Summary of Contents for Everex StepNote SA2050T

  • Page 2: Table Of Contents

    Table of Contents Table of Contents CHAPTER 1 ...1 ...1 NTRODUCTION Getting Started ...2 Inventory...3 Safety and Maintenance...4 Checklists ...5 Features ...6 Where to Look For Information ...7 Quick Start...8 Loading Windows ...9 Adjusting the Volume ... Error! Bookmark not defined. Adjusting the Brightness...
  • Page 3 Right Side Connectors ...36 Front Side Connectors ...37 Back Side Connectors...38 CHAPTER 4 ...39 ...39 OWER ANAGEMENT Power Management ...40 Monitoring Battery Power ...41 Power Saving Modes ...42 Power Saving Tips ...43 When to Replace the Battery ...44 Heat Considerations...44 CHAPTER 5 ...45 BIOS S SING THE...
  • Page 6: Getting Started

    Chapter 1 Getting Started Congratulations on your decision to purchase an Everex® computer! Your new notebook features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with sophisticated architecture to provide you with a personal computer that is compact, powerful, and easy to use.
  • Page 7: Inventory

    Inventory This computer system is designed for years of productive and pleasurable computing. Use this section to keep details of your purchase. This information will be required should you need to make repairs to your notebook during the warranty period. Update this section when you add new options.
  • Page 8: Safety And Maintenance

    Chapter 1 Safety and Maintenance You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: • Follow all warnings and instructions noted in this documentation and in the Windows Help program.
  • Page 9: Checklists

    • Set the computer on a flat, stable surface. To prevent damage to the computer’s hard disk drive, avoid using the computer where it will be exposed to strong vibration. Checklists After opening the package, carefully inspect the contents. If any of the items is missing or appear damaged, contact your dealer.
  • Page 10: Features

    Chapter 1 Features High Capacity Hard Disk Drive The computer has a high capacity hard disk drive, to store your favorite programs and large multimedia files. Built-in Modem/LAN Capability A built-in 56k modem and 10/100 Mbps Ethernet port allows you to access the Internet or a local area network (LAN).
  • Page 11: Where To Look For Information

    Chapter 1 Where to Look For Information About Your Computer This User’s Manual describes the key elements of your computer. New users can find a simple step-by-step orientation in the Quick Start section of this chapter. About Windows Windows Online Help, found on the Start menu, offers extensive Windows assistance.
  • Page 12: Quick Start

    Chapter 1 Quick Start Turning on the Computer for the First Time 1. Connect the AC adapter power cord to the AC adapter. 2. Connect the AC adapter to the DC power port on the right side of your computer. 3.
  • Page 13: Loading Windows

    Loading Windows The following section is for installing the Windows operating system only. If you are installing a different operating system, please check with your vendor for installation details. Your computer will begin loading Windows once you turn on the power. Wait a few seconds for Windows setup to load.
  • Page 14: Adjusting The Volume

    Chapter 1 Adjusting the Volume You can adjust the volume with hot key combinations as below: • Fn + F8 decreases the volume • Fn + F9 increases the volume • Fn + F10 Mute the volume Alternatively, you can adjust the volume with the Windows volume control applet located on the taskbar.
  • Page 15: Turning Off Your Computer

    Turning off Your Computer Turning off the computer properly is important to maintaining your computer. On the Start menu, click the button Shut Down in the Windows screen. If you are going to be away from the computer for a short period, there are ways of conserving power without shutting down the system.
  • Page 16: Tips For New Owners

    Chapter 1 Tips for New Owners Take responsibility for backup Back up files often. Users who need to manage large amounts of data may wish to use backup devices such USB drive. If you use your notebook as a networked workstation with system backup, talk to the system administrator about backup procedures for your notebook.
  • Page 17 Never take the notebook anywhere without the carrying case A broken screen or case can be costly to repair. Prevent accidents by carrying the computer in a suitable carrying case. Consider using a lock For added security, consider purchasing a Kensington lock to put into the Kensington lock hole on the back side of your computer (see Chapter 2, back View).
  • Page 19: Getting Started

