- Page 1 VEHICLE TRACKER Users Manual (ACT611) W CDM A VEHI CLE TRACKER Users Manual June, 2014 ACT611, V0.3 AnyDATA AnyTime AnyPlace Any Wireless Data Solutions™ 1/13 All Rights Reserved.
- Page 2 Any part of this document may not be distributed, communicated, reproduced or transmitted in any form or by any means, electronic or mechanical or otherwise, for any purpose, without the permission of AnyDATA Corp. This document can be subjected to revision without further notice.
-
Page 3: Table Of Contents
6.5 Environmental ...................... 12 7 Limitations of Liability Figures Figure 2.1: Package Contents ................... 7 Figure 3.1: External Interface ..................9 Figure 4.1: Installation of ACT611 in vehicle ............10 Tables Table 1.1: Revision History ..................6 3/13 All Rights Reserved. - Page 4 VEHICLE TRACKER Users Manual (ACT611) RF Exposure Warning: The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact during normal operation is minimized. In order to avoid the...
- Page 5 VEHICLE TRACKER Users Manual (ACT611) La puissance de sortie rayonnée de cet appareil est inférieure aux limites d'exposition de radio de fréquence IC. Néanmoins, le dispositif doit être utilisé de telle manière que le potentiel de contact humain pendant l'utilisation normale soit minimisé. Afin d'éviter la possibilité...
-
Page 6: Introduction
VEHICLE TRACKER Users Manual (ACT611) NTRODUCTION 1.1 P URPOSE This manual discusses the purpose and usage of the Vehicle GPS Locator (ACT611). 1.2 T ECHNICAL ETAIL Please refer to Technical Manual.pdf for a more detailed description of the ACT611. 1.3 R... -
Page 7: Physical Contents
VEHICLE TRACKER Users Manual (ACT611) HYSICAL ONTENTS Figure 2.1: Package Contents The box should contain: One ACT611 Vehicle GPS Tracker • One User Guide • 7/13 All Rights Reserved. -
Page 8: Description: Vehicle Gps Locator (Act611) 3.1 The Latest Vehicle Tracker In Gps Technology
3.2 T RACKING EPORTS The ACT611 can be configured to report its location on a sw scenario based chronological interval. The interval is remotely configurable and can be set via appropriate web and mobile software platforms. In addition to... -
Page 9: Figure 3.1: External Interface
VEHICLE TRACKER Users Manual (ACT611) Figure 3.1: External Interface 9/13 All Rights Reserved. -
Page 10: Handing The Vehicle Gps Locator
1. Most of vehicle has an OBD-II (On Board Diagnostics) connector, which is located within 2 feet of the steering wheel. 2. The installation is very easy, just put the ACT611 to the OBD-II connector in user vehicle. 3. The ACT611 will power on automatically from vehicle battery and start initiation for WCDMA network access. -
Page 11: Powering On/Off The Vehicle Gps Locator
1. If the device is needed for totally power-off, then just remove it from the OBD-II connector. 2. In case of the car has engine off with ACT611, and passed several days, the device has automatically power-off to protect the battery drain fully. -
Page 12: Vehicle Gps Locator Specifications
VEHICLE TRACKER Users Manual (ACT611) GPS L EHICLE OCATOR PECIFICATIONS 6.1 F ACTOR Dimensions : 80 x 45 mm, 22mm in Height • Weight 66.5g • 6.2 H ARDWARE PECIFICATIONS Assisted & Standalone GPS • Operating Voltage 9 ~ 18V, (internally 3.5V for WCDMA RF) •... -
Page 13: Limitations Of Liability
AnyDATA Locating Service through the Internet or other communication services. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL...
