Page 5: About
About The Guia Platinum is a GPS navigation system designed by AG-NAV Inc. for aerial agricultural application. It is a state-of-the-art system developed with the combination of latest technologies in GPS, computers, wired and wireless data communications, and aerial applications.
Page 6: Support
Support For technical help, please contact AG-NAV: Phone: (800) 99 AGNAV (North America) (800) 992-4628 (705) 734-0909 (International) Email: general@agnav.com Web: https://www.agnav.com Platinum – Main Menu AG-NAV Inc.
Page 7: Notes
AG-NAV Inc. AG-NAV Inc. provides this manual “as is”, without warranty of any kind and reserves the right to make improvements an/or changes to the product described in this manual at any time and without notice.
Page 8 AG-NAV. You can also gain assistance on our web page at www.agnav.com. For further assistance, contact the AG-NAV Technical Support Line by telephone or email. AG-NAV Customer Support personnel will discuss your situation, determine the cause of problem and provide the appropriate technical assistance.
Page 9: Main Menu
Other icons shown at the top right corner of screen serve as indicators when USB key is plugged in, system gets access to internet, or GPS signals received. Pilot should always check the GPS signals before flying. Platinum – Main Menu AG-NAV Inc.
Page 10: Navigate/Training
You can use the Training to learn all functions in the Navigate module and to get yourself familiar with the Platinum operation before you fly. The guide for Navigate and Training can be found in the Guia Platinum – Navigate manual.
Page 11: File Manager
Export spray data in Shapefile format to a USB key for use in third-party software. Import a mission or job created by AgMission webapp. Make a new mission to store area files and data for your new mission. Platinum – Main Menu AG-NAV Inc.
Page 12: Tools
4.3 Tools The Tools module has the special functions for wireless data and file transfer. Remote File Transfer Mail Box Calculator Weather System Diagnosis Web Browser AgMission Platinum – Main Menu AG-NAV Inc.
Page 13: Settings
The System Settings must be done properly once after Platinum installation. Manufacturer’s defaults will not work for wireless data communications such as AgNav Link, Weather, aircraft tracking, SOS and AgMission. More instructions can be found in Chapter 7. Platinum – Main Menu AG-NAV Inc.
Page 14: Tests
Lightbars used for guidance o Boom Switches used for spray on/off o GPS Receiver for GPS data o Flow Controller (old AgFlow) o Flow Meter o Universal Flow Controllers (UFC) for both liquid and granular materials Platinum – Main Menu AG-NAV Inc.
Page 15: Main Help
Guia Platinum Main Menu. Use this manual to learn the functions in the Guia Platinum system. Note: The Navigate and Training modules have their own help for more details and instructions in navigation and application on an area.
Page 16: Turn System Off
The system will perform the closing procedure and turn off the power by itself. To avoid system file corruption, please wait until the system is off completely before switching the power supply or breaker off. Platinum – Main Menu AG-NAV Inc.
Page 17: File Manager
File Manager on the Main Menu to run the File Manager. Note that while running File Manager, do not unplug the USB key to avoid file corruption or damage to the USB key. Platinum – Main Menu AG-NAV Inc.
Page 18: Up/Down
<Down>. To change the Control Menu, push straight down on the remote keys. Down functions are used to move the cursor up and down respectively. Use the Up and Down buttons on the remote keys when you can not reach the display. Platinum – Main Menu AG-NAV Inc.
Page 19: Tag
To deselect it, just tap the item again. You can use the Right remote key to <Tag> the desired items when you can not reach the display. Platinum – Main Menu AG-NAV Inc.
Page 20: Copy
Note that even though you select only .no1, .prj or .shp files, all files (grid lines, exclusion zones, spray data files, dbf, shx, etc…) associate with the selected areas and projects will be copied as well. Platinum – Main Menu AG-NAV Inc.
