CUSTOMACCES SEMIFARINGS ANARCHY Mounting Instructions

Indian scout '17-/ scout bobber '17

Advertisement

Quick Links

INDIAN SCOUT '17-/ SCOUT BOBBER '17-
M
O
U
REF CUP0027
1 Person
20 min
EASY
En las revisiones del vehículo es conveniente efectuar también el mantenimiento de apriete de toda la tornillería del
semicarenado, especialmente los tornillos que fi jan éste al vehículo. Gracias por su atención
It would be convinient to retight the semifairing screws, specially the ones that are fi xed to the motorcycle, whenever you
maintain the vehicle. Thanks for your attention
ID
PIEZA/PART
1
2
3
4
5
6
7
8
9
10
11
12
13
V0.12/20
N
T
I
N
G
DESCRIPCIÓN
Semicarenado
Soporte semicarenado izquierdo
Soporte semicarenado derecho
Soporte izquierdo
Soporte derecho
Tornillo M8x45 DIN 912
Casquillo Ø10 x Ø14 x 15
Silentblock Ø9 xØ6 x8mm
Casquillo con valona Ø12xØ6,8x7,3
Tornillo Allen M5x16 Ø11 ISO 7380
Tapón tornillo M5 ISO 7380
Tornillo M5x10 DIN912 ( Negro)
Ribete autoadhesivo negro longitud 485mm Self-Autoadhesive black trim lenght 485mm
I
N
S
T
R
SEMI FAIRING ANARCHY MODEL
DESCRIPTION
Semifairing
Left semifairing support
Right semifairing support
Left support
Right support
M8x45 DIN912 screw
Ø10 x Ø14 x 15 bush
Ø9 xØ6 x8mm silentblock
Ø12xØ6,8x7,3 Bush with flange
M5x16 Ø11 ISO 7380 Allen screw
M5 ISO 7380 screw cap
M5x10 DIN912 Screw ( Black)
Pg. 1/2
U
C
T
I
O
N
.
QTY
1
1
1
1
1
2
2
4
4
4
4
4
1
Illustrations and layout by: www.ciandisseny.com
S
ALLEN
Nº23
Nº24
Nº 6
REF
ANCHYCUP
SOP4P8L1CUP0027
SOP4P8R1CUP0027
SOP4P8L2CUP0027
SOP4P8R2CUP0027
CASQUI81415-101
AROPASACABLES-3
CASQUI-1A---750
TORNI-I7380-493
TAPON--------85
PERFIL-PVC-1048
