Analog Technologies 115C Quick Start Manual

Multimeter
Analog Technologies
115C and 117C
FEATURES
Digital display: 6000 counts, updates 4/sec
Bar graph: 33 segments, updates 32/sec
Operating temperature: -10℃ to +50℃
Storage temperature: -40℃ to +60℃
Operating altitude: 2000 meters
APPLICATIONS
It's widely used to measure AC, DC, direct voltage,
alternating voltage, resistance, etc.
DESCRIPTION
115C and 117C are battery powered, true-rms multimeters
with a 6000-count display and a bar graph.
nd
115C and 117C meet CAT Ⅲ IEC 61010-1 2 Edition
Figure 1. The Photo of Actual 117C
nd
safety standards. The IEC 61010-1 2 Edition safety
standard defines four measurement categories (CAT to IV)
based on the magnitude of danger from transient impulses.
CAT Ⅲ meters are designed to protect against transients in
fixed-equipment installations at the distribution level.
SAFETY INFORMATION
Warning: statement identifies hazardous conditions
and actions that could cause bodily harm or death.
Caution: statement indentifies conditions and actions
that could damage the meter or equipment under test.
To avoid possible electric shock or personal injury, follow
these guidelines:
Use the meter only as specified in this datasheet or the
protection provided by the meter might be impaired.
Do not use the meter or test leads if they appear damaged, or
the meter is not operating properly.
Figure 2. The Photo of Actual 117C
Always use proper terminals, switch position, and range for
measurements.
Verify the meter's operation by measuring a known voltage.
If in doubt, have the meter serviced.
Do not apply more than the rated voltage, as marked on
meter, between terminals or between any terminal and earth
ground.
Use caution with voltages above 30V AC rms, 42V AC peak,
or 60V DC. These voltages pose a shock hazard.
Disconnect circuit power and discharge all high-voltage
capacitors before testing resistance, continuity, diodes or
capacitance.
Do not use the meter around explosive gas or vapor.
When using test leads or probes, keep your fingers behind
the finger guards.
Figure 3. The Photo of Actual 117C
