Related Manuals for FAME Pro Trigger Pack
Summary of Contents for FAME Pro Trigger Pack
- Page 1 DRU0039599-000 03/2021 Users Manual...
- Page 2 In connection with a suitable E-Drum Module - e.g. the Fame Hybrid Pro - the sound behavior and the feel of the playing remain absolutely true to nature and super realistic. At the same time, there are countless high-end sounds of all kinds available in this context, which allow phenomenal flexibility in sound design.
- Page 3 Snare / Tom Trigger with independent Trigger-Zones for Head and Rim (Dual Zone) Every Sensor made of memory foam for continual pressure Fine response and perfect dynamic range Robust and silver-satined metal shell Plastic base protects the hoop from scratches ...
- Page 4 Thanks for purchasing the Fame Pro Trigger Pack. It is especially designed to work well with the Fame Hybrid Pro Module, but Fame Triggers work also perfectly with any other regular drum module. Before you mount the trigger it is important to know, that there is no need to over tighten the trigger on the Rim: Don’t use excessive force.
- Page 6 The reason for using the rubber washer is to get the actual sensor further in towards the center resulting in a better controlled triggering. Because Kick hoops differ in size the Fame Pro Kick Trigger has a mounting screw that can be moved up and down in its groove, making it possible to find the optimal mounting position.
- Page 7 Don’t worry: The sensor sports a special spring design that allows a pressure without compromising the trigger response. When you have found the correct position, lightly tighten the kick trigger to the Hoop Do not over tighten! The rubber sleeves on the casing will keep the trigger in place.
- Page 8 Adjusting trigger settings on your Fame Hybrid Pro Module: The Fame Hybrid Pro comes with default trigger settings for pads. You will need to adjust this to be able to get the best triggering for your Fame Pro Triggers. Please note: Always double check the actual sound modules owners...
- Page 9 First check that your Fame Hybrid Pro Module is set to SAVE MODE ON. Go to MIXER-UNIT- PREF Page and change the value SAVE to ON. When this is done you shall set the actual trigger parameter. Go to MIXER-UNIT-TRIG Page. Hit a drum or change the trigger channel at CHANNEL-CHAN you like to edit.
- Page 10 Make a KIT file called FAMEPROTrigger.dkt with the special trigger settings already set in the right place. Store this file on the memory of the Fame Hybrid Pro. By pressing the MORE and MODE button on start you get a list where you can choose the Bank-File that is suitable for the occasion.
- Page 11 To reduce Crosstalk between head and rim on the snare-drum, switch the feature X-TRG in the menu MIXER-UNIT-SPEC to on. Now you’re ready to play!
- Page 12 Works perfectly together with Fame Hybrid Pro Module:...
- Page 13 If you record your drums – you can sample the sound and put these sounds into your Fame Hybrid Pro. You will get a fantastic drum sound and if you slight de-tune the digital sound from...
- Page 14 Module. Thanks to the feature of using different KIT setting files, so called Bank file, you can choose different Bank files to start with depending on the gig you do or the trigger you are using! Refer to Fame Hybrid Pro manual for description on how to do this.
- Page 15 Maintenance: Keep you triggers looking good by using a soft cloth to clean them once and a while. Never use any solvent! If you choose to dismount the triggers after the gig make sure to pack them safely to avoid destroying the sensor. ...
- Page 16 Important safety instructions! Please read before connection: CAUTION! (Electro magnetic interferences) The normal function of the product may be disturbed by Strong Electro Magnetic Interference. If so, simply reset the product to resume normal operation by following the owner‘s manual. In case the function could not resume, please use the product in other location.
- Page 17 addition, make sure that children do not remove (small) parts from the device, as they could suffocate by swallowing parts! HINT! (Installation) Always check the device for damage before using it. Ideally use the original packaging or suitable transport or storage packaging to protect the product optimally from influences such as dust or moisture, etc.
- Page 18 Due to its structural characteristics, the device is designed for indoor operation (IP20). Never expose the device to rain, moisture or liquids as this may cause damage. Vibrations, dust or solar radiation can also lead to damage, avoid them! Do not apply excessive force to the switches or controls.
- Page 19 The regulations applicable in your country must be observed! Contact & Support Do you have any questions about FAME Pro Trigger Pack or a technical problem? Please contact: Music Store professional GmbH Istanbulstr.