    Chapter 2 Hardware and Software This chapter introduces the different components and controls of your notebook computer, including the hardware components, the software, and the audio and video systems. Getting Started Before you begin using your computer, read this chapter to familiarize yourself with the main components installed in the system.
  • Page 20: Front View

    Chapter 2 Front View 1. LCD panel 2. Power button 3. Keyboard 4. Status indicators 5. Touchpad 6. Touchpad buttons 7. Wireless LAN switch 8. Media Player button (N/A for SA2050T) 9. Microphone-in jack 10. Audio-out jack for external speakers or headphones 11.
  • Page 21: Left View

    Chapter 2 Left View 1. Kensington lock hole 2. DC in jack 3. IEEE 1394 slot 4. Optical drive 5. Optical drive button...
  • Page 22: Right View

    Chapter 2 Right View 1. USB ports 2. Express 34/54 card slot 3. VGA external video display port...
  • Page 23: Back View

    Chapter 2 Back View 1. Fax/modem RJ-11 jack 2. LAN RJ-45 jack...
  • Page 24: Bottom View

    Chapter 2 Bottom View 1. Ventilation slot 2. Battery release latch 3. Battery 4. Speakers...
  • Page 25: Led Status Indicators

    LED Status Indicators The status indicators in the upper left corner of the keyboard light up when a particular function of the computer is active. Each indicator is marked with a symbol. CD-ROM Drive Number-Lock Caps-Lock Power Indicators The power indicators show which power source the system is using. The power indicators remain active and viewable even when the LCD panel is closed.
  • Page 26: Function Keys

    Chapter 2 Function Keys Hold the Fn key while pressing the numbered function key. Function key Fn + F3 Fn + F4 Fn + F5 Fn + F6 Fn + F7 Fn + F8 Fn + F9 Fn + F10 Numeric Keypad The embedded numeric keypad consists of ten keys that make...
  • Page 27: Touchpad

    Touchpad The touchpad is a pressure sensitive pointing device that provides all the features of a two-button mouse. Its primary function is to move the cursor around the screen. Touchpad The instructions listed below describe how to use the touchpad. 1.
  • Page 28: Touchpad Precautions

    Chapter 2 5. Double-clicking is a common technique for selecting objects or launching programs from icons. Once you have moved the pointer over the object you wish to select, rapidly press the left button two times. This action is commonly referred to as “double- clicking”...
  • Page 29: The Optical Drive

    The Optical Drive Your computer comes with a pre-installed Optical drive. The optical drive can read or write both DVDs and CDs. Your notebook identifies the drive with the letter following the hard drive letter. If your hard drive is D, then the optical drive will be E. Inserting a Disk 1.
  • Page 30: Connecting The Printer

    Chapter 2 • Extremes in temperature may damage discs. Store discs in a cool dry place. • Do not use benzene, thinners, or cleaners with detergent. Only use optical cleaning kits. • Do not bend or drop the discs. • Do not place objects on top of discs.
  • Page 31: The Express Card Slot

    The Express Card Slot The express card slot can be used as an interface between your computer and a variety of communications devices, such as network adapters, SCSI adapters, fax/modems, or provide additional data storage capacity. Installing a Card 1. The top side of a express card is usually identified with a label.
  • Page 32 Chapter 2 Express Card Size Restrictions • The card will not able to eject if it is less the 75mm.
  • Page 33: The Graphics System

    The Graphics System Your computer has a high-performance graphics system, which can easily handle the demands of today's multimedia computing. Screen Controls Brightness Function keys can increase or decrease the brightness of the monitor. • <Fn> + <F6> decreases the LCD panel brightness •...
  • Page 34: Dual Displays

    Chapter 2 made in this dialog box. Dual Displays With Windows system, you may use an external monitor simultaneously with your notebook’s LCD. You may also use the external monitor only and disable the LCD or only use the LCD. To do this you may first need to enable the multiple display settings in Windows Vista.
  • Page 35 Chapter 2 Tip: To ensure trouble-free video output, the first time you use an external monitor, change the output in the Display Properties dialog box. After successfully switching modes, you may use the video function keys. Note: Light or dark dots may appear on the LCD due to technical limitations of LCD manufacturing.
  • Page 36: Communication Components