Page 21: Delete Area
Note: Always make sure you have the data copied to your office computer before deleting an area. To delete areas, tag the items then tap <DelArea>. When the Confirmation dialog appears, select "Yes" to confirm or "No" to cancel the deletion. Platinum – Main Menu AG-NAV Inc.
Page 22: Delete Spray Data
Note that when using the delete functions, the deleted files are saved in the recycle basket until you choose to delete them permanently. If there are files being deleted by accident, you can go to the recycle basket to retrieve them. Platinum – Main Menu AG-NAV Inc.
Page 23: Rename
To rename, highlight the desired file then tap <Rename>. You can rename one file at a time so you don’t have to tag it. A keyboard will be shown for you to enter a new filename. Platinum – Main Menu AG-NAV Inc.
Page 24 Platinum – Main Menu AG-NAV Inc.
Page 25: Duplicate
Training. Note: Only the area file is duplicated. No spray data. To duplicate a file, highlight the file, then tap <Duplicate>. A keyboard is shown for you to enter a new filename. Platinum – Main Menu AG-NAV Inc.
Page 26 Platinum – Main Menu AG-NAV Inc.
Page 27: View
The View function is used to view the content of the selected area (no1) or project (prj) file. To do this, highlight the desired file then tap <View>. The information in the file is shown. Platinum – Main Menu AG-NAV Inc.
Page 28 You can tap <Show Polygon> to view the spray area and spray coverage if any. Platinum – Main Menu AG-NAV Inc.
Page 29: Format
Note: All files on the USB key will be erased. Make sure you do not have any files you want to keep on the USB key. To format a USB key, tap <Format>. When the Confirmation dialog appears, select "Yes" to continue or "No" to cancel the format process. Platinum – Main Menu AG-NAV Inc.
Page 30: Backup
To back up files, tap <BackUp>. When the Confirmation dialog appears, select "Yes" to continue or "No" to cancel the backup process. Note that the BackUp function will not copy files in the recycle basket. Platinum – Main Menu AG-NAV Inc.
Page 31: Clean
To clean the Platinum hard drive, tap <Clean>. When the Confirmation dialog appears, select “Yes” to continue or “No” to cancel the Clean process. Note that the Clean function also deletes all files in the recycle basket to make more space for the hard drive. Platinum – Main Menu AG-NAV Inc.
Page 32: Change Directory
Use this function to go to the "missions" folder and view the jobs or missions. Note that the jobs in this folder are normally created by the AgMission webapp. To show the list of missions, tap <missions> then tap <ChgDir>. The list of jobs or missions is shown. Platinum – Main Menu AG-NAV Inc.
Page 33 You can select a mission, for example <BARRIE_290> and tap <ChgDir> to view files in the mission. To go back one level, i.e. from files to mission folders, you can tap at the top of screen, or if missions are on the USB key. Platinum – Main Menu AG-NAV Inc.
Page 34: Export
File Manager will select all spray on data files (*spron.shp, *spron.shx, *spron.dbf), compress the files, then export the zip files to the USB key. The zip filename on the USB key will be the filename of the selected file + "_spron.zip". Platinum – Main Menu AG-NAV Inc.
Page 35 File Manager will connect with AgMission for missions upload and download. Use <ChgDir> to view the list of missions in the <missions> folder. Then select the mission you want to upload. Platinum – Main Menu AG-NAV Inc.
Page 36 Tap <Export> to upload the selected mission. A keyboard will be shown for you to enter the zip filename. You can use the same name by pressing Once the filename is entered, File Manager will export the mission and show the confirmation when done. Platinum – Main Menu AG-NAV Inc.
Page 37 USB key. In this case, you plug in the USB key before running File Manager. The Export function will make a zip file and copy it to the USB key for you to upload to AgMission later in office. Platinum – Main Menu AG-NAV Inc.
