Summary of Contents for Etesia MBEB
- Page 1 Original user Please read carefully before using your machine manual MBEB...
-
Page 2: Table Of Contents
CONTENTS 1• Your safety and that of others ................................3 2• Key to diagrams ..................................... 4 3• Description ......................................8 4• Pictures ........................................9 5• Technical specifications ..................................13 6• Operating instructions ..................................14 7• Assembly - Disassembly - Access to components ..........................16 8•... -
Page 3: 1• Your Safety And That Of Others
ETESIA dealer. • Always keep the wheelbarrow and its accessories in a perfect condition. • ETESIA shall have no liability if the instructions or applicable regu- • Never use the electric wheelbarrow with defective guards or if its lations are not followed. -
Page 4: 2• Key To Diagrams
2• KEY TO DIAGRAMS - SAFETY • LABELS • Various labels have been affixed to your electric wheelbarrow. • Check that they are all present (see list below and picture A). • Labels with a yellow background warn against risks. •... - Page 5 2• KEY TO DIAGRAMS - SAFETY RECTANGLE A...
- Page 6 2• KEY TO DIAGRAMS - SAFETY Marking of accumulators RECTANGLE A Label for battery connections Label for power fuses...
- Page 7 2• KEY TO DIAGRAMS - USE A - BY-PASS D - CIRCUIT BREAKER - Lever on 1 position = advance transmission engaged 0 : Control and power circuit cut from the battery. - Lever on 0 position = advance transmission disengaged The charging function remains connected to the battery.
-
Page 8: 3• Description
3• DESCRIPTION Time indicator Power saving / low speed Maintenance Time indicator or error codes Warning light (see section 11•4) Charge level • 1. Operator connector • 6. Charging plug • 2. Driving direction joystick • 7. By-pass lever • 3. Handlebar •... -
Page 9: 4• Pictures
4• PICTURES... - Page 10 4• PICTURES...
- Page 11 4• PICTURES...
- Page 12 4• PICTURES - ACCESSORIES IN OPTION MBPB MBBT MBBR + MBER MLMBE + MV80N3 MLMBE + MM103...
-
Page 13: 5• Technical Specifications
5• TECHNICAL SPECIFICATIONS 1027 1722 MODEL MBEB ENGINE Electric Power 1700 W BATTERIES Type GEL (lead / acid) Voltage 48V (4 x 12V - connected in series) Capacity 38 Ah (C 20 ) Weight 4 x 13,7 Kg Service life (number of charge cycles) -
Page 14: 6• Operating Instructions
6• OPERATING INSTRUCTIONS 6•1 PRE-DELIVERY INSPECTION • Push the joystick gradually, to the left, to control the speed moving forward. • The pre-delivery inspection is a highly technical operation and will • Push the joystick gradually, to the right to control the speed in reverse. therefore be carried out by your approved dealer. - Page 15 (picture 7b). not keep the charge. Always recharge the battery with an original Etesia charger ref. 39237. The charger stops Is the battery pack fully Use your wheelbarrow CAUTION :...
-
Page 16: 7• Assembly - Disassembly - Access To Components
Batteries contain hazardous materials and must under no circumstances be disposed of into the environment. They are the subject of specific rules governing (directive 2006/66/CE). For the disposal of batteries marked ETESIA, we participate in the schemes in place in the countries where the machine is sold. -
Page 17: 9• Maintenance Schedule
• Before you start using the wheelbarrow, charge your batteries to ensure sufficient autonomy. CAUTION Use an Etesia charger. Contact your dealer for the following adjustments or maintenance operations: - Replacement of any parts, or repairs involving the removal of parts... -
Page 18: 11• Troubleshooting
Our dealer network has been informed about its obligation 11•3 CHANGING TYRES to take back, free of charge, all used pneumatics from ETESIA wheelbarrows. Where it is necessary to remove a wheel, this should be done on firm, even ground. -
Page 19: 12• Accessories (Options)
11• TROUBLESHOOTING 11•4•2 FAILURE WITH ERROR CODE Error Message on Symptoms Cause of problem Why ? How to repair ? code interface 02A27 High temperature Drive controller over- Rubbish preventi ng Clean the area around the heating drive controller from drive controller and allow the cooling controller to cool... -
Page 20: 13• Warranty
(main or secondary residence). requested to be returned at any time by ETESIA. Should ETESIA - Professional use = use of an ETESIA machine, in exchange of not receive these part(s), a warranty claim would automatically be money or not, on public areas to maintain companies or institutions rejected. - Page 22 Production year Serial number: Done in Wissembourg, the 04.09.2019 Mr. Francis NEFF Due to our continual improvement policy, ETESIA reserves the right to modify specifications, text and pictures without prior notice. 13, Rue de l’Industrie - F- ETESIA SAS -...
- Page 23 Stamp here please ETESIA SERVICE GARANTIE 13 rue de l'Industrie 67165 WISSEMBOURG CEDEX France...
- Page 24 This card has to be returned completed to ETESIA upon the first setting up. MODEL: SERIAL NUMBER: WARRANTY CERTIFICATE USER NAME __________________________ Forename _________________________ Street ____________________________ Zip code __________________________ Town ____________________________Country___________________________ Tel _____________________________ Date of purchase _____ _____ 20 __...
