- Page 1 Personal GPS Locator Users Manual (APT-210D) CDMA PERSONAL GPS LOCATOR Users Manual May, 2009 APT-210D – v 0.1 AnyDATA AnyTime AnyPlace Any Wireless Data Solutions™ 1/17 All Rights Reserved.
- Page 2 Any part of this document may not be distributed, communicated, reproduced or transmitted in any form or by any means, electronic or mechanical or otherwise, for any purpose, without the permission of AnyDATA Corp. This document can be subjected to revision without further notice.
- Page 3 1.2 Technical Detail ..........5 1.3 Revision History ..........5 2 Physical Contents ............ 6 3 Description: Personal GPS Locator (APT-210D) ......7 3.1 The Latest in GPS Technology ........7 3.2 Alerts & Messages ..........7 3.3 Tracking Reports ..........7 4 Charging the Personal GPS Locator ........
-
Page 4: Contents
Personal GPS Locator Users Manual (APT-210D) Figure 2.1: Package Contents .................... 6 Figure 3.1: External Interface ..................8 Figure 3.2: LED Indicator ....................8 Figure 4.1: USB Power Adapter (Wall Charger & Car Charger) ......9 Figure 4.2: Asset Tag w/ External Power ..............10 Figure 5.1: Reset Button .................... - Page 5 Personal GPS Locator Users Manual (APT-210D) NTRODUCTION 1.1 P URPOSE This manual discusses the purpose and usage of the Personal GPS Locator (APT-210D). 1.2 T ECHNICAL ETAIL Please refer to Technical Manual.pdf for a more detailed description of the APT-210D.
-
Page 6: Physical Contents
• One APT-210D Personal GPS Locator • One Power Adapter • One Car Charger • One User Guide If any of items on Figure 2.1 are missing, please contact AnyDATA or distributor/reseller where device was purchased. 6/17 All Rights Reserved. - Page 7 Utilizing both assisted and standalone GPS, APT-210D is able to determine your location via a combination of cell triangulation and the greatest number of GPS satellites available. APT-210D charges via the included USB wall charger. APT-210D is equipped with a battery life of 3-7 days with normal usage. 3.2 A &...
- Page 8 Personal GPS Locator Users Manual (APT-210D) Reset Button Power On/Off SOS Button Left Front Right Charging Port LED Indicator Bottom Figure 3.1: External Interface LED Indicator Figure 3.2: LED Indicator 8/17 All Rights Reserved.
-
Page 9: Battery Life
210D Locator is fully charged. 4.2 B ATTERY 1. Your APT-210D battery will last 3 to 7 days (depending on frequency of locating the device). 2. In Standby mode, it will last up to 7 days. Figure 4.1: USB Power Adapter (Wall Charger & Car Charger) 9/17 All Rights Reserved. -
Page 10: Battery Handling
Personal GPS Locator Users Manual (APT-210D) Figure 4.2: Asset Tag w/ External Power 4.3 B ATTERY ANDLING Lithium cells and batteries may get hot, explode or ignite and cause serious injury if exposed to abuse conditions. Be sure to follow the safety warnings listed below: •... - Page 11 Personal GPS Locator Users Manual (APT-210D) • Do not place the battery in microwave ovens, high-pressure containers or on induction cookware. • In the event the battery leaks and the fluid gets into one’s eye, do not rub the eye. Rinse well with water and immediately seek medical care.
-
Page 12: Powering On/Off
To Power OFF: 1. Switch the slider to the OFF position. 2. Wait a few seconds until the APT-210D has properly shut down. 3. The APT-210D Status LED will be solid blue until it shuts OFF. 5.2 R APT-210D ESETTING THE 1. - Page 13 Personal GPS Locator Users Manual (APT-210D) GPS L HECKING THE OCATOR TATUS COLOR LED INDICATOR STATUS BLUE, 2 QUICK BLINKS Power ON BLINKING BLUE Locator is on Standby BLINKING BLUE Charge is Complete (W/ POWER ADAPTER) SOLID BLUE UNTIL NO COLOR...
-
Page 14: Optional Feature
Personal GPS Locator Users Manual (APT-210D) PTIONAL EATURE NOTE: This feature is enabled/disabled by the application provider and may not be supported by the device you have purchased. 7.1 G ENCE PTIONAL Set GEO Fence On: 1. Press and hold the SET button for approx 3 seconds. -
Page 15: Mechanical
Personal GPS Locator Users Manual (APT-210D) GPS L ERSONAL OCATOR PECIFICATIONS 8.1 F ACTOR • Dimensions 56mm in diameter, 18mm in thickness • Weight 40.7g or 1.44oz 8.2 H ARDWARE PECIFICATIONS • Full TIA/EIA/IS-98D Compliance Assisted & Standalone GPS •... -
Page 16: Environmental
Personal GPS Locator Users Manual (APT-210D) 8.5 E INTERFACE XTERNAL • • Power/Service LED • Configurable Soft Button • External Reset • Power On/Off Button 8.6 E NVIRONMENTAL • Operating Temperature -4 ~ 140F (-20 ~ +60C) • Storage Temperature -22 ~ 140F (-30 ~ +60C) •... - Page 17 AnyDATA Locating Service through the Internet or other communication services. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL...
