P - Moving and releasing the switch allows viewing system information via the
LEDs, and performing the following functions:
P Position
Duration
Switch moved
to P for 2
seconds, then
released.
Switch moved
to P for more
than 5 seconds,
then released.
LEDs
LEDs: three LEDs indicate, by color and state (on/ off/ blinking
(2)
flickering /alternating
performance indications. For more information, refer to
https://www.solaredge.com/leds.
The main LED indications are:
Blue ON - the inverter is communicating with the monitoring
platform
Green ON - the system is producing
Green blinking - AC is connected but the system is not producing
Red ON - system error
(1) Blinking = Turns ON and OFF for the same duration
(2) Flickering = Turns ON for 100 mS and turns OFF for 5 seconds
(3) Alternating = alternate LED flashes
Single Phase Energy Hub Inverter MAN-01-00812-1.1
Function
Displays (via
LEDs) production
information for 5
seconds, or error type
indications (if exist) for 5
seconds.
Activates the Wi-Fi
access point for
connecting to the
SetApp
Starts pairing
(3)
), different system information, such as errors or
Chapter 3: Installing the Inverter
Comments
While the switch is in P, all
LEDs are ON.
When the switch is released all
LEDs turn OFF for 0.5 sec and
then display the production or
error indication.
Pairing is indicated by all 3
LEDs blinking simultaneously.
(1)
/
