The M210 AP is a Wi-Fi Alliance authorized Wi-Fi CERTIFIED 802.11a/b/g and 802.11n
product. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.
This Quickstart shows you how to get started using the M210 Access Point (US J9467A, WW J9468A).
After reading this Quickstart, you can visit www.hp.com/go/procurve/manuals and download the M210 Access Point Management and Configuration Guide
and other documentation.
Hardware overview
Package contents
M210, documentation, three antennas, and power supply.
Ethernet port
The M210 is equipped with an auto-sensing 10/100/1000 BaseT Ethernet port with RJ-45
connector. The port supports Power over Ethernet (PoE) 802.3af.
M210 Access Point Quickstart
Three antennas (MIMO)
Status lights (left to
right): Power, LAN,
WLAN 2.4 GHz,
WLAN 5 GHz
In
Ethernet port
Reset button
Radio and antennas
The M210 contains an 802.11a/b/g/n-compliant radio with three external dual-band antennas
(MIMO).
Reset button
Press and quickly release the button to reset the M210. To reset the M210 to factory defaults,
press the button until the status lights blink three times, then release.
Power connector
Antenna connector
Advertisement
Table of Contents
Related Manuals for HP J9467A
Summary of Contents for HP J9467A
- Page 1 The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. M210 Access Point Quickstart This Quickstart shows you how to get started using the M210 Access Point (US J9467A, WW J9468A). After reading this Quickstart, you can visit www.hp.com/go/procurve/manuals and download the M210 Access Point Management and Configuration Guide and other documentation.
- Page 2 Failure to do so may result in personal injury, fire, equipment damage, or a voided warranty. The HP ProCurve hardware warranty provides no protection against damage caused by static discharge or a lightning strike.
- Page 3 M210 Access Point Quickstart HP ProCurve Networking For drywall, it is recommended that wall anchors be used with the screws. In North America, B. Connect the cables and power on the M210 a #6 screw with matching wall anchor works well.
- Page 4 M210 by looking for its Ethernet base MAC address in the DHCP server log. For example select Connect to, and then HP ProCurve from the list of available wireless networks. after Step E.4 below, you could go to the DHCP server log to retrieve the IP address You may have to wait a short time for this wireless network name to appear in the assigned to the M210.
- Page 5 5998-0295 M210 Regulatory.book Page 1 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 HP ProCurve M210 Access Point Safety and Regulatory Information...
- Page 6 Publication Number The information contained herein is subject to change without 5998-0295 notice. The only warranties for HP products and services are set February 2010 forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
-
Page 7: Specifications
5998-0295 M210 Regulatory.book Page 1 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 HP ProCurve M210 Access Point Specifications HP ProCurve M210 Access Point (J9467A NA, J9468A WW) Electrical: For power, requires one of the following: • External power adapter module*, or •... - Page 8 Preliminary Draft06 HP ProCurve M210 Access Point External Power Adapters and Power Cords: HP ProCurve M210 Access Point (J9467A NA, J9468A WW): External Power Adapters and Power Cords: Universal External AC/DC AC Power Cords for Universal External AC/DC Power Adapter...
-
Page 9: Safety And Emc Regulatory Statements
5998-0295 M210 Regulatory.book Page 1 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Safety Information Safety and EMC Regulatory Statements Safety Information Documentation reference symbol. If the product is marked with this symbol, refer to the product documentation to get more information about the product. -
Page 10: Informations Concernant La Sécurité
5998-0295 M210 Regulatory.book Page 2 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Informations concernant la sécurité ■ This product and all interconnected equipment must be installed indoors within the same building, including all associated LAN connections as described by Environment A of the IEEE 802.3af standard. -
Page 11: Hinweise Zur Sicherheit
5998-0295 M210 Regulatory.book Page 3 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Hinweise zur Sicherheit Pour les connexions LAN : Si votre réseau local s'étend sur une zone desservie par plus d'un système de distribu- ■... - Page 12 5998-0295 M210 Regulatory.book Page 4 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Hinweise zur Sicherheit Klasse I: Es muss eine ununterbrochene Sicherheitserdung von der Hauptstromquelle bis zum Stromversorgungskabel des Produkts oder dem mitgelieferten Stromversorgungskabel vorhanden sein. Wenn es wahrscheinlich ist, dass der Schutz nicht mehr besteht, trennen Sie das Stromkabel, bis die Erdung wiederhergestellt wurde.
