Part Names

Control Panel

LAMP INDICATOR
KEYSTONE
9
Adjust the vertical keystone with menu-up,
menu-down.
VOLUME + / -
1 10
Sound louder or lower.
INPUT
11
Select input source:
MENU
1 12
Display or hide the OSD main menu page.
1 13 BLANK
Blanks the projected image. If the
projector is left in blank mode for more
than 15/30/60 minutes, the projector will
automatically shut down.
AUTO
1 14
Automatically adjust the setting to match
the current input.
9
10
11
13
15
16
1 15
1 16
1 17
7
10
12
14
17
POWER INDICATOR
(POWER)
Power on / operation mode, Standby mode,
Cooling-down mode.
LAMP INDICATOR
Indicates a status in the internal projector
temperature, lamp door properly closed or
cooling down.
POWER INDICATOR
Light on or flash to indicate the operating
status of the projector.