    Chapter 2 Communication Components This system provides powerful communication functions, including built-in Fax/Modem jack, LAN jack and Express card slot. Fax/Modem and LAN Fax/Modem and LAN jack on the left side of the computer allows you to connect to the Internet to send and receive data. When used with fax software, it can be used as a fax.
  • Page 37: Information About The Wireless Lan Button

    Information about the Wireless LAN button Wireless LAN button Even when a Wireless LAN module has not been built-in to your computer, the Wireless LAN indicator lights and remains active when you turn on the Wireless LAN button near the power button of your computer. If Wireless LAN module has been built-in, your notebook will search for the device and will display an icon on...
  • Page 39: Making Connections

    Making Connections Your computer is equipped with a full array of ports and connectors, including standard input/output (I/O) ports for quickly and easily adding peripheral devices such as printers, keyboards, and mice. Refer to documentation included with individual devices for details on connecting these devices to your computer.
  • Page 40: Right Side Connectors

    Chapter 3 5. Disk Eject Button Press the eject button to eject the disk tray. The manual eject keyhole is located next to it and allows you to manually eject a jammed disc. Right Side Connectors 1. USB 2.0(Universal Serial Bus) Ports The Universal Serial Bus (USB) is the latest standard for attaching monitors, input devices, scanners, and other devices to a PC.
  • Page 41: Front Side Connectors

    Front Side Connectors 1. Wireless LAN On/Off Build in wireless LAN card IEEE802.11A/B/G for user accessing the Internet without wire cable through by this switch On/Off. 2. Microphone-in Jack Connect a microphone to this jack to record. 3. Audio-out Jack Connect a stereo headset or external speakers to this jack to listen to multimedia.
  • Page 42: Back Side Connectors

    Chapter 3 Back Side Connectors 1. Fax/modem RJ-11 Jack The fax/modem can transmit data using the 56 Kbps V.90 protocol, and send and receive faxes at 14.4 Kbps. In some countries, local regulations may not permit the use of the fax/modem designed for this system.
  • Page 44: Power Management

    Power Management Battery Calibration The first time you use a battery, you should calibrate it. The calibration process empties and charges the battery one time. This allows the Windows battery gauge to accurately monitor battery status. To calibrate a battery, follow these steps: •...
  • Page 45: Monitoring Battery Power

    Chapter 5 Monitoring Battery Power The way to monitor how much power the battery has left. Click start/Control Panel/Mobile PC/Power Options; then click battery meter to Edit Plan Settings. Low Battery Alarms How your computer responds to a low battery condition is set under Start/Control Panel/Power Options/Alarms.
  • Page 46: Power Saving Modes

    If your computer is turned off or standby mode, a fully discharged battery will take about 3 hours to recharge. Note: A fully charged 6 cell battery can run the Notebook for approximately 3.5 hours. Power Saving Modes Adjust the default power management settings in the Power Options/ Advanced dialog box in the Control panel.
  • Page 47: Power Saving Tips

    Chapter 5 Power Saving Tips • Avoid operating the fax/modem, or audio and video applications when using battery power. Operating a fax modem, video, or audio equipment increases the computer's power requirements. • Decreasing monitor brightness can also save power. Decrease brightness by pushing <Fn>...
  • Page 48: When To Replace The Battery

    When to Replace the Battery Over time, the battery's capacity gradually decreases. We recommend that you replace your battery when you notice that it begins to store significantly less charge. Changing the Battery Change the main battery pack as follows: 1.
  • Page 50: Using The Bios Setup Utility

    Chapter 6 Using the BIOS Setup Utility Your notebook has a BIOS setup utility which allows you to configure important system settings, including settings for various optional functions of the computer. This chapter explains how to use the BIOS setup utility. BIOS Setup Menu The BIOS setup Utility allows you to configure your computer’s basic settings.
  • Page 51 Chapter 6 Navigating and Entering Information in BIOS Use the following keys to move between fields and to enter information: Select Screen Push the up and down arrow keys to move among selections, then press Enter to make a selection. Change Option Select Field General Help...
  • Page 52: The Main Menu

