Status, HDD/ODD Status,
WLAN Status, Caps Lock Status, Scroll Lock Status,
Num Lock Status
Physical Security: Provision for Kensington Lock
Software Security: Fixed Disk Boot Sector Protection,
Password on Boot
65W (20V@3.25A) Auto sensing external AC
Adapter (100-240V~1.5A; 50-60Hz)
Dimensions: 4.25" (107mm) x 1.75" (44.45mm) x
1.13" (28.70mm) (L x W x H)
Weight: 0.7lb (0.32kg)
6-Cell (11.1V, 4400mAh) rechargeable, removable
Lithium-Ion Battery
Dimensions: 8.15" (207mm) x 1.57" (40mm) x 0.79"
(20mm) (L x W x H)
Weight: 0.7lb (0.32kg)
CyberLink DVD Suite
Norton Internet Security™ 2007
Page 1 of 1
