10-2-8 Query about input select status

Command name : INPSEL?
Function
◇Query
Command format : INPSEL? □ ch
◇Response
Command format : INPSEL□ sys , flg
Example: INPSEL? 1 ... Inquires about the input select status of the channel A.
INPSEL 1,0 ... Input select of the unit of system address 1 is turned off.

10-2-9 Inquiry about set values

Command name : VALUE?
Function
◇Query
Command format : VALUE? □ pre , ch
◇Response
Command format : VALUE□ sys , data
NOTE: When the specified channel is in the short circuit mode, the parameter of the response is
"0".
Example: VALUE? 1,1 ... Inquires about the discharge mode set value of the channel A of the
PRESET 1 key.
VALUE 1,1.0 ...The discharge mode set value of the unit of system address 1 is 1.0 A.

10-2-10 Query about STEP value in CR mode

Command name : SVALUE?
Function
◇Query
Command format : SVALUE? □ pre , ch
: Inquires about the input select status.
ch : Channel
1: Channel A, 2: Channel B, 3: Channel C, 4: Channel D
sys : System address 1 to 32
flg : Input select status of the specified channel
0: Off, 1: On
: Inquires about the set value of each discharge mode.
pre : PRESET key
1: PRESET 1 key, 2 : PRESET 2 key, 3: PRESET 3 key, 4: PRESET 4 key
ch : Channel
1: Channel A, 2: Channel B, 3: Channel C, 4: Channel D
sys : System address 1 to 32
data : Discharge set value
Real number data. The unit is A (current), V (voltage), ? (resistance) or W
(power). A maximum of eight characters (including the decimal point).
: Inquires about the STEP value in the CR mode.
pre : PRESET key
1: PRESET 1 key, 2 : PRESET 2 key, 3: PRESET 3 key, 4: PRESET 4 key
ch : Channel
1: Channel A, 2: Channel B, 3: Channel C, 4: Channel D
