Preface

dCC is an operator control pendant often referred to as a jogbox for a Coordinate Measuring Machine
(CMM). The pendant allows the operator to move the sensor portion of the CMM to a desired location in
the work volume. In addition to driving the machine, dCC allows the operator to pull up part programs on
the embedded tablet in the pendant. dCC is available either as a tethered wired version or a wireless
version.
This manual was written for Customers who own or intend to purchase the Hexagon Manufacturing
Intelligence (hereafter referred to simply as Hexagon) dCC Jogbox (hereafter referred to simply as Jogbox).
This document is a supplement to the operating manual of the CMM. Only after you have read and
understood both will you be able to operate the CMM safely with the Jogbox. Which functions you can run
from the Jogbox depends on which CMM is connected to it. Therefore, you will find the machine-specific
functions in the operating manual of the CMM that is connected to the Jogbox.
Keep the user manual in such a way that it is accessible when required. Ensure that the user manual is
always complete and in a readable state. The information it contains is essential to ensure the safety of the
equipment and personnel operating it. We therefore recommend you read it carefully before proceeding to
use the Jogbox or carrying out maintenance activities.
This documentation is only valid for the versions of the Jogbox described here. The figures and drawings
shown are not to scale. All dimensions are in millimeters. This user manual does not claim to be a
comprehensive technical description. All the information on the functionalities and specifications hold good
only in conjunction with the original accessories of the manufacturer.
This Jogbox is intended for use for operating CMMs that are equipped with a DC and B3C controller.
Note. You may print as many copies of this copyrighted manual as desired for personal
use.
i
Note. Due to continuous product development, the images included in this manual
may not resemble the customer's configuration.
