Lower rack Cutlery basket Upper rack Start-up and use, 7-8 Starting the dishwasher Measuring out the detergent LFZ 3284 Wash options Wash cycles, 9 Table of wash cycles Rinse aid and refined salt, 10 Measuring out the rinse aid Measuring out the refined salt...
All manuals and user guides at all-guides.com Installation Positioning and levelling see Assistance see adjacent information see the Assembly instruction sheet New Acqua Stop Connecting the water and electricity supplies see figure...
All manuals and user guides at all-guides.com Anti-condensation strip Connecting the water outlet hose After installing the dishwasher, open the door and stick the adhesive transparent strip under the wooden shelf in order to Connect the outlet hose (without bending it) to a drain duct with a minimum diameter of 4 cm.
All manuals and user guides at all-guides.com Electrical Connection As the colours of the wires in the mains lead may not correspond with the coloured markings identifying the If your appliance is supplied with a 13 amp. fused plug it can be plugged into a 13 amp socket for terminal in your plug, proceed as follows: connect Green &...
All manuals and user guides at all-guides.com Description of the appliance Overall view Upper rack Upper sprayer arm Tip-up compartments Rack height adjuster Lower rack Lower sprayer arm Cutlery basket Washing filter Salt dispenser Detergent and rinse aid dispensers Data plate Control Panel Control panel Good Night option...
All manuals and user guides at all-guides.com Loading the racks Tilt A Tilt B Tilt C After loading the appliance, check that the sprayer arms can rotate freely. Lower rack Loading examples. Adjusting the height of the upper rack The height of the upper rack should ideally be adjusted WHEN THE RACK IS EMPTY.
All manuals and user guides at all-guides.com Start-up and use Starting the dishwasher Measuring out the detergent A good wash result also depends on the correct amount of detergent being used; exceeding the stated amount ON/OFF does not result in a more effective wash and increases environmental pollution.
Page 8
All manuals and user guides at all-guides.com Half load using the upper rack Good Night option HALF LOAD Good Night Remember to load the upper rack only, and to reduce the amount of detergent accordingly. It is better to use powder detergent in this case. The Good Night option is not compatible with This option is not compatible with the following the HALF LOAD option.
All manuals and user guides at all-guides.com Wash cycles If the crockery is only lightly soiled or if it has been rinsed with water before being placed in the dishwasher, reduce the amount of detergent used accordingly. The number and type of wash cycles and options may vary depending on the dishwasher model. Detergent Wash Wash cycle...
All manuals and user guides at all-guides.com Rinse aid and refined salt Only use products which have been specifically designed for dishwashers. Do not use table salt or industrial salt, or washing up liquid. Follow the instructions given on the packaging. we recommend that you add salt, especially if you live in an area where the water is hard or very hard.
All manuals and user guides at all-guides.com Care and maintenance Clean the water inlet filter at the tap outlet regularly. - Turn off the water tap. - Unscrew the end of the water inlet hose, remove the filter and clean it carefully under running water. - Replace the filter and screw the water hose back into position.
All manuals and user guides at all-guides.com Precautions, advice and Assistance see Start-up and use General safety Phosphate-free and chlorine-free detergents containing enzymes Assistance Disposal Before contacting Assistance: see Troubleshooting Please have the following information to hand: Saving energy and respecting the see Description of the appliance environment Saving water and energy...
All manuals and user guides at all-guides.com Troubleshooting Malfunction: Possible causes / Solutions: The dishwasher does not start. • T h e p l u g h a s n o t b e e n i n s e rt e d i n t o t h e e le c t ri c a l s o c k e t p ro p e rly, o r t h e re i s n o p o we r i n t h e h o u s e .
Page 15
All manuals and user guides at all-guides.com التركيب وصل خرطوم إدخال الماء احتفظ بدليل التعليمات هذا في مكان آمن لمراجعته في المستقبل. إذا تم بيع الجهاز، إعطاؤه أو نقله، الرجاء تأكد من أن دليل التعليمات قد أرفق بالنقطة المالئمة لتوصيل المياه الباردة: قبل وصل الخرطوم، قم بتشغيل •...