Page 38: New Mission
To make a new mission on the Platinum, tap the <missions> item on the list of files. Then tap the hard drive icon at the top right corner of the left panel to open the “missions” folder. When the list of missions shown, tap <New Mission>. Platinum – Main Menu AG-NAV Inc.
Page 39 Tap the edit box to open a virtual keyboard. Platinum – Main Menu AG-NAV Inc.
Page 40 Enter the name of the new mission, then tap Tap <OK> to accept the new name. Platinum – Main Menu AG-NAV Inc.
Page 41 To do this, tap the new mission name, then tap to open the folder. On the USB side, select the files created for the new mission and copy them to the new folder. Platinum – Main Menu AG-NAV Inc.
Page 42: Report
Google Earth. To do this, select the desired file then tap <Report> to open the Report form. Fill in the form and select the information you want to show on the report. Platinum – Main Menu AG-NAV Inc.
Page 43 Report>. When the report filename is shown, tap <OK>. Then tap <Generate The report file is shown on the list of files. Select <Copy> to copy it to the USB key. Platinum – Main Menu AG-NAV Inc.
Page 44: Recycle Basket
Recycle Basket. To do this, tap the basket icon at the bottom left corner of screen. When the Password dialogue is shown, tap on the password box. Use the virtual keyboard to enter the password. Platinum – Main Menu AG-NAV Inc.
Page 45 If the password is correct, it will be confirmed. Tap <Open> to show the items in the recycle basket. Platinum – Main Menu AG-NAV Inc.
Page 46 If you remember the date when files were deleted, check the date and select the desired folder. The deleted files in the selected folder are shown. Select the files you wish to restore. Platinum – Main Menu AG-NAV Inc.
Page 47 This should be done once per year. To remove deleted files permanently, when File Manager shows the list of folders in the All> to remove all folders then tap <Yes>. recycle basket, tap <Remove Platinum – Main Menu AG-NAV Inc.
Page 48: Exit
5.17 Exit The Exit function is used to exit the File Manager. whenever you want to exit the File Manager. Platinum – Main Menu AG-NAV Inc.
Page 49: Tools
Tools The Tools module provides the handy tools for Platinum diagnosis, simple calculator, web browser and wireless file transfer. on the Main Menu to open the Tools menu. Platinum – Main Menu AG-NAV Inc.
Page 50: Remote File Transfer
The Remote File Transfer item is used to transfer area and flight data files to office personnel or to another Guia Platinum system found in the same local network. The list of available contacts is displayed for you to select who to send the files to.
Page 51 Tap the file you want to send. o Tap <Select> to tag the file. A checkmark is tagged to the filename. o If you want to send more files, repeat the above steps to select other files. Platinum – Main Menu AG-NAV Inc.
Page 52 Tap the recipient or user shown on the Contact List that you want to send to. For example "LaiAgnav". o Tap to start the process. o Tap <Yes> to confirm you want to send files to the selected user. Platinum – Main Menu AG-NAV Inc.
Page 53 Note: For other people to send files to your Platinum, you should let them know your Login Username. They should enter your username as a contact or recipient in their Contact List. Platinum – Main Menu AG-NAV Inc.
Page 54: Mail Box
Tools menu to open the Mail Box. Tap the desired mail shown on the mail list, the files and message in that mail are shown. Platinum – Main Menu AG-NAV Inc.
Page 55 "MV_S_5758" or "BARRIE_290", select the mission name. If the files are for a new mission or new client, you can create a new mission then select the new mission name. Platinum – Main Menu AG-NAV Inc.
Page 56 Note that after downloading files successfully, you can choose to delete the mail to avoid downloading it again and make the mail list to show only new mails. To delete mail, highlight the mail that you already downloaded then tap <Delete>. Platinum – Main Menu AG-NAV Inc.
Page 57: Calculator
The Calculator item is implemented for your convenience. Use this to do simple calculation. on the Tools menu to pop up the Calculator. Tap on the keys to perform desired calculations. To exit or close the Calculator, tap <Close>. Platinum – Main Menu AG-NAV Inc.
