04/2020 MN048014 EN
Manual
XP-503
Panel PC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP-503-10-A10-A01-1B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton XP-503-10-A10-A01-1B

Summary of Contents for Eaton XP-503-10-A10-A01-1B

  • Page 1 04/2020 MN048014 EN Manual XP-503 Panel PC...
  • Page 2 No part of this manual may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, micro-filming, recording or otherwise, without the prior written permission of Eaton Industries GmbH, Bonn. Subject to alteration.

  • Page 3: Table Of Contents

    Connecting the power supply .................... 27 Using peripheral devices ....................28 External connections ......................29 4.8.1 Ethernet connections ......................29 4.8.2 USB connections ....................... 29 4.8.3 DVI-I interface ........................30 4.8.4 Serial interfaces ........................ 31 XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 4 5.6.5 Touch parameters ......................48 5.6.6 License Eaton Galileo-Open Runtime ................50 5.6.7 License Eaton Visual Designer Runtime ................50 5.6.8 Activation / Deactivation IIS Communication for Visual Designer ........50 5.6.9 Activation / DeactivationScreensaver ................50 Operating system XP-503 with Windows 10 Enterprise LTSC ......... 51 5.7.1...
  • Page 5 Dimensions for XP-503 with 54.6 cm (21.5") display ............66 8.3.1 Front dimensions ....................... 66 8.3.2 Device dimensions ......................67 8.3.3 Fitting dimensions ......................68 General ..........................69 Directives and standards ....................73 Approvals .......................... 74 XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 6: General

    Download Center To download the documents, go to the Download Center - Documentation page by clicking on the Customer Support tab on the Eaton website and then selecting the appropriate option: Eaton.eu/doc (search for the document number using the search field on the home page) ...

  • Page 7: List Of Revisions

    11/2015 ATEX accreditation ✓ 09/2016 Marine approvals ✓ 01/2017 Additional device models ✓ 04/2018 Updates ✓ 07/2019 Updates ✓ ✓ Protect Mode 11/2019 ✓ 03/2020 Additional device models ✓ 04/2020 Windows 10 Enterprise LTSC ✓ XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 8: Description Of Device

    Intended use XP-503 panel PCs are primarily intended for use in machine and system building applications. They are suitable for use in industrial environments and are typically used for automation purposes. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 9: Device Models

    2 Description of device 2.3 Device models Device models Overview of available XP-devices Use the EATON online catalogue. By entering "XP-503" in the search field, you will be directed to this product group from the sector: Automation, Control and Visualisation. Eaton/ecat Catalog- Part no.
  • Page 10 2 Description of device 2.3 Device models Catalog- Part no. 199526 XP-503-10-A10-A00-2B 199527 XP-503-15-A10-A00-2B 199694 XP-503-10-A10-A00-2V 199695 XP-503-10-A10-A01-2B 199696 XP-503-10-A10-A01-2V 199697 XP-503-15-A10-A00-2V 199698 XP-503-15-A10-A01-2B 199699 XP-503-15-A10-A01-2V 199700 XP-503-21-A10-A00-2B 199701 XP-503-21-A10-A00-2V 199702 XP-503-21-A10-A01-2B 199703 XP-503-21-A10-A01-2V Tab. 1 Device models XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 11: Marking

    Layout of interfaces and controls  To get fast and effective support, make sure to always provide Customer Service with the following information from the nameplate: Article No. (Part No. or Art. No.)  Serial No.  XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 12: Marine Approvals

    Installation restrictions Install and commission referring to manuals • Screened communication cables improve EMC behavior • PE connection of communication cables improve EMC behavior • (e.g. earth-connection kit: EATON ZB4-102-KS1) Location class Interface Installations EMC B Power supply Place interference filter...

