Reliable XD-EU5 Specification Sheet

XD-EU5
5" Straight Knife Cloth Cutting Machine
DESCRIPTION
The Reliable™ XD-EU5 is the world's best small straight knife cutting machine. Equipped with an automatic
knife sharpening system, the XD-EU5 uses the newest and most advanced technology to ensure the finest
cutting quality.
The use of a die cast housing ensures lightweight and easy operation, while the safety mechanisms assure the
proper protection is provided for the operator.
BEST USED FOR
Light to medium weight fabrics
Woven and knit fabric
FEATURES
• Automatic sharpening system
• Low-profile ergonomic design
• Powerfull 1" stroke
OPTIONS
Specify U-ground or twist plug when ordering machine
Fine, medium and course sharpening bands are available
Model
Electrical
Horsepower
Speed
Stroke
Blade size
Sharpening belts
Lubrication
Dimensions - net
Weight - net
Shipping dimensions
Shipping weight
Warranty
XD-EU5
110V
1/3 h.p.
3,400 rpm (single speed)
1"
5"
Medium
Manual
6.25" x 10.5" x 15.5"
20 lbs
13" x 21" x 10"
25 lbs
Reliable™ 1 Year Warranty