    The Main Menu BIOS SETUP UTILITY Main Advanced Boot Security Exit System Overview AMIBIOS Build Date: 05/09/06 Processor Type : Genuine Intel® CPU T2300@ Speed :1666MHz System Memory Size : 1016MB System Time [19:14:50] System Date [Thu 01/01/2006] V02.59 ©Copyright 1985-2005, American Megatrends , Inc. Figure 6-1 Use [ENTER] , [TAB] Or [SHIFT-TAB] to...
  • Page 53: Advanced Menu

    Chapter 6 Advanced Menu BIOS SETUP UTILITY Main Advanced Boot Security Advanced Setting Battery Calibration [ Enter ] Start FAN Calibration [ Enter ] Auto DIM function [ Enable] Legacy USB Support [ Auto ] V02.59 ©Copyright 1985-2005, American Megatrends , Inc. Figure 6-2 Exit Battery Learning Function...
  • Page 54: Boot Menu

    Boot menu BIOS SETUP UTILITY Main Advanced Boot Security Exit 1st Boot Device [CD/DVD: 3M-_NEC] Boot Device [SATA : PM-HTS541080G] 3rd Boot Device [Networking: Realtek Bo] V02.59 ©Copyright 1985-2005, American Megatrends , Inc. Figure 6-3 Specifies the boot sequence from the available devices.
  • Page 55: Security Menu

    Chapter 6 Security menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Security Settings Supervisor Password : Not Installed User Password : Not Installed Change Supervisor Password Change User Password V02.59 ©Copyright 1985-2005, American Megatrends , Inc. Figure 6-4 Install or Change the password. ←→...
  • Page 56: Exit Menu

    Exit menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Exit Options Save Changes and Exit Discard changes and Exit Discard Changes Load Optimal Defaults V02.59 ©Copyright 1985-2005, American Megatrends, Inc. Figure 6-5 Exit system setup after saving the changes. F10 key can be used for this operation.
  • Page 57 Chapter 6 Change User Password With a User password, you can enter the Setup Utility and change or remove the User password, but you cannot enter the Setup Utility and change or remove the Supervisor password, nor enable diskette access if it has been disabled. Change Supervisor Password A supervisor password must be set before a lower-level user password can be set.
  • Page 59: Frequently Asked Questions

    Frequently Asked Questions Q: My screen seems to time out too quickly. I have to constantly hit a key or move the mouse in order to bring it back. How can I adjust the screen time-out? This is part of Windows Power Management. Access Power Management by clicking on Start / Settings / Control Panel / Power Management.
  • Page 60 Appendix A Double click on the Speaker icon on the task bar. Then, under Microphone Balance, check the Mute box. Q: Because of a software problem, I was unable to shut down power normally. I pressed the power button to force a power off, but it didn't work.
  • Page 61 Appendix A Save configuration changes and exit setup? [OK] [Cancel]...
  • Page 63: Statements

    Statements Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 64: About The Modem

    Appendix B About The Modem This equipment complies with Part 68 of FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company.
  • Page 65: European Notice

    The Telephone Consumer Protection Act of 1991 marks it unlawful for any person to use a computer or other electronic device, including fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending...
  • Page 66: Ul Caution

    Appendix B In France, the equipment must be restricted to the 2.4465-2.4835GHz frequency range and must be restricted to indoor use." CE Declaration of Conformity Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC), Low- voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC), the procedures given in European Council Directive...
  • Page 67: Canadian Department Of Communications

    Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations.
  • Page 68: Battery Disposal

    Appendix B "The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop which is used by the device. To prevent overloading, the termination on a loop may consist of any combination of devise subject only to the requirement that the total of the Load Numbers of all the devices does not exceed 100."...
  • Page 69 Technical Support Information Information of the responsible party for a DoC product Product name: Notebook PC , Model number: SA 2052T Technical Support: Address: 6FL., No.300 Yang Gunag St., Neihu, Taipei, Taiwan Telephone:+886-2-8751-8751 ext.7935 Fax: +886-2-87518822 Emaill: rex_kuo@pcg.fic.com.tw Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Appendix B Technical Support in the US:...
  • Page 70: System Recovery & Driver Installation

