INSTALLATION INSTRUCTIONS
1.
Position Rim Clamp Assembly
on INSIDE of
drum holder bracket (item 1)
with holes aligned
2.
Bolt in place using
2 bolts (item 2) and
2 washers (item 3)
WARNING:
2-methylimidazole, which are known to the State of California to cause cancer, and bisphenol-A, which is known to
the State of California to cause birth defects or other reproductive harm.
For more information go to
Copyright 2021 - Morse Mfg. Co., Inc.
This product can expose you to chemicals including barium sulfate, cobalt, titanium dioxide, and
www.P65Warnings.ca.gov
Form PL4560B-P (0821-____)
Kit # 4560B-P
Kit, Rim Clamp Assembly
Operator's Manual
for Morse Rim Clamp Assembly Kit
Page
1
Kit # 4560B-P
2 - 3
Serial number 0821 to ____ (MMYY)
4
(Updated 30 Aug, 2021)