Page 16
All manuals and user guides at all-guides.com *شريط مقاومة التكثيف وصل خرطوم إخراج الماء بعد تركيب ماكينة غسل األطباق، افتح الباب والصق الشريط الشفاف .الالصق تحت الرف الخشبي بهدف حمايته من أي تكثيف يمكن أن يتك و ّ ن قم بوصل خرطوم اإلخراج (من دون ثنيه) إلى قنات التسريب بواسطة قطر من...
Page 17
All manuals and user guides at all-guides.com التوصيالت الكهربائية في حال لم تتوافق ألوان األسالك في التوصيل مع مفاتيح األلوان المعرفة في التوصيالت الكهربائية :نهائيات القابس لديك، تصرف على النحو التالي إذا كان الجهاز مزودا بقابس مصهره 31 أمبير، فيمكن إدخاله إلى مقبس ”...
Page 18
All manuals and user guides at all-guides.com وصف الجهاز نظرة عامة الرف العلوي ذراع الرشاش العلوي حجرات قابلة للطي ضابط ارتفاع الرف الرف السفلي ذراع الرشاش السفلي سلة السكاكين فلتر الغسل حاوية الملح حجرات مواد التنظيف ومادة الشطف المساعدة لوحة البيانات ***لوحة...
Page 19
All manuals and user guides at all-guides.com...
Page 20
All manuals and user guides at all-guides.com بدء التشغيل واالستخدام تشغيل ماكينة غسل األطباق قياس مواد التنظيف تعتمد نتائج الغسل الجيدة أيضا على كمية مواد التنظيف الصحيحة التي .1. افتح حنفية الماء يتم استخدامها؛ تعدي كمية المواد المحددة ال ينتج عنه غسل أكثر جودة 2.
Page 21
All manuals and user guides at all-guides.com * (Good Night ) خيار ليلة سعيدة *نصف حمل باستخدام الرف العلوي .هذه اإلمكانية تقلل من كمية الضجيج الصادر عن الماكينة ويطيل مدة دورات الغسل إذا لم تكن هناك أطباق كثيرة تحتاج إلى الغسل، يمكن استخدام دورة نصف الحمل .إنه...
Page 22
All manuals and user guides at all-guides.com دورات الغسيل .للخيارات المتوفرة، الرجاء راجع جدول الخيارات في صفحة بدء التشغيل واالستخدام .يمكن لرقم ونوع دورة الغسل وكذلك الخيارات أن تتغير وفقا لطراز ماكينة غسل األطباق مواد التنظيف مدة دورة دورات الغسل A ) الحجرةA) = الغسل...
Page 23
All manuals and user guides at all-guides.com ملح التكرير ومادة الشطف المساعدة ( مثال، مستوى القساوة 1 يومض مؤشر الدورة .استخدم المنتجات المصنعة خصيصا لماكنات غسل األطباق فقط )1 سيومض مؤشر دورة الغسل ، 2 ( مستوى القساوة 2 سيضيء مؤشر الدورة .ال...
Page 24
All manuals and user guides at all-guides.com العناية والصيانة .نظف فلتر إدخال الماء الموجود على مخرج الحنفية بشكل منتظم .- أقفل حنفية الماء - فك نهائية خرطوم إدخال الماء بشكل لولبي، أزل الفلتر ونظفه بعناية تحت الماء .الجاري .- أعد الفلتر وأعد تركيب خرطوم الماء في موضعه تنظيف...
Page 25
All manuals and user guides at all-guides.com وسائل حذر، نصائح ومساعدة :• أختر دورة غسل مالئمة لنوع األواني باستخدام جدول دورات الغسل تم تصميم هذا الجهاز وتصنيعه طبقا لمواصفات األمان العالمية سارية - لألطباق ذات مستوى االتساخ العادي، استخدم دورة الغسل المفعول.
Page 26
All manuals and user guides at all-guides.com استكشاف المشاكل وحلها .إذا لم يعمل الجهاز، وقبل استدعائك للمساعدة ابحث عن حل في القائمة التالية :األسباب المحتملة/ الحلول :العطل • لم يتم إدخال القابس في المقبس الكهربائي، أو لم يتم إدخاله بما فيه الكفاية ليحدث .ماكينة...
Page 27
صفحه کنترل ،قرار دادن ظروف در قفسه ها قفسه پایین سبد مخصوص کارد و چنگال قفسه باال ،راه اندازی و استفاده LFZ 3284 33-34 راه اندازی ماشین ظرفشویی اندازه گیری مایع شستشو گزینه های شستشو ،برنامه های شستشو جدول برنامه های شستشو...
