Summary of Contents for Reliable 2000FR
- Page 1 2000FR CORDLESS CLOTH CUTTER INSTRUCTION MANUAL...
- Page 2 We would like to thank you, and congratulate you for purchasing the 2000FR cordless cutting knife from Reliable. The Reliable 2000FR can cut from a single ply of fabric right up to 1” thick, making it a very versatile, lightweight machine. Ideal for sample making or other light-duty operations.
- Page 3 INSTRUCTIONS IMPORTANT: Check blade screw before use. If blade is loose, see section G to reset the blade A. Lithium Battery Installation 1. Before installing the lithium battery, please keep the power switch in the "O" position and install the lithium battery into the battery slot of the cutting machine.
- Page 4 D. LED Light Function 1. Press the speed button (as labeled "C" above) for 3 seconds to turn on the LED. Hold for another 3 seconds to turn off. ** Before cutting, connect the battery to the machine and sharpen the knife-edge by pushing the spring loaded projection-grinding switch several times.
- Page 5 H. Replacing the Grinding Wheel *remove the battery first ** 1. Hold the grinding wheel's outer circle with your hand, insert the bolt into the positioning hole on the shaft, lock the wheel, then rotate in the direction indicated by the arrow. 2.
- Page 6 GRINDING WHEEL REPLACEMENT GUIDE Hold the grinding wheel by hand. Insert the attached lock shaft to the hole provided in the grinder shaft and turn to arrow indiation. Remove used wheel and replace with a new one. GRINDERSHAFT LOOSEN LOCK SHAFT ALLEN KEY FASTEN EMERY WHEEL...
-
Page 7: Maintenance
MAINTENANCE A. Oil Injection 1. In order to ensure the best performance and life of the cutting machine, please always keep the lubricating oil pot in an oily state. 2. Inject oil every 30-40 hours of use. B. Grinding Wheel 1. -
Page 8: Specifications
SPECIFICATIONS 110MM KNIFE SIZE KNIFE SHAPE: OCTAGON CUTTING CAPACITY: 25MM (1") 2KGS NET WEIGHT: 120V VOLTAGE: POWER: 150W SPEED: 800/950/1100/1250/1400 RPM... -
Page 9: Assembly & Accessories
ASSEMBLY & ACCESSORIES DRIVE HANDLE KNIFE LI-ION BATTERY SHIELD SHARPENER FRAME OIL FELT PRESSURE SPRING KINFER OILER GRIND WHEEL PRESSURE SPRING BUTTON PANEL SCREW FOR OILER SELF-TAPPING SCREW COMBINATION SCREW SOCKET CONNECTOR BLADE PRESSURE PLATE COMBINATION SCREW 4.5*9*0.8 TERMINAL PLATE INNER HEXAGON SCREW INNER HEXAGON SCREW M4NUT... - Page 10 CHARGER INTERNAL HEXAGON WRENCH OILER BUTTERFLY WRENCH CHASSIS...
- Page 11 Reliable on an exchange basis, and will be either new or refurbished to be functionally equivalent to new. If Reliable is unable to repair or replace a Reliable Product, it will refund the current value of that Reliable Product at the time the warranty claim is made.
- Page 12 1 800 268 1649 www.reliablecorporation.com...
