- Page 1 Product size: W155*D92*H80cm The intended use of this product is for domestic use only. Important, please retain for future reference. Read carefully. ---------------- ---- - www.ro y alcraft.co.uk Produced in China for A Mir & Co., Ltd. 1 / 6 ©A Mir &...
- Page 2 Tips: Do NOT fully tighten bolts before all components are connected. Only fully tighten once you are satisfied with the alignment of all components. Do not overtighten the bolts. www.royalcraft.co.uk Produced in China for A. Mir & Co., Ltd. © A. Mir & Co., Ltd. 2 / 6...
- Page 3 Diagram Qty. Diagram Qty. 1 PC 1 PC Back Panel Front Panel 2 PCS 1 PC Bottom Side Panel Panel 1 PC 2 PCS Pump 1 PC Washer Lining www.royalcraft.co.uk Produced in China for A. Mir & Co., Ltd. © A. Mir & Co., Ltd. 3 / 6...
- Page 4 Side Panels (C) using Washers (H), Bolts (K) and Bolt Head Caps (I). NOTE: Do not fully tighten any of the bolts until all bolts are in place and aligned. www.royalcraft.co.uk Produced in China for A. Mir & Co., Ltd. © A. Mir & Co., Ltd. 4 / 6...
- Page 5 Step Three With the help of another person, assemble the Lid (E) to the Back Panel (B) using Washers (H), Bolts (L), Nuts (J) and Bolt Head Caps (I). www.royalcraft.co.uk Produced in China for A. Mir & Co., Ltd. © A. Mir & Co., Ltd. 5 / 6...
- Page 6 Be careful and don’t pinch your fingers. Always be careful when close the lid. Drop down the lid slowly. Children and Kids should NOT use this box. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE www.royalcraft.co.uk Produced in China for A. Mir & Co., Ltd. © A. Mir & Co., Ltd. 6 / 6...
