- Page 1 LCD Television LT7-M22BB / LT7-M22WB LT7-M19BB / LT7-M19WB Owner’s Manual STAND BY POWER VOL. MENU PROG.
-
Page 2: Off Precautions
PRECAUTIONS CAUTION WARNING: Do not attempt to open the cabinet. There are no user serviceable parts inside. Refer all servicing to qualified TO REDUCE THE RISK OF FIRE OR service personnel. ELECTRIC SHOCK, DO NOT EXPOSE THIS Slots and openings in the cabinet and the sides or APPARATUS TO RAIN OR MOISTURE. -
Page 3: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ..............................2 THINGS TO DO FOR THE FIRST TIME ......................4 OPERATING CONTROLS AND FUNCTIONS ....................5 PREPARATION FOR USE ..........................8 SETUP FOR USE ............................12 OPERATIONS ..............................13 OTHER SETTINGS ............................17 MAINTENANCE...............................29 TROUBLESHOOTING GUIDE ........................29 SPECIFICATIONS ............................30 DECLARATION OF CONFORMITY ........................31 Features A Note about Recycling •... -
Page 4: Things To Do For The First Time
THINGS TO DO FOR THE FIRST TIME ATTACHING THE STAND You need to attach the stand to the unit to display upright. Make sure the front and rear of the stand match the proper direction. Place the unit face down onto Hang the hook under the Drive Phillips pan screws in the soft stuff such as a cloth on a... -
Page 5: Operating Controls And Functions
OPERATING CONTROLS AND FUNCTIONS All operations described are based on the use of the remote control. Some operations can be carried out using the buttons on the control panel. CONTROL PANEL REMOTE CONTROL ASPECT STAND BY POWER VOL. MENU PROG. STAND BY POWER VOL. - Page 6 REAR PANEL <LT7-M22BB / LT7-M22WB> PC-IN HDMI-IN HDMI 1 COMPONENT AUDIO PC-IN HDMI-IN HDMI 1 PC-IN VIDEO AUDIO S-VIDEO VIDEO AUDIO SCART COMPONENT AUDIO PC-IN VIDEO AUDIO S-VIDEO VIDEO AUDIO SCART <LT7-M19BB / LT7-M19WB> PC-IN HDMI-IN HDMI 1 PC-IN COMPONENT...
- Page 7 26. COMPONENT (Y/Pb/Pr) / AUDIO (L/R) input jack Connect an RCA component video and an RCA audio cable (not supplied) to the component video and audio output jack of an external device. 27. S-VIDEO input jack Connect an S-Video cable (not supplied) to the S-Video output jack of an external device.
-
Page 8: Preparation For Use
PREPARATION FOR USE Installing the Batteries Dear Customer, By connecting an HDMI cable to your Funai LCD TV, you 1) Open the battery compartment cover. have to use only a certified HDMI cable to guarantee a 2) Insert “R6/AA” penlight batteries into battery compartment in sufficient immunity against parasitic frequency radiation. - Page 9 AUDIO (L/R) input jack of this unit. Use an RCA audio AUDIO (L/R) input jack of this unit. Use an RCA audio cable (not supplied). cable (not supplied). <LT7-M22BB / LT7-M22WB> Rear of this unit <LT7-M22BB / LT7-M22WB> PC-IN VIDEO...
- Page 10 VIDEO input jack of this unit. Use an RCA video cable (not supplied). 2) Connect the audio output jack of your video device and the AUDIO (L/R) input jack of this unit. Use an RCA audio cable (not supplied). <LT7-M22BB / LT7-M22WB> Rear of this unit PC-IN VIDEO AUDIO...
- Page 11 60 Hz (AUDIO) jack of this unit. Use a mini-plug audio cable (not SVGA 800 x 600 60 Hz supplied). 1,024 x 768 60 Hz <LT7-M22BB / LT7-M22WB> 1,280 x 768 60 Hz WXGA 1,360 x 768 60 Hz PC-IN AUDIO...
-
Page 12: Setup For Use
SETUP FOR USE Initial Setting You need to set the followings to use the unit appropriately for the first time you turn on the unit. 1) Press [Q (standby-on)] to turn on the unit. • “Initial Setup” language menu will appear. Note: The settings may be limited by the location you purchased. -
Page 13: Operations
OPERATIONS Watching a TV Programme Switching the Input Mode You can switch the input mode to TV mode or external input mode. To select a channel Press [ ] repeatedly to select your desired channel. 1) Press [INPUT]. • “Select Input” menu will appear. Press [the Number buttons] to enter a channel number then [OK] for quicker access. - Page 14 Sound Select TV Screen Information You can see the broadcasting information. 1) Press [SOUND] to display the currently selected audio language and the number of available languages. 1) Press [I (information)]. 2) Press [SOUND] repeatedly to cycle through the available •...
- Page 15 EPG (Electronic Programme Guide) You can easily find a channel or see the detailed channel information. EPG gives you scheduled information of the TV programmes. 1) Press [GUIDE]. • EPG will appear. Television TV guide Viewing date: Thu Current time: 21:16:27 19:00 Hit Music...