Page 58: Weather
DarkSky. If you haven't done anything for the Weather Settings, please go to Settings → Weather API for more information. on the Tools menu to open the Weather dialogue. Tap the <Latitude> edit box. A virtual keyboard is shown. Platinum – Main Menu AG-NAV Inc.
Page 59 Tap the <Longitude> edit box and enter the Longitude coordinate. Tap <Check> to send a request for weather data. If Platinum receives a reply, it will show the weather information. o Temperature: Surface temperature in Celcius or Farenheit degrees. Platinum – Main Menu AG-NAV Inc.
Page 60 P.O.P: Precipitation of Probability, %, i.e. chance of rain. o Pressure: Atmospheric pressure in milibars. Standard pressure is 1013.25 mbars. Note: The P.O.P might not be available at all times. In this case, "N/A" is shown. Platinum – Main Menu AG-NAV Inc.
Page 61: System Diagnosis
Tools menu to view system information which include CPU, Mother and Carrier Board Temperatures, Fan Speed, Vcc, Vcore, MCU Serial, System Memory, Hard Drive, and Running Time. Platinum – Main Menu AG-NAV Inc.
Page 62: Web Browser
Tap on the <Address> box at the top of screen to enter the link or address of a web page you want to visit. to go the previous or next web page. to exit the internet. Platinum – Main Menu AG-NAV Inc.
Page 63: Agmission
USB key by using the File Manager, and upload data to AgMission manually in office. If there is no WiFi network in the spray areas, you can tap <Settings> to change the AgMission settings to not sending missions automatically. Tap <Close> to exit AgMission Status display. Platinum – Main Menu AG-NAV Inc.
Page 64: Home
6.8 Home The Home item is used to exit the Tools menu. on the Tools menu to exit and return to the Main menu. Platinum – Main Menu AG-NAV Inc.
Page 65: Settings
Settings Settings module is used to set up the Platinum system for your preference and internet access. Tap the Settings icon on the Main Menu to open the Platinum Settings menu. Platinum – Main Menu AG-NAV Inc.
Page 66: System Type
PhotoNav for photogrammetry; and FireNav for aerial fire fighting. on the Settings menu to open the System Type menu. If you want to use your Platinum for other applications, please contact AgNav for details. Platinum – Main Menu AG-NAV Inc.
Page 67: Languages
Platinum. The available languages are English, Portuguese, Spanish, and Chinese. on the Settings menu to open the Language menu. After selecting the desired language, you have to reboot the Platinum to get the language change completely. Platinum – Main Menu AG-NAV Inc.
Page 68: Date & Time
Date and Time function. You can tap to change the date and time; or tap on the calendar to select the desired date. Then tap to accept the changes and exit to the Settings menu. Platinum – Main Menu AG-NAV Inc.
Page 69: Screen
Feedback, when enabled, gives you the feedback by vibration and sound when you touch the screen. This indicates that the screen receives your touch. If you don't want to have the touch feedback, you just disable it. Platinum – Main Menu AG-NAV Inc.
Page 70: Gps
<Receiver> bar is correct. As shown in the picture, the receiver type is AgNav-P500 or P550. Tap <Connect> to initiate the communication with the GPS receiver. If the connection is successful, data received from GPS receiver will be shown on screen. Platinum – Main Menu AG-NAV Inc.
Page 71 When all GPS data is good, tap <Save> to save the configuration into GPS receiver memory. Note that if you don't tap <Save>, when the GPS receiver is powered off, the old configuration will be used. Platinum – Main Menu AG-NAV Inc.
Page 72: Wifi
After connecting to a WiFi network, you can test if internet is accessible. on the Settings menu to see a list of WiFi networks and connect to the desired one. To select a WiFi network, tap on the WiFi name to highlight it, then tap <Connect>. Platinum – Main Menu AG-NAV Inc.