    Appendix B System Recovery & Driver Installation Using Recovery Disk Before we go on, let’s define some terminologies. Hard disk is divided into RP & UP. RP - Recovery Partition, it stores system files and is hidden by default UP – User Partition, it can be divided into 2 parts (system files area + user data area) Users can choose to recover the system from either hard disk or recovery DVD(s)/CD(s).
  • Page 71 Appendix B 2. Please choose Repair Your Computer to go into recovery mode.
  • Page 72 Appendix B 3. Please choose between “Non destructive system recovery” & “Destructive system recovery”. When the ”Non destructive” option is chosen , please click Next.
  • Page 73 Appendix B 4. Reconfirm your choice by clicking OK, 5. Reconfirm your choice by clicking OK, the Non destructive system recovery will begin...
  • Page 74 Appendix B 6. The non destructive system recovery is begin 7. Then Non destructive system recovery is finished. System will be rebooting. b. “Destructive Recovery from Hard Disk”...
  • Page 75 1. How recovery is done: System files from RP are copied to system files area in UP, and user data area is formatted! Before OS boots, please press hotkeys F8 button to go into advance boot options. 2. Please choose Repair Your Computer to go into recovery mode.
  • Page 76 Appendix B 3. Please choose between “Non destructive recovery mode” & “Destructive recovery mode”. To choose “Destructive” please click Advance...
  • Page 77 Appendix B 4. When the ”Destructive” option is chosen , please click Next. 5. Reconfirm your choice by clicking OK,...
  • Page 78 Appendix B 6. Reconfirm your choice by clicking OK, the destructive recovery will begin...
  • Page 79 7. The destructive system recovery is begin 8. Then destructive system recovery is finished. System will be rebooting II. Recovering System from Recovery DVD There are three available methods: Appendix B...
  • Page 80 Appendix B The “Non destructive” & “Destructive” recoveries from Recovery DVD have the same result as a recovery from Hard Drive. a. “Non Destructive” Recovery from Recovery DVD b. “Destructive” Recovery from Recovery DVD 1. Insert the recovery DVD into the DVD drive, then choose to boot from CD ROM in BIOS.
  • Page 81 3. Please choose Standard Mode, the subsequent processes are just like those in “non destructive” & “destructive” recoveries from hard disk. c. Full Recovery from Recovery DVD In this mode, all the data in your computer will lose 1. Please insert the recovery DVD into the DVD drive, then choose to boot from CD ROM in BIOS.
  • Page 82 Appendix B 2. Please press any key to boot from DVD 3. Please choose Full Mode to go into full recovery mode.
  • Page 83 Appendix B 4. Reconfirm your choice by clicking OK,...
  • Page 84 Appendix B 5. Reconfirm your choice by clicking OK, the full recovery will begin 6. The full recovery is begin 7. Then full recovery is finished. System will be rebooting.
  • Page 85 Device Drivers Installation If you already have an operating system installed into your notebook computer, it is best to install the needed device drivers for using the built-in devices of your computer. Before installing the drivers, check with your dealer first if they have already installed all the drivers along with the operating system.
  • Page 86 Appendix B 2. Click the Browse button and specify the directory as. "E:\Drivers\Vista32\Audio\Setup.exe" where the audio driver is located. 3. When computer appears unidentified program, click “Allow” for accessing the computer 4. Click "Next" to continue the following steps. 5. Click “Next” and select “Agree” to continue the installation.
  • Page 87 Installing Wireless LAN driver for Windows Vista 32 Click the Start button and then click Run. The Run dialog box appears. Click Browse button and specify the directory as "E:\Drivers\Vista32\Wireless LAN\Liteon\setup.exe" Click “Continue” in message of a program needs your permission to Click “Next”...
  • Page 88: Technical Support Information

    Technical Support Information For the latest Product Information, Drivers, and Support Documents visit www.everex.com For complete warranty information, please refer to the Everex Limited Warranty Agreement. To register your product visit www.everex.com or simply email your User Name (first and last), Model (SA2050T, SA2052T, etc.) and Serial Number to customerservice@everex.com.
