- Page 1 24E900 Ver 1.0 USER’S MANUAL 24” LED TELEVISION For technical assistance or troubleshooting please call 1-855-994-3832 or visit www.sibrandssupport.com...
-
Page 2: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. - Page 3 Safety Instructions Important safeguards for you and your new TV Observing the simple precautions discussed in this booklet will provide you with many years of enjoyment and safe operation. This product complies with all applicable US Federal safety requirements, and those of the Canadian Standards Association.
- Page 4 Safety Instructions 13. Outdoor Antenna Grounding If an outside antenna or cable system is connected to the TV be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built up static charges. Article 810 of the National Electrical Code (U.S.A.), ANSI / NFPA 70 provides information with regard to proper grounding of the mast and supporting struc- ture, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna- discharge unit, connect on to grounding electrodes, and requirements for the grounding electrode.
- Page 5 Safety Instructions 19. Replacement Parts When replacement parts are required, be sure that only an authorized service technician has used replacement parts specified by Apex Digital or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards and void any warranty.
-
Page 6: Table Of Contents
Table of Contents Important Safety Instructions ............................1 Table of Contents ................................5 Introduction ..................................6 Remote Control Battery Install .................................7 Overview ..................................8 TV Overview Front Panel ................................10 Rear Panel ................................. 11 Installation Connection to Antenna & Cable / Satellite Box ......................12 Connection to HDMI Input ............................13 Connection to Component YPbPr Input ........................14 Connection to Composite Input ...........................15... -
Page 7: Introduction
Introduction What’s In The Box Thank you for purchasing the energy efficient 24E900 television. It has been designed to enjoy today’s high definition television experience. With a display resolution of 24”1920X1080 you are assured of one of the finest quality televisions available today. -
Page 8: Remote Control
For non-major TV functions not listed, use the remote control included with this TV. o program your Cable / Satellite remote to operate this ETEC TV, follow the programming instruc- tions included with your providers’ remote and use the following codes. -
Page 9: Overview
Remote Control Overview 24E900... - Page 10 Remote Control Overview Button Function 1. POWER Turn the display ON or OFF (Standby). 2. DISPLAY Provides program information for program being viewed. PLAY/PAUSE (USB) PREVIOUS (USB) NEXT (USB) STOP (USB) 7. REP REPEAT (USB) 8. CH.LIST Press to display a list of channels saved in the TV tuner memory. 9.
-
Page 11: Tv Overview
TV Overview Front Panel IR Receiver A Red/Blue light illuminates When the television power is on. Œ Ž 1. INPUT - After connecting your DVD, cable box, etc. select the appropriate input source to view. Press the INPUT button to display the input options. -
Page 12: Rear Panel
TV Overview Rear Panel Œ Ž Wall Mounting It is recommended that you consult a professional before mounting this TV a wall. Use VESA 100 x 100 wall mount hardware. NOTE: You must remove the pedestal before wall mounting. 1. -
Page 13: Installation
Connection to Antenna & Cable / Installation Satellite Box It is strongly recommended that the installation of a high quality roof top antenna, digital cable, or satel- lite set top box be used in conjunction with your television for best broadcast reception. For indoor use, we recommend an amplified HDTV antenna. -
Page 14: Connection To Hdmi Input
Installation Connection to HDMI Input Digital Cable / Satellite Set Top Box HDMI cable ( not included ) Cable / Satellite set top box Coaxial / RF Cable (not included) How to connect with Digital Cable / Satellite Set Top Box Connect the RF coaxial (75 ohm) cable from the video outlet of your cable / Satellite box to the RF input on the TV’s panel. -
Page 15: Connection To Component Ypbpr Input
Connection to Component Installation YPbPr Input Connecting External Equipment to Component Video IN (Y Pb Pr) Component cables (not included) Digital set top box, gaming console or DVD For BETTER video performance Connect to external equipment that features component video output jacks for better performance. -
Page 16: Connection To Composite Input
Installation Connection to Composite Input Connecting External Equipment to AV Composite IN on your television Audio Video Cable (not included) Digital set top box, gaming console or DVD For GOOD video performance Connect to external equipment using optional video and audio cables. Composite output jacks are available on most set top cable / satel- lite boxes and DVD players. -
Page 17: Connection To A Personal Computer
Installation Connection to a Personal Computer Connecting a Personal Computer with VGA to your television VGA & Audio Cable (not included) Recommended computer display resolution:1920x1080@60 Hz How to Connect a PC Source Selec t Connect using an optional male to male VGA cable (not included) from your PC to the VGA input on the TV’s panel. -
Page 18: Connection To A Home Theater System
