Specification
Model
XEDHDA28V12AW-1M3
Pick up Element
1/3" SONY 1.3MP CMOS Sensor
Effective Picture
1280 X960
Elements (H×V)
Resolution
960P
0.001 Lux/F1.2
Minimum Illumination
S/N Ratio
More than 50dB
Synchronous System
Internal, Negative sync.
IR Distance
30 Meters (with Ф5X36PCS Infrared LED)
IR Power On
Photodiode AUTO Control
AHD,CVBS
Video Output
Functions
OSD menu, DWDR, 3DNR,Sense-up
Power/Current
DC12V(+/-10%)/700mA
Lens
2.8-12mm Manual Zoom Lens
IP Rating
Dimension (mm)
Φ131 x 93(H)
Weight (g)
800
Operating Tempera-
-10~+50℃ RH95% MAX
ture
Accessories list
Name
Camera
User Guide
/
Notes:
Number
Do not attempt to disassemble the camera. If the camera
1
does not work, please contact your supplier.
1
X E D H D A 2 8 V 1 2 A W - 1 M 3
Installation and user guide
Thank you for choosing to use this Xeno
Nitro High Definition Analogue camera.
Before providing power for the camera,
please read this manual carefully before
use.