- Page 16 Changing the TV Screen Display Mode For HD (High Definition) video signal You can select your favourite TV screen size. “Full” Press [ASPECT] repeatedly to switch the TV screen display “Auto” mode. For SD (Standard Definition) video signal “Zoom” “Expand” “Sidebar”...
-
Page 17: Other Settings
OTHER SETTINGS Picture Adjustment “Colour Temperature” 3) Press [K / L] to select “Colour Temperature”. You can adjust the picture settings according to your personal preference. These settings are automatically stored after exiting the 4) Press [s / B] to select the setting (“Cool, Normal, Warm”) picture menu. - Page 18 Advanced Picture Adjustment “Flesh Tone” You can set to activate the flesh colours or not. You can adjust the detailed picture settings according to your personal preference. 4) Press [K / L] to select “Flesh Tone”. 1) Press [MENU] to display the menu. 5) Press [s / B] to select the setting (“On, Off ”) you want.
- Page 19 PC Settings Sound Adjustment You can adjust the PC screen position, clock and phase. Make sure your PC is connected. You can adjust the sound settings according to your personal preferences. These settings are automatically stored after exiting 1) Press [MENU] to display the menu. the sound menu.
- Page 20 Country Setting “Auto Volume Control” Note: You may not select the country depending on the You can set to keep a constant loudness differential between the location you purchased. TV commercials and the programs. 3) Press [K / L] to select “Auto Volume Control”. You can select the channels according to the country you select.
- Page 21 Audio Language Selection Auto Scan You can scan the channels receivable in your area automatically. You can select the main language. 1) Press [MENU] to display the menu. 1) Press [MENU] to display the menu. 2) Press [K / L] to select “TV”, then press [OK]. 2) Press [K / L] to select “TV”, then press [OK].
- Page 22 Analogue Manual Scan Update Scan You can adjust an analogue channel individually. You can scan the updated channels automatically. 1) Press [MENU] to display the menu. 1) Press [MENU] to display the menu. 2) Press [K / L] to select “TV”, then press [OK]. 2) Press [K / L] to select “TV”, then press [OK].
- Page 23 Channel Skip Channel Sort When using [ / ], the channel you selected will be skipped. You can change the channel order. 1) Press [MENU] to display the menu. 1) Press [MENU] to display the menu. 2) Press [K / L] to select “TV”, then press [OK]. 2) Press [K / L] to select “TV”, then press [OK].
- Page 24 Channel Edit “Frequency” You can edit channel information. 1) Press [MENU] to display the menu. 7) Press [the Number buttons] to enter a frequency you want, then press [OK]. 2) Press [K / L] to select “TV”, then press [OK]. 3) Press [K / L] to select “Channel”, then press [OK].
- Page 25 Fine Tune Time Zone You can set the time zone according to the resident area. 1) Press [MENU] to display the menu. 1) Press [MENU] to display the menu. 2) Press [K / L] to select “TV”, then press [OK]. 2) Press [K / L] to select “Setup”, then press [OK].
- Page 26 Subtitle Settings Teletext You can change the teletext settings. 1) Press [MENU] to display the menu. 1) Press [MENU] to display the menu. 2) Press [K / L] to select “Setup”, then press [OK]. 2) Press [K / L] to select “Setup”, then press [OK]. 3) Press [K / L] to select “Subtitle”, then press [OK].
- Page 27 When using this kind of card, Sound insert the card reader firmly into the C.I. slot on the unit first. Then, insert the viewing card into the reader. <LT7-M22BB / LT7-M22WB> Setup PC IN Parental...
- Page 28 Software Download “Maturity Rating” You can set the parental rating to avoid watching an inappropriate You can update the current software when this unit detects a new programme for your children. version of software. 4) Press [K / L] to select “Maturity Rating”, then press [OK]. 1) When this unit receives software updates automatically, the 5) Press [K / L] to select “Parental Rating”.
-
Page 29: Maintenance
MAINTENANCE Panel Cleaning Cabinet Cleaning • If the LCD panel should require cleaning, wipe it with a cotton • Wipe the front panel and other exterior surfaces of the unit with or soft cloth. Before cleaning the panel, disconnect the power a soft cloth immersed in lukewarm water and wrung dry. -
Page 30: Specifications
Digital encoded infrared light system PAL D/K TV standard Power requirements: AC 220-240 V~, 50 Hz SECAM L TV standard SECAM L' TV standard <LT7-M22BB / LT7-M22WB> SECAM B/G TV standard Power consumption: 70W (Standby: less than 1W) SECAM D/K TV standard LCD: 21.6 inches... -
Page 31: Declaration Of Conformity
EN61000-3-2: 2006 Class A Low Voltage Directive: 2006 / 95 / EC EN61000-3-3: 1995+A1: 2001+A2: 2005 EN60065: 2002+A1: 2006 Funai Electric (Polska) Sp. z o.o. EN55022: 2006 Class B ul. Inżynierska 1 EN55024: 1998+A1: 2001+A2: 2003 Nowa Sól, 67-100 / Poland... - Page 32 Web Site: http://www.funai.eu 1EMN25124A A9370EP/A9371EP/A93N0EP/A93N1EP Printed in EU...
