CUSTOMACCES CUP0025 Mounting Instructions

Honda cmx 500/300 rebel '20- semifairing dark night

Advertisement

Quick Links

HONDA CMX 500/300 REBEL '20-
M
O
U
RE F CUP00 25
1 Person
20 min
EASY
En las revisiones del vehículo es conveniente efectuar también el mantenimiento de apriete de toda la tornillería del
semicarenado, especialmente los tornillos que fi jan éste al vehículo. Gracias por su atención.
It would be convinient to retight the semifairing screws, specially the ones that are fi xed to the motorcycle, whenever you
maintain the vehicle. Thanks for your attention.
ID
PIEZA/PART
1
2
3
4
5
6
7
8
9
10
11
12
13
V0.10/20
N
T
I
N
G
DESCRIPCIÓN
Semicarenado Dark Night
Cúpula
Soporte superior
Soporte inferior izquierdo ( • )
Soporte inferior derecho ( •• )
Tornillo Allen M5x20 Ø11 ISO 7380
Casquillo Ø8,5x Ø13 x6mm
Silentblock Ø9 xØ6 x8mm
Casquillo con valona Ø12xØ6,8x7,3
Tornillo Allen M5x16 Ø11 ISO 7380
Arandela de nylon M5x1
Tapón tornillo M5 ISO 7380
Silentblock M5
I
N
S
T
R
U
SE MIFAIR IN G DAR K N IG HT
DESCRIPTION
Dark Night semifairing
Screen
Upper Right support
Upper Left support
Lower Right support
M5x20 Ø11 ISO 7380 Allen screw
Ø8,5x Ø13 x6mm arrowhead
Ø9 xØ6 x8mm silentblock
Ø12xØ6,8x7,3 Bush with flange
M5x16 Ø11 ISO 7380 Allen screw
M5x1 nylon washer
M5 ISO 7380 screw cap
M5 silentblock
Pg. 1/3
C
T
I
O
N
S
QTY
1
1
PANTDKNH/F/NM3
1
SOP3P2S-CUP0025
1
SOP3P2ILCUP0025
1
SOP3P2IRCUP0025
2
TORNIAI7380-387
2
 CASQUI------776
6
AROPASACABLES-3
6
CASQUI-1A---750
11
TORNI-I7380-493
7
 ARNV0000000245
11
TAPON--------85
7
SILENBTM5-046/1
Illustrations and layout by: www.ciandisseny.com
ALLEN
Nº23
Nº24
Nº 6
REF
DAKNIGHT