Connection to a Home Installation Theater System Connection to a Home Theater Audio System Optional cables Dolby Prologic Front Left Front Right Center Channel How to Use (Video) Dolby Surround Connection Illustration Press the appropriate INPUT ENTER. How to Use (Audio) -
Page 19: Tv Setup
TV Setup Initial Setup Wizard Initial Setup Wizard Setup Wizard only appears when first turning the TV on. After connecting your TV antenna or cable wire, turn the television ON. The quick setup wizard will display on-screen. Select your preferred Picture setting followed by antenna options and performing Auto Scan to receive local broadcast channels that will be stored in the TV tuner memory. -
Page 20: Tv Provider Setup & Channel Auto Scan
TV Provider Setup TV Settings & Channel Auto Scan After the Setup Wizard has been completed, please skip this page as your Cable/Antenna is already set up. The following instructions on this page are provided if you need to make changes at a later time. -
Page 21: Picture Setting
Menu Adjustments Picture Setting The Picture menu offers options to enhance and refine the picture displayed on your TV based on ambient room light and personal preferences. Adjustment options include contrast, brightness, color, sharpness and color temperature. How to Navigate: Press the MENU button on the remote control. -
Page 22: Audio Settings
Menu Adjustments Audio Settings The Audio menu offers options to make sound enhancements while listening through the built-in speakers or to select digital audio options when connected to a Dolby Digital receiver though a (SPDIF) coaxial digital output. How to Navigate: Press the MENU button on the remote control. - Page 23 Menu Adjustments Date & Time Settings The Time menu includes adjustment of settings for your local time zone and daylight savings time. The clock will adjust automatically after the initial Channel Auto Scan of available broadcast channels in your area (see page 18 for TV Setup).
-
Page 24: Setup Settings
Menu Adjustments Setup Settings In the Setup menu you may change the initial set up of preferences that include settings for language, menu display, computer monitoring,closed captions, enhancement of black detail in the picture and resetting your TV back to its fac- tory default status. -
Page 25: Closed Captions
Menu Adjustments Closed Captions The Setup menu includes adjustments for activating the Closed Caption text feature for display on-screen and customiz- ing CC display types and font styles. How to Navigate: Press the MENU button on the remote control. Navigate using arrow buttons to select Setup. -
Page 26: Pc Menu Adjustments
PC Menu Adjustments Advanced Settings In the Setup menu you may adjust the position of images displayed on screen once you connect an input signal from your PC. The recommended resolution is 1920X1080. For use with a laptop or desktop computer, refer to your computer’s user manual on instruction for proper display output. -
Page 27: Parental Control
Menu Adjustments Parental Control In the Lock menu, you may block television and movie programming based on TV ratings and Motion Picture Association guidelines. To gain access and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control. - Page 28 Menu Adjustments Parental Control In the Lock menu, you may block television and movie programming based on Canadian TV and movie rating guidelines. To gain access and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control.
-
Page 29: Tv Settings
Menu Adjustments TV Settings The Channel provides the setup / changes of your television to receive broadcast channels, store your favorite chan- nels, add or skip channels in memory and label or name channels.(For antenna and Auto Channel Scan setup, please refer to page 18.) How to Navigate: Press the MENU button on the remote control. -
Page 30: Usb Modes
USB Modes 1. Press the INPUT Input menu, and then press the ENTER button to enter USB Mode. Source Selec t Component / AV HDMI Media sic, and then press the ENTER button to enter. press ENTER button to enter. then press the ENTER button to enter. -
Page 31: Mhl Setting
MHL Setting Connecting an MHL-enabled device You can connect an MHL-enabled device, such as a cell phone, and view your device’s screen on your TV. To connect an MHL-enabled device: 1 Press INPUT to open the Input Source list. 2 Press to select HDMI, then press ENTER. - Page 32 Specifications Display Size (inch) Aspect Ratio 16:9 Digital Compatibility 480i / 480p / 720p /1080i Resolution 1920x1080 Brightness (cd / m2) Dynamic Contrast Ratio 3000:1 Vertical Viewing Angle (degrees) 178° Horizontal Viewing Angle (degrees) 178° Maximum Colors (millions) 16.7M Power Consumption 36Watts Audio Power 2 X 3 W...
-
Page 33: Troubleshooting
Troubleshooting Check for a possible solution to a symptom before contacting a customer service representative. Cannot receive certain • Perform Channel Scan to add channels into the TV tuner memory. channels through the See page 19. antenna • Readjust your antenna and retry Auto Channel Scan. •... - Page 34 We warrant this product to be free from defects in material and workmanship under normal use for a one-year period from the original date of purchase from an authorized ETEC dealer. We will repair or replace the unit free of charge should it become defective under this warranty, providing you, the original purchaser, submit proof of purchase (sales slip) along with the TV and all accessories.