-
Page 13: Considerazioni Sulla Sicurezza
5998-0295 M210 Regulatory.book Page 5 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Considerazioni sulla sicurezza Considerazioni sulla sicurezza Simbolo di riferimento alla documentazione. Se il prodotto è contrassegnato da questo simbolo, fare riferimento alla documentazione sul prodotto per ulteriori informazioni su di esso. -
Page 14: Consideraciones Sobre Seguridad
5998-0295 M210 Regulatory.book Page 6 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Consideraciones sobre seguridad Manutenzione Nessun componente di questo prodotto può essere riparato dall'utente. Qualsiasi lavoro di riparazione, messa a punto, manutenzione o assistenza va effettuato esclusivamente da personale specializzato. - Page 15 5998-0295 M210 Regulatory.book Page 7 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Consideraciones sobre seguridad Para coneMxiones LAN: Si la LAN abarca un área cuyo suministro eléctrico proviene de más de una red de ■...
-
Page 16: Safety Information (Korea)
5998-0295 M210 Regulatory.book Page 8 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Safety Information (Korea) Safety Information (Korea) -
Page 17: Safety Information (China)
5998-0295 M210 Regulatory.book Page 9 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements Safety Information (China) Safety Information (China) -
Page 18: Emc Regulatory Statements
Safety and EMC Regulatory Statements EMC Regulatory Statements EMC Regulatory Statements Notice for U.S.A. Manufacturer’s FCC Declaration of Conformity Statement Product No: J9467A NA, J9468A WW FCC ID No: B94RSVLC-1001 Regulatory Model No: RSVLC-1001 Manufacturer: Hewlett-Packard Company 3000 Hanover Street... -
Page 19: Regulatory Model Identification Number
For regulatory identification purposes, this product has been assigned a Regulatory Model Number (RMN). The RMN for your product is RSVLC-1001. The RMN should not be confused with the marketing name (HP ProCurve M210 Access Point) or the Product Numbers (J9467A, J9468A). -
Page 20: Notice For Canada
This device has been designed to operate only with the antennas supplied. Use of accessory antennas not supplied with the product are strictly prohibited for use with this device. For additional Industry Canada statements, see the Management and Configuration Guide for this product, available at www.hp.com/go/procurve/manuals. 2-12... -
Page 21: Notice For European Community
95/EC and R&TTE Directive 1999/5/EC. Compliance with these directives implies conformity to harmonized European standards (European Norms) that are listed on the EU Declaration of Conformity that has been issued by HP for this device. Countries of Operation & Conditions of Use... - Page 22 All ProCurve devices are designed to be compliant with the rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to ProCurve devices, not expressly approved by HP, could void the user's authority to operate this device.
-
Page 23: Eu Declaration Of Conformity
Supplier's Name: Hewlett-Packard Company Supplier's Address: 8000 Foothills Blvd., Roseville CA 95747 U.S.A. declares, that the product Product Name and Model: ProCurve M210 Access Point, J9467A, J9468A Regulatory Model Number: RSVLC-1001 Product Options: AC Adapters: 5188-6700, 5184-5864 PoE Injector: J9407A... -
Page 24: Notice For Taiwan
5998-0295 M210 Regulatory.book Page 16 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Safety and EMC Regulatory Statements EMC Regulatory Statements Notice for Taiwan For Taiwan 5.25-5.35 (GHz) Notice for Korea 2-16... -
Page 25: Recycle Statements
5998-0295 M210 Regulatory.book Page 1 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Disposal of Waste Equipment by Users in Private Household in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. - Page 26 5998-0295 M210 Regulatory.book Page 2 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Laitteiden hävittäminen kotitalouksissa Euroopan unionin alueella Jos tuotteessa tai sen pakkauksessa on tämä merkki, tuotetta ei saa hävittää kotitalousjätteiden mukana. Tällöin hävitettävä...
- Page 27 5998-0295 M210 Regulatory.book Page 3 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Smaltimento delle apparecchiature da parte di privati nel territorio dell'Unione Europea Questo simbolo presente sul prodotto o sulla sua confezione indica che il prodotto non può essere smaltito insieme ai rifiuti domestici.
- Page 28 Para obter mais informações sobre locais que reciclam esse tipo de material, entre em contato com o escritório da HP em sua cidade, com o serviço de coleta de lixo ou com a loja em que o produto foi adquirido.
- Page 29 5998-0295 M210 Regulatory.book Page 1 Tuesday, March 9, 2010 7:37 PM Preliminary Draft06...
- Page 30 To learn more, visit www.hp.com/go/procurve/ © Copyright 2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
