Summary of Contents for FujiFilm SPRAY Auto V8 Series
-
Page 2: Table Of Contents
CONTENTS Specifications Safety Precautions 3 - 4 Assembly Operation 6 - 7 Technique Parts Diagram 8 - 9 Air Cap Sets Finish Problems Troubleshooting 11 - 12 Cleaning 13 - 14 Reassembly 14 - 15 Disassembly for Service or Repairs Warranty Information... -
Page 3: Specifications
SPECIFICATIONS Max. cfm at psi Max. 12.2 cfm at 35 psi HVLP Max. 14.7 cfm at 28 psi Air Consumption 12.2 cfm HVLP 14.7 cfm Operating Pressure Range 9 to 35 psi HVLP 9 to 28 psi Standard Air Cap Set 1.3mm HVLP 1.4mm... -
Page 4: Safety Precautions
Please read these instructions before using the equipment FIRE AND EXPLOSION HAZARD Equipment must not be used in an area contaminated by volatile or flammable materials. This could ignite the contaminants causing a dangerous explosion. • Do not spray flammable or combustible materials near an open flame or sources of ignition such as cigarettes, motors, and electrical equipment. - Page 5 EQUIPMENT MISUSE HAZARD Misuse of equipment can cause serious injury or death. • Health and safety, accident prevention, work and environment protection regulations and policies are mandatory. • Never aim the Spray Gun at another person or animal. In the event of injury, seek expert medical attention immediately.
-
Page 6: Assembly
ASSEMBLY Cup Assembly Installation: Insert Paint Strainer into the base of the Cup from the outside. Attach the cup assembly by screwing into the Fluid Coupler of the Spray Gun. Hand- tightened is enough. Connecting to Air Supply: Attach pressure regulator with gauge (not included) to the Spray Gun’s air inlet 2. -
Page 7: Operation
OPERATION To clean out any impurities that may have accumulated during assembly or shipping of the Spray Gun, we recommend spraying a small quantity of clean paint thinner through the gun. If you intend to spray water-based paints and materials, make sure fluid passages and components that may have come in contact with paint thinner are completely dry. -
Page 8: Technique
Pattern Control - To produce a smaller fan pattern, turn the Fan Pattern Control Knob (#16-6) clockwise. For widest pattern, turn Fan Pattern Control Knob counter-clockwise. NOTE: In most cases, a combination of all three adjustments will provide the desired results. TECHNIQUE The Spray Gun should be held perpendicular to the surface at all times. -
Page 9: Parts Diagram
FUJI SPRAY AUTO™ V8 SERIES SPRAY GUN PART DESCRIPTION ITEM PART NAME • • 6882 Spray Gun Air Cap with Collar Rebuild Kit con- Air Cap Retaining Ring sists of one each of these parts Collar Air Cap O-Ring Air Cap •... - Page 10 ITEM PART NAME Rear Barrel Plug Seal Rear Barrel Plug • Valve Seal • Spindle Valve Housing • • 6808 Spindle Valve Bushing • • 6809 Spindle Valve • • 6810 Spindle Valve Spring • • 6811 Fluid Screw Nut Needle •...
-
Page 11: Air Cap Sets
AIR CAP SETS Air Cap Set Sizes (Sold Separately) Part Number MP Part Number HVLP 1.2mm 6800MP-V8-1.2 6890H-V8-1.2 1.3mm (Standard MP-V8) 6800MP-V8-1.3 6890H-V8-1.3 1.4mm (Standard H-V8) 6800MP-V8-1.4 6890H-V8-1.4 1.7mm 6800MP-V8-1.7 6890H-V8-1.7 2.0mm 6800MP-V8-2.0 6890H-V8-2.0 2.2mm 6800MP-V8-2.2 6890H-V8-2.2 FINISH PROBLEMS PROBLEM CAUSE Add more thinner (or Material is too thick... -
Page 12: Troubleshooting
TROUBLESHOOTING SPRAY GUN PROBLEMS PROBLEM CAUSE Check for air leaks No pressure from air on hose or adjust to supply hose appropriate pressure The air passage in Lid Clean obstruction at NO PAINT of the Cup may be pinhole located on Lid of OR VERY LITTLE PAINT obstructed the Cup... - Page 13 SPRAY GUN PROBLEMS CONTINUED PROBLEM CAUSE Cup or Lid may be Replace Cup Assembly cracked Tighten Cup Lid - hold CUP LEAKS Cup (not Gun) with one Cup Lid is too loose hand, and tighten Lid with the other Replace THE TRIGGER IS Bent Needle or not SLUGGISH...
-
Page 14: Cleaning
CLEANING GENERAL CLEANING It is very important to properly clean your Spray Gun after each use. This will prevent any build-up and/or contamination when spraying other materials. Keeping your Spray Gun clean will also prevent spray problems due to blockage. PLEASE DO NOT USE A WIRE BRUSH OR ANYTHING METAL TO CLEAN THE GUN OR CUP AS THIS WILL CAUSE DAMAGE. -
Page 15: Reassembly
THOROUGH CLEANING (Level 2) DISSASSEMBLY - See page 16 for images You may soak only the metal parts in neutral cleaning solution (pH value 6 to 8) and clean with the soft bristle cleaning brush. After performing Level 1 cleaning and removing the gravity cup from the Spray Gun: Fig. - Page 16 230-240 lbf-in 200-208 kgf-cm...
-
Page 17: Disassembly For Service Or Repairs
DISASSEMBLY Disassembly for Service or Repairs Needle Packing Nut Assembly Follow instructions on page 15 up to #6, then follow the steps below: Fig. K - Use an Allen Key size 6 to remove Fluid Screw Nut # 11, Then remove Spindle Valve Spring #10, Spindle Valve #9 and Spindle Valve Bushing #8 2. -
Page 18: Warranty Information
Fuji Spray Auto™ Limited 1 Year Warranty Fuji Industrial Spray Equipment Ltd. (“Fuji”) provides a 12 month limited warranty on the product to the original purchaser effective from the date of purchase against defects in materials and workmanship. The warranty does not cover damage or defects arising as a result of abuse, misuse, accident, negligence, malfunction, corrosion, normal wear and tear, inadequate or lack of spray gun or other aspects of maintenance of the product, damage arising from improper assembly,... - Page 19 FUJI SPRAY® AUTO CONNECT WITH US! @FUJISPRAYAUTO @FUJISPRAYAUTO @FUJISPRAY NEED HELP? FUJISPRAY.COM FUJISPRAYAUTO.COM AUTO@FUJISPRAY.COM +1 (800) 650 0930 Fuji Industrial Spray Equipment Ltd. 40 Magnetic Drive. #48, Toronto, ON, Canada M3J 2C4...