Page 28
All manuals and user guides at all-guides.com نصب وصل کردن شلنگ آب ورودی این دفترچه راهنما را برای استفاده های آتی در مکانی مطمئن نگهداری کنید. اگر ماشین ظرف شویی را می فروشید، می بخشید یا جابجا می کنید حتما ً دفترچه راهنما را داخل آن بگذارید، تا صاحب جدید بتواند از اطالعات •...
Page 29
All manuals and user guides at all-guides.com وصل کردن شلنگ آب خروجی نوار آب بندی بعد از اینکه ماشین ظرف شویی را نصب کردید، در آنرا باز کرده و نوار چسب شفاف را زیر قفسه چوبی بگذارید تا آب بندی شلنگ...
Page 30
All manuals and user guides at all-guides.com اتصاالت برق اتصاالت برق از آنجاییکه رنگ سیم های کابل اصلی شاید با کدگذاری ترمینال دوشاخه شما مطابقت نداشته باشد، به ترتیب زیر عمل اگر یک فیوز 31 آمپر همراه دستگاه است می توانید برای استفاده ً...
Page 31
All manuals and user guides at all-guides.com معرفی ماشین ظرفشوئی نمای کلی قفسه باال بازوی آب پاش باال محفظه های متحرک تنظیم کننده ارتفاع قفسه قفسه پایین بازوی آب پاش پایین سبد مخصوص کارد و چنگال فیلتر شستشو مخزن نمک مخزن...
Page 32
All manuals and user guides at all-guides.com...
Page 33
All manuals and user guides at all-guides.com راه اندازی و استفاده راه اندازی ماشین ظرفشوئی اندازه گیری مایع شستشو شستشوی خوب به استفاده از مقدار صحیح شوینده بستگی دارد؛ اگر از .شیر آب را باز کنید مقدار تعیین شده بیشتر استفاده کنید شستشوی بهتری نخواهید داشت و به (روشن/خاموش) را...
Page 34
All manuals and user guides at all-guides.com گزینه شب بخیر نصف بار با قفسه باال این گزینه صدای تولید شده توسط دستگاه را کاهش داده و مدت زمان برنامه اگر خیلی ظرف برای شستن ندارید، می توانید از برنامه نصف بار استفاده شستشو...
Page 35
All manuals and user guides at all-guides.com برنامه های شستشو .برای آگاهی از گزینه های موجود به جدول گزینه ها در صفحه راه اندازی و استفاده مراجعه کنید اگر ظروف فقط کمی کثیف شده باشند یا قبل از قرار دادن در ماشین ظرف شویی آنها را آب کشیده اید، مقدار ماده شوینده را متناسبا ً کاهش .دهید...
Page 36
All manuals and user guides at all-guides.com کمک آبکشی و نمک تصفیه شده چشمک می (چراغ نشانگر برنامه شستشوی بعنوان مثال، میزان سختی فقط از شوینده های مخصوص ماشین ظرف شوئی استفاده م ا )زند .کنید روشن و 1 (چراغ نشانگر برنامه شستشوی بعنوان...
Page 37
All manuals and user guides at all-guides.com نگهداری و مراقبت از ماشین ظرفشویی .فیلتر آب ورودی را در شیر بطور مرتب تمیز کنید .- شیر آب را ببندید - سر شلنگ آب ورودی را باز کنید، فیلتر را بردارید و با دقت زیر آب جاری .بشویید...
Page 38
All manuals and user guides at all-guides.com نکات احتیاطی، راهنمایی و کمک رسانی • برنامه شستشو را بر اساس نوع ظروفی که دارید و میزان کثیفی آنها از این ماشین ظرف شویی بر اساس استانداردهای جاری بین المللی در :جدول برنامه های شستشو انتخاب کنید زمینه...
Page 39
All manuals and user guides at all-guides.com عیب یابی .اگر ماشین ظرف شویی کار نمی کند، ابتدا و قبل از تلفن کردن به بخش کمک رسانی سعی کنید راه حل را از فهرست زیر بیابید :دالیل احتمالی / راه حل ها :مشکل...
Page 40
All manuals and user guides at all-guides.com 195074887.00 01/2009 - Xerox Fabriano...
