- Page 1 Installation Guide WT-C Accumulator tanks www.thermia.com...
- Page 2 Thermia AB is not liable or bound by warranty if these instructions are not adhered to during installation or service. The English language is used for the original instructions. Other languages are a translation of the original instructions. (Directive 2006/42/EC)
- Page 3 WT-C FC (Front Connection) ........
-
Page 4: Getting Started
Installation Guide WT-C Accumulator tanks Getting started Getting started Installation The accumulator tank should stand on a solid surface and be leveled with assistance from the setscrews underneath the tank (not fitted on all models). The tank models that come without setscrews can be leveled with assistance of a shim. This must be done before the tank is connected to the pipes and filled with water. -
Page 5: Model Specifications
Installation Guide WT-C Accumulator tanks Model specifications WT-C Technical data WT-C Unit Corrosion protection, coil copper copper Storage volume V litres Volume, coil litres 4x3,5 6x3,5 Length, coil litres 4x12 6x12 Max. pressure, hot water heater Max. pressure, coil Max. immersion heater length Net weight Immersion heater max. - Page 6 Installation Guide WT-C Accumulator tanks 2.1.1 WT-C 500 Connections 1758 1 Expansion/venting (DN25) 1710 2 Connections (DN50, x8) 3 Temperature sensor (DN20, x3) 1492 4 Immersion heater (DN50) 5 Tap water coil (2x12m, Ø22mm) 1217 6 Preheat coil/tap water (2x12m, Ø22mm)
- Page 7 Installation Guide WT-C Accumulator tanks 2.1.2 WT-C 750 Connections 1831 1 Expansion/Venting (DN25) 1784 2 Heat source (DN50, x8) 3 Tap water coil (3x12m, Ø22) 1515 4 Temperature sensor (DN20, x3) 5 Immersion heater (DN50) 1240 6 Preheat coil/Tap water(3x12m, Ø22)
-
Page 8: Wt-C Fc (Front Connection)
Installation Guide WT-C Accumulator tanks WT-C FC (Front Connection) Technical data WT-C FC Unit 500 FC (3Bar) 500 FC (6Bar) 750 FC (3Bar) 750 FC (6Bar) 1000 FC (3Bar) 1000 FC (6Bar) Total volume litres Storage volume V litres 704,5... - Page 9 Installation Guide WT-C Accumulator tanks 2.2.1 WT-C 500 FC (3 bar) Connections 1765 1 Venting (DN32) 1738 2 Heat source (DN50, x4) 1505 3 Tap water coil (2x12m, Ø22mm) 1400 4 Temperature sensor (DN20, x2) 1290 5 Heat source (DN32) 6 Heat source/Immersion heater (DN50) 7 Preheat coil/Tap water (2x12m, Ø22mm)
- Page 10 Installation Guide WT-C Accumulator tanks 2.2.2 WT-C 500 FC (6 bar) Connections 1 Venting (DN32) 2 Heat source (DN50, x4) 3 Tap water coil (2x12m, Ø22mm) 4 Temperature sensor (DN20, x2) 5 Heat source (DN32) 6 Heat source/Immersion heater (DN50) 7 Preheat coil/Tap water (2x12m, Ø22mm)
- Page 11 Installation Guide WT-C Accumulator tanks 2.2.3 WT-C 750 FC (3 bar) Connections 1830 1 Venting (DN32) 1804 2 Heat source (DN50, x4) 3 Tap water coil (3x12m, Ø22mm) 1535 4 Temperature sensor (DN20, x2) 1430 5 Heat source (DN32) 1320...
- Page 12 Installation Guide WT-C Accumulator tanks 2.2.4 WT-C 750 FC (6 bar) Connections 1837 1 Venting (DN32) 1812 2 Heat source (DN50, x4) 1531 3 Tap water coil (3x12m, Ø22mm) 1501 4 Temperature sensor (DN20, x2) 1396 5 Heat source (DN32)
- Page 13 Installation Guide WT-C Accumulator tanks 2.2.5 WT-C 1000 FC (3 bar) Connections 1927 1 Venting (DN32) 2 Heat source (DN50, x4) 3 Tap water coil (4x12m, Ø22mm) 1565 4 Temperature sensor (DN20, x2) 1460 5 Heat source (DN32) 1350 6 Heat source/Immersion heater (DN50) 7 Preheat coil/Tap water (4x12m, Ø22mm)
- Page 14 Installation Guide WT-C Accumulator tanks 2.2.6 WT-C 1000 FC (6 bar) Connections 1900 1 Venting (DN32) 1875 2 Heat source (DN50, x4) 3 Tap water coil (4x12m, Ø22mm) 1570 4 Temperature sensor (DN20, x2) 1540 1435 5 Heat source (DN32)
- Page 15 Installation Guide WT-C Accumulator tanks VIBND502 Thermia AB...
- Page 16 Internet: www.thermia.com Thermia can accept no responsibility for possible errors in catalogues, brochures and other printed material. Thermia reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
