Omcan FP-IT-0003 Instruction Manual page 9

Model FP-IT-0003
Item No. Description
38932 Foot for C1
38933 Bottom for C1
38934
Belt for C1
18740
38935 Plate for C1
38936 Screw for C1
38937 Cable for C1
38938 Washer for C1
38939 Screw for C1
38940 Washer for C1
38941 Screw for C1
38942 Screw for C1
38943 Screw for C1
38944 Nut for C1
38945 Washer for C1
38946 Screw for C1
38947 Motor Plate for C1
38948 Cam Belt for C1
38949 Nut for C1
38950 Motor Pulley for C1
38951 Set Screw for C1
38952 Plug for C1
38953 Screw for C1
38954
Motor for C1
15213
38955 Terminal Clamp for C1
38956 On / Off Switch for C1
38957 Switch Assembly for C1
14859 Power Cord for C1
38959 Housing for C1
38960 Magnetic Microswitch for C1
10830
Position Item No. Description
1 38961 Screw for C1
2 38962 Washer for C1
3 38963 Hinge Pin for C1
4 38964 Hinge Support for C1
5 38965 Lever for C1
6 38966 Thumb Knob for Lever for C1
7 38967 Washer for C1
38968
8 Lock Knob for C1
15217
9 38969 Lever Handle for C1
10 38970 Threaded Shaft for C1
11 38971 Shaft Pin for C1
12 38972 Clip for C1
13 38973 Locking Pin for C1
14 38974 Nut for C1
15 38975 Driving Pot for C1
16 38976 Screw for C1
38977
17 Micro Switch Pin for C1
15220
18 38978 Screw for C1
19 38979 Micro Switch for C1
20 38980 Set Screw for C1
21 38981 O-Ring for C1
22 38982 Bearing and Shaft for C1
23 38983 Pulley for C1
24 38984 O-Ring for C1
25 38985 Bearing for C1
26 38986 Spacer for C1
27 38987 Clip for C1
28 38988 Clip for C1
29 38989 Pulley for C1
Parts Breakdown
Position Item No.
30 38990
31 38991
32 38992
33 38993
34 38994
35 38995
36 38996
37 38997
38998
38
15223
39 38999
40 39000
41 39001
42 39002
43 39003
44 39004
45 39005
46 39006
47 39007
48 39008
49 39009
50 39010
51 39011
52 39012
53 39013
54 39014
55 39015
56 39016
57 39017
58 39018
9
Description Position
Set Screw for C1 59
Screw for C1 60
Washer for C1 61
Capacitor & Bracket for C1 62 - 63
Screw for C1 64
Block Magnet for C1 65
Magnet for C1 66
Shaft for C1 67
Lid for C1 68
Plug for C1 69
Screw for C1 70
Blade Support for C1 71
Plug for C1 72
Blade for C1 73
Spacer for C1 74
Screws for C1 75
Blade for C1 76
Pot for C1 77
Strain Relief for C1 78
Bracket for C1 79
Screw for C1 80
Screw for C1 81
Pin for C1 82
Complete Assy. for C1 83
Nut for C1 84
Micro Switch for C1 85
Terminal Clamp for C1 86
Screw for C1 87
Hallow Cable for C1 88
