Nuaire Group CYFAN Installation And Maintenance Manual

1.0 CYFAN Extract Fans

The Nuaire CYFAN 230V/24V DC SELV extract fans have been
designed to ventilate areas such as the bathroom, toilet, kitchen,
utility rooms etc (splash zone 2).
The unit package offers the installer 2 alternative mounting options.
Fig 1a. Surface mounting on
a cavity wall.
Accessories and kits available for CYFAN:
•
Wall mounting kit
Product Code Colour option
CYFAN-WALLKIT-WH White
CYFAN-WALLKIT-BR Brown
CYFAN-WALLKIT-COT Cotwolds
CYFAN-WALLKIT-TC Terracotta
•
Optional window mounting kit (Part number: CYFAN-WKIT).
•
Optional subsidiary spigot kit for ventilation of adjacent
bathroom/separate toilet (Part number: CYFAN-DKIT).
• Semi-recessed mounting kit (Part number: CYFAN-RKIT).
• Optional Filter available (Part number: 7702017).
The unit discharges air through a 100mm or 125mm dia. spigot which
for surface and semi-recessed mounted units exits at the rear
of the unit. The subsidiary spigot kit allows the fan to extract
air through the side of the fan via a 50mm dia. spigot.
The motor is 24V brushless DC. Bearings are sealed, self-
lubricating ball type with integral locked rotor protection.
Units are supplied with a separate transformer enclosure
if fans are required for SELV usage.

2.0 Fan Installation General

Installation must be completed by qualified personnel.
A solid non reverberant mounting position must be
selected and passages for ductwork from the outlet
spigot, as well as electrical connection prepared.
Compatible ductwork should have already been installed.
Procedure
Unpack the fan unit and other components and ensure
all parts are included against the components checklist on the right.
CYFAN Extract Fans
230V/24V DC SELV Surface and
Semi-Recessed Mounted Domestic Fans
Installation and Maintenance
Fig 1b. Semi-Recessed
mounting in a cavity wall.
Nuaire Limited Western Industrial Estate Caerphilly United Kingdom CF83 1NA
T: 029 2085 8400 F: 029 2085 8444 E: info@nuaire.co.uk W: www.nuaire.co.uk

2.1 Back draught shutters

Are suitable for intermittent operation only
therefore are not to be fitted when using
in continuous operation.
On using intermittent operation we
recommend that the back draught shutters
are not fitted when duties are set less than
15 l/s and for installations other than directly
through the wall to avoid failure of the shutters
opening. Shutters are clipped into place.
Ensure the spring is fitted in lower position.
Key to fan components
Item No. Part No.
1. 041265
2. 041270
3. 041269
4. 041266
5. 041267
6. 830296
7. 041277/8
8. 041568
9. 041275
10. 041276
11. 041285
12. 041286
13. 041279
Fig 3. General view of unit and components.
4
3 1
5
1
The EMC Directive
2004/108/EC
The Low Voltage
directive
2006/95/EC
Fig 2.
Spring.
Description Quantity
Fan Skirt
Recessed frame see fig 7.
Fan Body
Front cover
Fan Grille
PCB Assembly
Fan Scroll
PCB cover
125mm dia Spigot
100mm dia Spigot
125mm dia backdraught shutter 2
100mm dia backdraught shutter 2
Impeller
6
7 8
13
21. 10. 13. Leaflet Number 671629
1
1
1
1
1
1
1
1
1
1
1
12
11
9
10
