TEFAL EXPRESS AUTO CONTROL Manual page 8

Description
1. Power Zone Button
2. Comfort handle
3. Easy cord system
4. Thermostat light
5. Iron rest
6. Power cord
7. Power cord storage space
8. Steam Control Button
9. Retaining clip for locking iron on the base unit
10. Water tank filler cover
11. 1,7 L water tank
12. Boiler (in the base unit)
Locking system for retaining the iron on the base - Lock-system
Your steam generator is fitted with a retaining hoop to hold the iron onto the base with a locked position for easy
transport and storage - fig.1:
• Locking - fig.2.
• Unlocking - fig.3.
To transport your steam generator using the handle of the iron:
- Put the iron on the steam generator iron rest and raise the retaining hoop over the iron until it locks into place (audible
click) - fig.2.
- Hold the iron by the handle to transport your steam generator
Preparation
What water may be used?
• Tap water:
Your appliance has been designed to function using untreated tap water. If your water is very hard, we recommend you
use a mix of 50% untreated tap water and 50% distilled water available in hardware stores.
• Types of water not to use:
Heat concentrates the elements contained in water during evaporation. The types of water listed below may contain
organic waste, mineral or chemical elements that can cause spitting, brown staining or premature wear of the
appliance: water from clothes dryers, scented or softened water, water from refrigerators, batteries, air conditioners,
rain water, boiled, filtered or bottled water. These types of water should not be used in your TEFAL iron. Also only use
distilled water as advised above.
Always remember:
Never use rainwater or water containing additives (like starch, fragrance or water from domestic appliances). Such
additives can affect the steam properties and at high temperature, form deposits in the steam generator chamber
which are likely to stain your washing.
Filling the water tank
• Place the steam generator on a flat, stable, heat-resistant surface.
• When the red «Water tank empty» light is flashing
• Unplug the steam generator. Open the water tank filler cover
• Fill the water tank using a jug taking care not to exceed the MAX level
• Close the water tank filler cover
• Switch the steam generator on.
Switch the steam generator on
• Put the steam generator on a flat, stable, horizontal surface that is heatproof.
The first time the
appliance is used, there
• Always ensure that the base unit is positioned close enough to the ironing surface to avoid
may be some fumes
and smell but this is not
• Completely unwind the power cord and take the steam cord out of its storage space
harmful.
• Plug your steam generator into an earthed socket.
They will not affect
• Press the «ON-OFF» button
use and will disappear
• When you switch on the appliance the «NORMAL» button flashes
rapidly.
- fig.7.
straining and wear of the steam cord.
light also flashes while the iron is warming up.
13. Sliding storage space for steam cord
14. Steam cord
15.
Anti-Calc Collector Cap
16. Anti Calc-Collector
17. Autoclean soleplate
18. Control panel
a. «ON-OFF» and «NORMAL» button with light
b. «MAX» (JEANS) button with light
c. «MIN» (DELICATES) button with light
d. «Water tank empty» light
e. «Anti-Calc» light
f. «ECO» button with light
- fig.1.
- fig.4, there is no more steam. The water tank is empty.
- fig.5.
- fig.6.
- fig.8.
8
- fig.9-10.
- fig.11 and the thermostat