  • Page 13: Safety Instructions

     Read this chapter before working with the device. It contains important information regarding your own personal safety, and must be read and understood by everyone who will be working with the device. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 14: Precautionary Statements

    Indicates a situation that could result in property damage if it is not avoided.  Used to highlight useful information. The hazard symbol used and the corresponding text will provide information regarding the specific hazard and how to avoid or prevent it. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 15: Mandatory Requirements, Personnel Requirements

    Make sure that the device is connected, installed, serviced, and disposed of professionally and in line with all relevant standards and safety rules. 3.3.5 Prohibited use It is strictly prohibited to use the device in order to implement safety-relevant functions (in the sense of personal and machine protection). XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 16: Prerequisites For Proper Operation

     Improper use and/or handling  Failure to follow the instructions in this manual  Alterations, changes, and repairs to the device  For more information on repairs, please refer to chapter 6.3.1, "Repairs."  XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 17: Device-Specific Hazards

     If necessary, route an equipotential bonding conductor, with a cross-sectional area that is several times larger than that of the cable screen, parallel to the cable. XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 18 Minimum sheet thickness of control panel panel where the device will be flush  mounted: 1.5 mm. In order for the device to be properly mounted, every single one of the holding  brackets included with the delivery must be used at its intended spot. XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 19  Do not use pointy or sharp objects (e.g., knives) to clean the device.  Do not use any aggressive or abrasive cleaning products or solvents.  Make sure that no liquids get into the device (short-circuit hazard). XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 20: Installation

    When installing the XP-503, make sure to also consult the "Technical data" chapter.  The following requirements and instructions must be observed without fail in order to ensure that the XP-503 will run properly and will not be damaged. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 21: Temperature

    50 mm around the XP-503. The clearance behind it can be reduced to 20 mm if necessary. Make sure that there is enough air recirculation.  Example: XP-503-15 The following also applies to other device versions as applicable. Fig. 1 Aeration and de-aeration XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 22: Mounting Position

    The dimensions for the mounting cutout can be found in the"Fitting dimensions" section (for the relevant device) of the "Mechanical dimensions" chapter  Make sure that there is also sufficient clearance for removing the XP-503 from the mounting cutout. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 23: Fixing And Sealing

    Example: XP-503-15 The following also applies to other device versions as applicable. Device holding brackets Polyurethane foam gasket Fig. 3 Fixing and sealing XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 24 1-mm stainless steel sheet M4 x 25 DIN 914 Allen set screw, galvanized Fig. 5 Device holding bracket  When tightening the M4 x 25 DIN 914 Allen set screw with torque: 0.6 – 0.7 Nm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 25: Conditions For Marine Approval

    Integrate a radio interference suppression filter into the wiring.  Depending on the output, the following filters can be used: XT-FIL-1 radio interference suppression filter for 24-V-DC supply up to 2.2 A (Eaton article no. • 285316) or XT-FIL-2 radio interference suppression filter for 24-V-DC supply up to 12 A (Eaton article no.

  • Page 26: Preparing The Device For Operation

    Emitted interference as per EN 55022:2010 Class A and EN 61000-6-4:2007 WARNING Devices with a 24 V DC supply The device should only be run with safety extra-low voltage (functional extra-low voltage with protective separation). The power transformer must meet all applicable standards. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 27: Connecting The Power Supply

    Connecting the 24 V DC supply voltage Connection cable For the power supply connection: Copper conductor: 60° / 70°C Cross section: 0.75 – 2.5 mm² Tightening torque of 0.56 to 0.79 Nm (screws on plug section) XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 28: Using Peripheral Devices

    UL 508! The device is now ready to run on 24 VDC. Using peripheral devices With their peripheral ports, Eaton's devices make it possible to connect a variety of components. CAUTION Disturbances in EMC When using commercially available peripheral devices (e.g., with the USB port), it is...