Page 73 If connection is successful, the network status will show "Connected". If connection fails, a warning will be shown. <Test Internet> to test if internet is accessible. The test result will be shown on screen. Platinum – Main Menu AG-NAV Inc.
Page 74 Note that internet must be available for all wireless data transfer, weather query and aircraft tracking to work properly. Platinum – Main Menu AG-NAV Inc.
Page 75: Control Hub
The knobs can be pushed in. You can select the function for this action. For example, when pushing in the left knob, the screen will change the mode from night to day or day to night. When done, tap to accept the knob settings and exit to Settings menu. Platinum – Main Menu AG-NAV Inc.
Page 76: Agnav Link
Note that internet access must be available for AgNav Link to run properly. on the Settings menu to run AgNav Link. Before you can use the AgNav Link, please register a free account with AG-NAV. To do this, o Go to the website http://guia.agnav.com:9004/account.php...
Page 77 Enter the Password you registered for AgNav Link. Uppercase and lowercase letters must be entered correctly. o Tap <LogIn>. If the User name and Password are correct, the Status will show "Logged in as ..". Platinum – Main Menu AG-NAV Inc.
Page 78 For your laptop or computer in office, you should download and install the AgNav Link software to be able to receive and send files from/to the Platinum. You can find more instructions on the AgNav's website on how to install and use the AgNav Link. Platinum – Main Menu AG-NAV Inc.
Page 79: Weather Api
If you don't have an API key to get weather data, you can register a new key at "https://developer.forecast.io/register". Each key has 32 characters. Write down the key and enter it for the Weather API Key. Tap <Test> to test the key. Platinum – Main Menu AG-NAV Inc.
Page 80 Tap <Save> to save the Weather API settings. Platinum – Main Menu AG-NAV Inc.
Page 81: Trackernav
Internet access must be available for TrackerNav to send tracking data to the server. To set and turn on the TrackerNav feature, tap on the Settings menu. TrackerNav Service is disabled, tap to enable the service. Platinum – Main Menu AG-NAV Inc.
Page 82 TrackerNav server again. o When data is in memory, the number of tracking records is shown as "Unsent Records". You can tap <Clear Unsent Records> to delete them all if tracking data is no longer wanted. Platinum – Main Menu AG-NAV Inc.
Page 83: Sos
Do not enter the country code. Phone 1 Carrier: The carrier or service provider of mobile phone 1. • Platinum – Main Menu AG-NAV Inc.
Page 84 2: The second mobile phone number to be used for SOS message. • • Phone 2 Carrier: The carrier or service provider of mobile phone 2. Message 1: Predefined message 1, for example “SOS. Need help…”. When SOS • Platinum – Main Menu AG-NAV Inc.
Page 85 If the mobile phones don't get the message, do the following: o Check your mobile phone for number and carrier, i.e. email domain for text message. If your phone service provider is AT&T, the carrier should be "@txt.att.net". For Verizon, the carrier is "@vtext.com". Platinum – Main Menu AG-NAV Inc.
Page 86 "3214031234@txt.att.net" with some message like "Test message..." o You should receive the message on your phone. If not, contact your phone service provider and ask them to activate the text via email feature. Platinum – Main Menu AG-NAV Inc.
Page 87: Agmission
Platinum for review and report. Note that internet access must be available for data transfer between Platinum and AgMission. Before you can use the AgMission, please register an account with AG-NAV. To do this, o Go to the website https://www.agnav.com/software/ag-nav-agmission/ o Fill in the Account Registration form.
Page 88 Tap the <User name> box. A virtual keyboard pops up. o Enter User Name assigned to this Platinum. For example “c-agn12@mail.com” o Tap the <Password> box. Platinum – Main Menu AG-NAV Inc.
