Summary of Contents for Ariston LGO30L
-
Page 3: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS CAUTION! 1. This manual is an integral part of the product. Keep it with care with the appliance, and hand it on to the next user/owner in case of change of property. 2. Read the instructions and warning in this manual carefully, they contain important information regarding safe installation, use and maintenance. - Page 4 13. Make sure to drain the appliance when it is out of service or in an area subject to subzero temperatures. 14. Water heated to over 50° C can cause immediate serious burns if delivered directly to the taps. Children, disabled persons and the aged are particularly at risk.
-
Page 5: General Safety Standards
Symbols: Symbol Meaning Failure to observe this warning can result in injury, which may even be fatal in certain circumstances Failure to observe this warning can result in damage or injury, even serious in certain circumstances, to property, plants and animals Observe the product's general and specific safety instructions. -
Page 6: Anti - Legionella Function
ANTI - LEGIONELLA FUNCTION Legionella are small rod shaped bacteria which are a natural constituent of all fresh waters. Legionaries’ disease is a pneumonia infectio caused by inhaling of Legionella species. Long periods of water stagnation should be avoided; it means the water heater should be used or flushed at least weekly. The European standard CEN/TR 16355 gives recommendations for good practice concerning the prevention of Legionella growth in drinking water installations but existing national regulations remain in force. -
Page 7: Description Of The Water Heater
DESCRIPTION OF THE WATER HEATER (see figure 7) F) LED A) Cap M) Adjustment knob B) Water intake pipe C) Water outlet pipe TECHNICAL CHARACTERISTICS For the technical specifications, refer to the nameplate (the nameplate is located next to the water intake/outlet pipes). Product information Model 10L Undersink... -
Page 8: Electrical Connection
ELECTRICAL CONNECTION Before performing any operations, disconnect the appliance from the electricity mains using the external switch. 1. Electrical installation must comply with SANS 10142 – Electrical code for wiring of premises and should be tested by the local electricity authority. The fixed wiring must incorporate a means of disconnecting from the main supply having a separation of at least3 mm in all poles. -
Page 9: Useful Hints
Replacing parts Disconnect the appliance from its power supply. Remove the enclosure to access the electrical equipment. To work on the thermostat, extract it from its mount and disconnect it from its power supply. To work on the heating element and anode, first drain the appliance. Use only original spare parts Scheduled maintenance The heating element (R fig. - Page 10 - the condition of the hot water pipe; - the electrical equipment. NEVER ATTEMPT TO REPAIR THE APPLIANCE YOURSELF - ALWAYS HAVE THIS DONE BY A QUALIFIED TECHNICIAN. The indicated data and specifications are not binding; the manufacturer reserves the right to modify them at his own discretion notification or replacement.
- Page 14 GARANTEE to be retained Heat Tech Geysers Heat Tech Geysers (Pty) Ltd, 294 Barolong St., Icon Park, Sunderland Ridge, South Africa T: (+27) 87 9437471 - F: (+27) 87 941 7403 - Web: www.heattech.co.za Address Town Model Serial N. Date of purchase Years of Guarantee Heattech guarantees against corrosion (leaking) the 7 This guarantees provides the free replacement of...
- Page 17 The warranty period will commence from the date of purchase or installation, failure to provide proof of this will result in the date of manufacture being used as indicated on the serial label: Whilst the product or spare parts are still under warranty, Ariston Thermo SA must be contacted for prompt assistance.
- Page 18 Ariston Thermo SA will repair or replace defective units/parts at its own discretion inclusive of labour costs during the warranty period. After repairs or replacements take place, the warranty time frame continues from the original date registered, not from the repaired or replacement date.
- Page 19 WARRANTY PROCEDURE Herewith a kind reminder to our valued customers of the Ariston/Heat Tech Warranty Procedure. 1.) Warranty periods on Ariston/Heat Tech Geysers: 5 Years on Inner Cylinder 1 Year on Electrical (Element & Thermostat) 2 Years on Safety Valve & Drain Cock 2.) Please always urge your customers to utilize qualified plumbers to do installations of...
- Page 20 The customer will be given a reference number for the incident reported. f.) Ariston/Heat Tech Service Agent will then contact the end user customer to make the necessary further arrangements. May we please ask that you distribute to, and advise your relevant staff accordingly.
- Page 21 INSTALLATION AND WARRANTY INSTRUCTIONS IT IS THE RESPONSIBILITY OF THE INSTALLER TO INFORM THE END USER OF THE INSTALLATION, MAINTENANCE & REPAIR REQUIREMENTS FOR THIS WATER HEATER IN ACCORDANCE WITH SANS 10254 AND THE MANUFACTURERS REQUIREMENTS. ALL PIPE WORK AND COMPONENTS CONNECTED TO THE INLET, OUTLET AND T&P VALVE SHOULD BE THERMALLY INSULATED FOR 2 METERS. INSTALLATION INSTRUCTIONS - PLUMBING THE THERMAL INSULATION SHALL COMPLY WITH THE REQUIREMENTS OF SANS 10252-1, SANS 10254, SANS 10400-XA AND SANS 204.