  • Page 29: External Connections

    Bi-directional data C + DC – Bi-directional data C – LED yellow Link LED green Activity Tab. 4 Ethernet [1000 Base-T]  2 x Ethernet 4.8.2 USB connections Two 9-pole USB ports, Type A, for connecting USB peripherals. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 30: Dvi-I Interface

    Data 5 – Data 4 + Data 3 + Data 5 + DDC Clock Clock Shield DDC Data Ground (for +5V) Clock + VSYNC Hot Plug Detect Clock – Blue Ground Green HSYNC Tab. 6 DVI-I XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 31: Serial Interfaces

    One serial interface on a 9-pole SUB-D plug that can be used as an RS 232 port. SUB-D plug Signal Description Input/Output 9-pole Data Carrier Detect Receive Data Transmit Data Data Terminal Ready Signal Ground Data Set Ready Request to Send Clear To Send Ring Indicator Tab. 8 RS 232 XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 32: Commissioning And Operation

    Limitation of Liability All technical data, certifications, and approvals will cease to apply/be void if expansions other than those approved by Eaton are used. We will not assume liability for functional limitations resulting from the use of third-party devices and components.
  • Page 33 When closing the device, follow the same steps you used to open it, but in opposite order.  Note on marine approvals The gasket installed inside the enclosure cover at the factory must be present in order to provide stability against vibrations. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 34: Connecting Peripheral Devices

    Before connecting peripherals, make sure they are designed for use in industrial environments! For the ports' layout, see the nameplate on the back of the housing. The connections are standard contacts with the corresponding standard pinouts. XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 35 RJ 45 socket, 8-pole, 2 LEDs USB 3.0 Port USB Type A, 9-pole USB 3.0 Port USB Type A, 9-pole Serial interface RS 485 Sub-D plug, 9-pole Serial interface RS 232 Sub-D plug, 9-pole Tab. 9 Interfaces XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 36: Periphery

    The XP-503 can be connected to various computer networks using the two RJ45 ports that serve as Ethernet ports. Ethernet is a standard used for local networks, and requires twisted-pair cables in order to connect the computers. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 37: Using The Storage Media

    A cover must be used to protect the card from falling out. The card will come out from the bottom of the slot!  The CFast card can be inserted and changed without opening the housing. XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 38 To insert a card, push it in until you feel it lock into place. To remove a card, push on the card so that it will be released and will jump out of the chase. Fig. 12 Changing the CFast memory card XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 39: Using The Xp-503

    Make sure that the gestures you perform on the multi-touch display will be recognized by the application. It may be necessary to practice certain gestures beforehand. XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 40 Make sure that the glass panel is not damaged during installation or use. WARNING Dangerous currents when installing and connecting the device Connecting the device incorrectly may result in dangerous currents and overvoltage being produced. Always connect the protective conductor before anything else. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 41: Commissioning

    Always check to make sure that the device has recognized the operator actions  you have entered. 5.5.1 Commissioning Windows operating system  Note: Taking appropriate precautions will make it possible to prevent other malfunctions while the device is running. XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 42 Important operating functions must be programmed in such a way that they can only be triggered by gestures requiring multiple fingers on the touch panel at the same time. XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 43 If there is static contact on the touch panel during booting, this may result in functional restrictions. This can be prevented by taking the following measures: Do not touch the touch panel during booting!  If you do touch it, make sure to move your finger(s) slightly!  XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 44: Operating System Xp-503 With Windows Embedded Standard 7

    5.6.2 Protect Mode (Operated with two drives, C:\ and D:\) The Eaton XP-503 family of products running the Windows Embedded Standard 7 operating system have a unique and exclusive Protect Mode™ feature that safeguards the integrity of files stored on the C:\ drive of your operating system.
  • Page 45 C:\ drive. Once the XP-503 has been restarted, make your changes and then save the changes by selecting “StartAll ProgramsEatonProtect Mode Manager”. From the Protect Mode Manager window select the “Protect Mode Save” tab and click on the “Commit” button.
  • Page 46 C: , (Change of default password, installation of required software, change of settings ...), the Protect mode should be activated. For this please start the Protect Mode Manager under Windows " StartAll ProgramsEaton Protect Mode Manager",select the "Advanced" tab and press the "Enable Protect Mode Save"...

  • Page 47: Managing Accounts And Auto Logon Functionality

    Managing Accounts and Auto Logon functionality Managing Accounts There is an “XP503” user account with administration rights set up on your Eaton XP-503 unit when shipped from the factory. During initial power on, the user has to enter a new password for this account.