Page 89 Enter the Password assigned to this Platinum. Uppercase and lowercase letters must be entered correctly. o Tap <LogIn>. If the User name and Password are correct, the Status will show "Logged in ..." and the number of jobs sent to this Platinum. Platinum – Main Menu AG-NAV Inc.
Page 90 AgMission by using the File Manager. o Tap <Close> to exit AgMission settings. There are many other functions in AgMission. You can find more information and instructions in the AgMission manual. Platinum – Main Menu AG-NAV Inc.
Page 91: Tests
Tests Tests module is used to test devices connected to the Platinum. on the Main Menu to open the Tests menu. Platinum – Main Menu AG-NAV Inc.
Page 92: Communications
This test is normally done by AG-NAV's staff for hardware test and troubleshooting. on the Tests menu to run Communications test. If there is data coming in to any comports, it will be shown on screen. Normally you see GPS data scrolling on COM 2 window.
Page 93 Analog 1 and Analog 2. If an atomizer or flow sensor is connected, the pulse counts will be shown on RPM and/or counters at the bottom of screen. Tap <Exit> to exit the Communications test. Platinum – Main Menu AG-NAV Inc.
Page 94: Light Bar
If the selection is correct, the lightbar will show the same information as you see on the screen. Note that the 887-LBar is the small version of 889-LBar for mounting inside aircraft. If you have an 887-LBar, select “889 LBar” for the test. Platinum – Main Menu AG-NAV Inc.
Page 95 Pilot indicator is a 2-line LCD display. OLED Lightbar is a transparent lightbar designed for mounting inside the cockpit of aircraft. When finishing the lightbar test, tap <Close> to exit. Platinum – Main Menu AG-NAV Inc.
Page 96: Boom Switches
. If the relay circuit is closed it should turn on the pump or open the 3-way valve to turn spray on. In real flight, the auto spray mechanism will close the boom switch for spray painting on the map. Platinum – Main Menu AG-NAV Inc.
Page 97 If the relay circuit is open , it should turn off the pump or close the 3-way valve to recirculate liquid to the tank. Platinum – Main Menu AG-NAV Inc.
Page 98: Gps
GPGGA and GPVTG. If no data is shown, there must be a problem with the GPS receiver or data communications. If connection fails, check and make sure the right type of receiver is selected. Platinum – Main Menu AG-NAV Inc.
Page 99: Flow Controller
If you need to adjust the calibration code, tap <Pulses/Liter> then enter the desired value. Then tap <Update Pulses/Liter> to save the new Pulses/Liter (PPL) value to the flow controller memory. Note that you change the PPL when the flow controller works Platinum – Main Menu AG-NAV Inc.
Page 100 If you do calibration 3 times, calculate the average PPL. If the PPL is good, tap <Pulses/Liter> then enter the desired PPL. Then tap <Update Pulses/Liter> to set and save the PPL to the flow controller. When the test is done, tap <Exit> to exit the flow controller test. Platinum – Main Menu AG-NAV Inc.
Page 101: Ag-Flow Meter
PPL. If the actual amount was less than the displayed amount, you should increase PPL. Calibration: To calibrate the flow sensor, do the following: o Tap <Unit > to set the unit "Met" or "US". Platinum – Main Menu AG-NAV Inc.
Page 102 If you do calibration 3 times, calculate the average PPL. If the PPL is good, tap <Pulses Per Liter> then enter the desired PPL. Then tap <Save> to save the PPL to the Platinum settings. Platinum – Main Menu AG-NAV Inc.
Page 103: Ufc
Tests menu. • System Information: Shows the information currently in the memory of UFC. For example if "AgNav Dual Valve" flow controller is currently used, the following or similar information will be shown: Platinum – Main Menu AG-NAV Inc.
Page 104 ULV: Test ultra low volume flow controller. AgNav Flow: Test liquid flow controller. • AgNav Dual Valve: Test dual valve flow controller. • • AgNav Hatfield RGate: Test Hatfield rotary gate controller. • AgNav Bucket: Test IMS bucket flow controller. Platinum – Main Menu AG-NAV Inc.
