Epson PowerLite 703c Specification page 2

EPSON PowerLite 703c Specifications
Projection System
Projection Method
LCD
Size 0.9"
Driving method EPSON Poly-Silicon TFT Active Matrix
Pixel number 786,432 dots (1024 x 768) x 3
Native resolution XGA
Aspect ratio 4:3 (supports 16:9, 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual: zoom/focus
F-number 2.0 to 2.2
f-number 35 to 42mm
Zoom ratio 1:1.2
Lamp
Type 150W UHE
Life(typical) 1000H
Screen Width Ratio: (Distance/Width)
Screen Size (Projected Distance)
Keystone Correction
Brightness (typical)
Contrast Ratio
Brightness Uniformity (typical)
Color Reproduction
Sound Output
Operating Temperature
Power Supply Voltage 100-120V, 200-240V ±10%, 50/60Hz AC
Power Consumption
Dimension (including lens and feet)
Weight
Fan Noise
Effective Scanning Frequency Range
Pixel clock
Horizontal
Vertical
Remote Control Features
Keystone, picture in picture, special effects, source selection, power, resize,
right/left mouse click, volume, presets
RGB
Analog RGB I/O
Display performance
Native 1024 x 768
Resize 1600 x 1200
1280 x 1024
800 x 600
640 x 480
Input terminal
Video Mini D-sub 15pin
Audio Stereo mini jack
Output terminal
Audio Stereo mini jack
(Common Video Audio output)
(plug-in, then speaker-off)
Specifications and terms are subject to change without notice. EPSON is a registered trademark of Seiko Epson Corporation. PowerLite is a registered trademark, SizeWise is a trademark and Epson Connection,
PrivateLine and Presenters Online are service mark of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any
and all rights in these marks. © Copyright 2001 Epson America, Inc. CPD-11604 50K 2/01 CL
EPSON original LCD prism technology
Front/rear/ceiling mount
1.83 to 2.23:1
26" to 300" (1.1m to 13.8m)
±15 degrees
1000 ANSI lumens
320:1
85%
24 bit; 16.7 mil
1W monaural
5°C to 35°C (41°F to 95°F)
230W (5W at standby mode)
10.5"D x 8.4"W x 3.4"H
5.8 lb/2.6kg
42db
25.2MHz to 162MHz
15.6KHz to 91.1KHz
50Hz to 86.9Hz
Video I/O
Display performance NTSC: 550 line
PAL: 550 line
(Depends on observation
of multi-burst pattern)
Input signal NTSC/NTSC4.43/NTSC50/
PAL/M-PAL/N-PAL/PAL60/SECAM
Input terminal
Video Composite video: RCA x 1
S-Video x 1
Video RGB: Mini D-sub 15pin
Audio RCA x 2
Output signal 0 - 500m Vrms / 600ohm
Output terminal Stereo mini jack
(Common Analog RGB Audio output)
(plug-in, then speaker-off)
Control I/O
Mouse/serial I/O
I/O terminal Din 9pin x 1 / USB type B x 1
Mouse compatibility PS/2, ADB, USB
Security
Warranty
Standard two year limited warranty, international warranty, 90-day lamp
warranty, EPSON Road Service Program and EPSON PrivateLine dedicated
toll-free support (U.S. and Canada only)
Supplied Accessories
Power cord, RCA video/ audio cable, remote control, 2 batteries, computer
cable HD15/HD15, PS/2 mouse cable, USB mouse cable, soft case, Start
Here Kit
Product/Accessory Part Numbers
EPSON PowerLite 703c Projector
Replacement lamp
Samsonite wheeled soft case
Slimline soft shoulder bag
Notebook/projector soft shoulder bag
ATA molded hardshell case
50" portable screen
60" insta-theatre screen
80" insta-theatre screen
Mac adapter set
Kensington security lock
Ceiling mount
Suspension adapter for ceiling mount, 1
Suspension adapter for ceiling mount, 1" pipe
Presentation audio system
Wireless microphone system
Support–The Epson Connection SM
Pre-Sales Support U.S. and Canada
Automated Technical Support
Internet Web Site
SM
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Epson Latin America
6303 Blue Lagoon Drive, Miami, FL 33126
Kensington-style lock provision
EMP-703
ELPLP14
ELPKS35
ELPKS31
ELPKS32
ELPKS30
ELPSC06
ELPSC07
ELPSC08
ELPAP01
ELPSL01
ELPMB32
1 / " pipe ELPMBAST
2
ELPMBAPS
ELPPAS1
ELPCVS1
800-463-7766
800-922-8911
www.epson.com
presentersonline.com
Printed on Recycled Paper