  • Page 48: Touch Parameters

    No functional restrictions if EMC interference is up to 20% higher than normal, e.g. highly EMC loaded environment through devices with electromagnetic fields Set parameters In the Windows operating system, go to “StartAll ProgramsEatonTouchParameter”.  The cmd window will open. Select the setting you want to use: ...
  • Page 49 5.6 Operating system XP-503 with Windows Embedded Standard 7 Once the program is successfully completed, the following line will appear: "Firmware update Success." The program will return to the starting screen. Select '0'.  Press the Enter key  to exit the program. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 50: License Eaton Galileo-Open Runtime

    5.6.6 License Eaton Galileo-Open Runtime XP-503 device types, which are licensed for Eaton Galileo Open Runtime, are licensed at the factory for the Galileo runtime software and enabled with 340 license points. Shipped from the factory only the license is installed on the device, the Galileo Open runtime software and the project files need to be transferred by the Galileo Development Software tools to the XP-503 (device selection Galileo Open) from the development PC.

  • Page 51: Operating System Xp-503 With Windows 10 Enterprise Ltsc

    5.7.1 Updates Eaton regularly publishes patches and updates for its products to protect them against any vulnerabilities that are discovered. Eaton encourages customers to consistently monitor the availability of new firmware updates and to install them promptly. Please check following Eaton.eu/software...
  • Page 52 C: , (Change of default password, installation of required software, change of settings ...), the Protect mode should be activated. For this please start the Protect Mode Manager under Windows " StartEaton Protect Mode Manager",select the "Advanced" tab and press the "Enable Protect Mode" button.

  • Page 53: Managing Accounts And Auto Logon Functionality

    Managing Accounts and Auto Logon functionality Managing Accounts There is an “XP503” user account with administration rights set up on your Eaton XP-503 unit when shipped from the factory. During initial power on, the user has to enter a new password for this account.

  • Page 54: Touch Parameters

    No functional restrictions if EMC interference is up to 20% higher than normal, e.g. highly EMC loaded environment through devices with electromagnetic fields Set parameters In the Windows operating system, go to “StartEatonTouch”.  The cmd window will open. Select the setting you want to use: ...
  • Page 55 5.7 Operating system XP-503 with Windows 10 Enterprise LTSC Once the program is successfully completed, the following line will appear: "Firmware update Success." The program will return to the starting screen. Select '0'.  Press the Enter key  to exit the program. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 56: License Eaton Galileo-Open Runtime

    5.7.6 License Eaton Galileo-Open Runtime XP-503 device types, which are licensed for Eaton Galileo Open Runtime, are licensed at the factory for the Galileo runtime software and enabled with 340 license points. Shipped from the factory only the license is installed on the device, the Galileo Open runtime software and the project files need to be transferred by the Galileo Development Software tools to the XP-503 (device selection Galileo Open) from the development PC.

  • Page 57: Maintenance And Repairs

    The battery in the device can be replaced. Repairs The device should only be opened by the manufacturer or by an authorized repair center. For repairs, please contact your vendor or Eaton's Technical Support. Use the original packaging to ship the device. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 58: Storage, Transport And Disposal

    When transporting or shipping the device, make sure that the device is not damaged (use appropriate packaging). All ambient conditions need to be met during transportation and shipping as well. Check the device for transit damage after arrival. XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 59: Disposal

    Substance weight 2-4 %  Electrical components Various Tab. 10 Materials used in the device Materials used in the packaging Packaging Material characteristic Outer packaging Cardboard Inner packaging Tab. 11 Materials used in the packaging XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 60: Technical Data

    8 Technical data 8.1 Dimensions for XP-503 with 25.65 cm (10.1") display Technical data Dimensions for XP-503 with 25.65 cm (10.1") display 8.1.1 Front dimensions XP-503-10-… Fig. 13 XP-503 10.1"– front dimensions in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 61: Device Dimensions

    8 Technical data 8.1 Dimensions for XP-503 with 25.65 cm (10.1") display 8.1.2 Device dimensions XP-503-10-… ISO 2768mK general tolerances Fig. 14 XP-503 10.1"– device dimensions in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 62: Fitting Dimensions