Page 105: Granular Fc
Material: Shows the material used last time. Tap to change the name. You can enter a new material for calibration. To do this, o Touch and hold the Material bar for 2 seconds. The list of material names is shown. Platinum – Main Menu AG-NAV Inc.
Page 106 Tap <Add>. o When the keyboard appears, enter the new material name, for example "Bti-corncob". When done, the material name is added to the list. o Tap <OK> to select the new material name. Platinum – Main Menu AG-NAV Inc.
Page 107 > and enter the calibration RPM. If the material is light like Bti and application rate high, you can start with RPM=20. This is the estimated minimum RPM. If the material is heavy like clay and/or application rate low, you can start at Platinum – Main Menu AG-NAV Inc.
Page 108 When the motor stops, weigh the bag or container with material. This is the gross weight. As an example, the weight is 10.5 lbs. o Tap <Gross Weight: > and enter the weight. Remember you can tap and hold the bar to pop up the keyboard. Platinum – Main Menu AG-NAV Inc.
Page 109 RPM will be 40, 60, 80, 100, 120, 140 and 160. If the material is heavy and/or application rate low, you can increase RPM by 10 up to 65. Platinum – Main Menu AG-NAV Inc.
Page 110 Repeat a whole procedure for motor 2. o When you finish calibration for both motors, calculate the average revs/lb or revs/kg for each RPM used during the calibration. For example, if you get revs/lb = 3.51, Platinum – Main Menu AG-NAV Inc.
Page 111 3.55, 3.45 for RPM = 100, the average revs/lb will be 3.50. o Find the threshold RPM at which revs/lb remained about the same or changed very little when increasing RPM. o Tap <Calib Parameters>. Platinum – Main Menu AG-NAV Inc.
Page 112 The default value is 0.5. To view or change the Tank Empty current, o Tap <UFC Extra Parameters> bar. The Tank Empty Current Offset show the Tank Empty currents for motor 1 and motor 2. Platinum – Main Menu AG-NAV Inc.
Page 113 Tap <Exit> to exit the UFC Extra Parameters view. Note that if you have a Tank Empty sensor attached to the Isolair tank, you don't have to set the current for Tank Empty detection. Platinum – Main Menu AG-NAV Inc.
Page 114: E-Motor Fc
PPL should be the manufacturer default, for example 165. Calibration Volume: This defines the volume of liquid material used for flow sensor • calibration. It should be enough to run for at least one minute. For example, if the Platinum – Main Menu AG-NAV Inc.
Page 115 • Save: When calibration was done and you are happy with the PPL value, tap <Save> to save the new PPL to the flow controller memory. This PPL will be used for your spray missions. Platinum – Main Menu AG-NAV Inc.
Page 116 Note that if you don't tap <Save>, the old PPL will be used. Platinum – Main Menu AG-NAV Inc.
Page 117: Ulv Fc
8.10 ULV FC To run Ultra Low Volume (ULV) flow controller test, tap <AgNav ULV> on the UFC Test menu . <Connect ULV> to initiate the communication between Platinum and flow controller. Platinum – Main Menu AG-NAV Inc.
Page 118 It should be enough to run for at least one minute. For example, if the target LPM is 4.0, the calibration volume should be 4.0 liters or more for precise calibration. • Flow Sensor Type: This defines the range of flow rates the flow sensor was Platinum – Main Menu AG-NAV Inc.
Page 119 • Save: When calibration was done and you are happy with the PPL value, tap <Save> to save the new PPL to the flow controller memory. This PPL will be used for your ULV missions. Platinum – Main Menu AG-NAV Inc.
Page 120 You can calibrate the sensor for all materials you're going to spray. Just write down the PPL for each material. When changing material for different mission, remember to change PPL and save it to the flow controller memory again. Platinum – Main Menu AG-NAV Inc.
Page 121: Agflow Ufc
Tap <Connect> to initiate the communication between Platinum and flow controller. To change a value or option, you can tap on the selected bar. You can change the units to US measurement units, i.e. gallons, GPM, by tapping the <Unit: Met> bar. Platinum – Main Menu AG-NAV Inc.
Page 122 PPL should be the manufacturer default, for example 165. • Calibration Volume: This defines the volume of liquid material used for flow sensor calibration. It should be enough to run for at least one minute. Platinum – Main Menu AG-NAV Inc.
Page 123 3-way valve, you can run the pump to pump liquid to the flow sensor. The program will count the pulses and calculate new PPL based on the total pulses and calibration volume. • Stop Calibration: You can stop the calibration at any time by tapping <Stop Calibration>. Platinum – Main Menu AG-NAV Inc.
Page 124 • Save: When calibration was done and you are happy with the PPL value, tap <Save> to save the new PPL to the flow controller memory. This PPL will be used for your spray missions. Note that if you don't tap <Save>, the old PPL will be used. Platinum – Main Menu AG-NAV Inc.
Page 125: Dual Valve Fc
(PPL): This is the calibration value of the flow sensor. Regardless • of unit selection, PPL is always the number of pulses per liter. For the first calibration, PPL should be the manufacturer default, for example 165. Platinum – Main Menu AG-NAV Inc.
Page 126 • Save: When calibration was done and you are happy with the PPL values, tap <Save> to save the new PPL to the flow controller memory. This PPL values will be used for your spray missions. Platinum – Main Menu AG-NAV Inc.
Page 127: Hatfield Rgate
RPM. The way to calibrate the Hatfield RGate is similar to the calibration of AgNav granular FC for motor 1. Please refer to the Granular FC section for Platinum – Main Menu AG-NAV Inc.
Page 128: Bucket Fc
To run bucket flow controller test, tap <AgNav Bucket> on the UFC Test menu . Tap <Connect> to initiate the communication between Platinum and flow controller. Platinum – Main Menu AG-NAV Inc.
Page 129 Lump: To remove a hard lump stuck in the dispenser. Note that when the • dispenser is jammed, the Platinum will turn off the motor to avoid damages. You can use this function to remove the lump stuck in the dispenser. Platinum – Main Menu AG-NAV Inc.
Page 130: Main Help
Main Help When you need help, tap the Help button on the Main Menu. Platinum – Main Menu AG-NAV Inc.
Page 131: About
TraxNav is for animal tracking and baiting. PhotoNav is navigation for photogrammetry. FireNav is navigation for aerial fire attack. Please contact AgNav if you need special software to run on your Platinum system. Platinum – Main Menu AG-NAV Inc.
Page 132: Software Update
Platinum from AgNav's website. Unzip the file to a USB key to make the update key. If you want to update the Platinum software, plug in the update key then tap the Help menu. • Tap <Update from USB key>. Platinum – Main Menu AG-NAV Inc.
Page 133 • Tap <Start Update>. The Platinum will read the update file and show the version number and the changes in this version. Platinum – Main Menu AG-NAV Inc.
Page 134: Remote Troubleshooting
AgNav's website and update the software directly. 9.3 Remote Troubleshooting With Remote TroubleShooting, AG-NAV Staff can get access to your Platinum to troubleshoot the system remotely. Use this when your system has a problem or when you want to learn a function in the Platinum.
Page 135: User Manual
Write down the ID number and leave the system alone. Phone and tell AG-NAV the ID number. When troubleshooting or training has finished, tap <Close> to close Remote Troubleshooting. 9.4 User Manual User Manual is the online help to provide quick help to pilot.
Page 136: Turn System Off
The system will perform the closing procedure and shut down by itself. To avoid corrupting system files, please wait until the system is powered off completely before switching the power supply or breaker off. Platinum – Main Menu AG-NAV Inc.