    8 Technical data 8.1 Dimensions for XP-503 with 25.65 cm (10.1") display 8.1.3 Fitting dimensions XP-503-10-… Recommended mounting cutout ISO 2768mK general tolerances Fig. 15 XP-503 10.1"– mounting cutout in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 63: Dimensions For Xp-503 With 39.6 Cm (15.6") Display

    8 Technical data 8.2 Dimensions for XP-503 with 39.6 cm (15.6") display Dimensions for XP-503 with 39.6 cm (15.6") display 8.2.1 Front dimensions XP-503-15-… Fig. 16 XP-503 15.6"– front dimensions in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 64: Device Dimensions

    8 Technical data 8.2 Dimensions for XP-503 with 39.6 cm (15.6") display 8.2.2 Device dimensions XP-503-15-… ISO 2768mK general tolerances Fig. 17 XP-503 15.6"– device dimensions in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 65: Fitting Dimensions

    8 Technical data 8.2 Dimensions for XP-503 with 39.6 cm (15.6") display 8.2.3 Fitting dimensions XP-503-15-… Recommended mounting cutout ISO 2768mK general tolerances Fig. 18 XP-503 15.6"– mounting cutout in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 66: Dimensions For Xp-503 With 54.6 Cm (21.5") Display

    8 Technical data 8.3 Dimensions for XP-503 with 54.6 cm (21.5") display Dimensions for XP-503 with 54.6 cm (21.5") display 8.3.1 Front dimensions XP-503-21-… Fig. 19 XP-503 21.5" – front dimensions in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 67: Device Dimensions

    8 Technical data 8.3 Dimensions for XP-503 with 54.6 cm (21.5") display 8.3.2 Device dimensions XP-503-21-… ISO 2768mK general tolerances Fig. 20 XP-503 21.5" – device dimensions in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 68: Fitting Dimensions

    8 Technical data 8.3 Dimensions for XP-503 with 54.6 cm (21.5") display 8.3.3 Fitting dimensions XP-503-21-… Recommended mounting cutout ISO 2768mK general tolerances Fig. 21 XP-503 21.5" – mounting cutout in mm XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 69: General

    ITO-based touch sensor Touch controller connected to computer board via USB interface Safe PCT function by using a functional earth with as low a resistance as possible: minimum cross-sectional area of 6 mm² Tab. 12 Technical data XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 70 WUXGA / 1920 x 1080 pixels Format 16:9 Viewing range [left/right/above/below] normally 89°/89°/89°/89° Color resolution 16.7 million colors Contrast ratio (Normally) normally 5000:1 Brightness normally 300 cd/m² Backlight Technology Life point 50000 h Tab. 13 Technical data XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 71 Galileo Runtime License ...-1V Windows Embedded Standard 7 Kit “P” (32-Bit) Visual Designer runtime License …-2B Windows 10 Enterprise LTSC Galileo Runtime License ...-2V Windows 10 Enterprise LTSC Visual Designer runtime License Tab. 14 Technical data XP-503 04/2020 MN048014 EN Eaton.com...
  • Page 72 -20 ºC to +60 ºC Relative humidity 10% … 90%, non-condensing Ambient air Free of corrosive gases Burn-in test 24 h burn-in [system without HDD] 48 h burn-in [system with HDD] Tab. 15 Technical data XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 73: Directives And Standards

    Explosion protection (in relation to CE), ATEX Directive 94/9 EG 2014/34/EG only type XP-503-…-A10-A01-1B Explosive atmospheres: equipment - IEC/EN 60079-0:2012 + A11:2013 general requirements Explosive atmospheres: equipment dust IEC/EN 60079-31:2014 ignition protection by enclosure «t» Tab. 16 Directives and standards XP-503 04/2020 MN048014 EN Eaton.com...

  • Page 74: Approvals

    DNV GL Marine approval Type approval – provided that a radio interference suppression filter for the device is (shipping classification) installed in the wiring Type-Approval DNVGL-CG-0339, Edition November 2015, Certificate No.: TAA00000NC Tab. 17 Aapprovals XP-503 04/2020 MN048014 EN Eaton.com...
