AUTOMATIC TARGET FLOW SYSTEM II (AUTO BOOMS)
INSTALLATION MANUAL
Part No: MN-ATF-2 REV: A
AG-NAV Inc. 1-800-99 AGNAV (24628)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MN-ATF-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AG-NAV MN-ATF-2

  • Page 1 AUTOMATIC TARGET FLOW SYSTEM II (AUTO BOOMS) INSTALLATION MANUAL Part No: MN-ATF-2 REV: A AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 2 AG-NAV Inc. AG-NAV Inc. provides this manual “as is”, without warranty of any kind and reserves the right to make improvements and/or changes to the product described in this manual at any time and without notice.
  • Page 3 NAV. You can also gain assistance through the user’s area on our web page at www.agnav.com. For further assistance, contact the AG-NAV technical support line by telephone, fax, or email. AGNAV customer support personnel will discuss your situation, determine the cause of problem and provide the appropriate technical assistance.
  • Page 4: Table Of Contents

    Table of Contents 1. Getting Started: ………………………………………………… About the Ag-Nav Automatic Target Flow II Component List Before Installation 2. System Overview: ………………………………………………. How the system works Function of the 3 position Auto / Manual switch Function of the 3 position Run / Dump switch 3.
  • Page 5: Getting Started

    1: Getting Started About Ag-Nav Automatic Target Flow II The Ag-Nav Automatic Target Flow II is the next step of integrating today’s advanced technology into the world of aerial application. The automatic target flow II allows for worry free automatic boom control. The automatic target flow II system accurately turns on and off the spray system at the exact boundary of the desired application area, eliminating spraying outside or too far inside the area.
  • Page 6: Before Installation

    Component List Before Installation Before you begin installation, please make sure to carefully read the installation instructions. If any questions arise, please contact Ag-Nav customer support. Contact information is located on page 3 of this manual. 2. System Overview How the system works...
  • Page 7: Function Of The 3 Position Run / Dump Switch

    (Figure 1.0.1). Please keep in mind that the valve motor can be installed in an upward or downward position. The new 3-way valve should directly replace the existing manual 3-way valve on common agricultural aircraft. AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 8 Automatic Target Flow II System Diagram Figure 1.0.1 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 9: Determining The Position Of The Valve

    New hose clamps should be used to avoid any possible leaks from the 3-way valve. Please note that some smaller 1.5” valve (AAP8285) will not include a camlock port as they have a regular barbed end. 3-way Valve Ports Figure 1.0.2 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 10: 3-Way Valve Suck Back Adjustment

    1. Install inside the aircraft. 2. Install in an area free of high moisture levels. 3. Install away from major heat sources such as an engine or exhaust manifold. 4. Use all mounting holes to fasten box. AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 11: Fastening The Control Box

    1. Locate suitable area to mount the switch. 2. Drill hole per specification in figure 1.0.5 3. Install 3-way switch 4. Label the Panel with the following modes: Automatic / Manual AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 12: Installing 3-Way Run / Dump Switch

    5. Locate suitable area to mount the switch. 6. Drill hole per specification in figure 1.0.5 7. Install 3-way switch 8. Label the Panel with the following modes: Run/Off/Dump 3-Way Switch Hole Dimensions Figure 1.0.5 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 13: Installing The Autobooms Controller Wiring Harness

    Auto-booms controller to the Platinum System. See Figure 1.0.8 for how to connect the Auto-booms controller to the Guia system. Please solder and heat shrink the connection points or use aviation approved butt splice self- insulated connectors. AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 14 Automatic Target Flow II Harness Diagram / Platinum Connection AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 15 Figure 1.0.7 Automatic Target Flow II Harness Diagram / Guia Connection AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 16: Testing Procedure

    *** Tie up all lose wires and secure to airframe *** Label switch functions on aircraft front panel *** Label the dedicated 5A circuit breaker Once these checks have been completed, the system is ready for operation. AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 17: Maintenance

    Please Contact AGNAV if this is occurring. Just like any ball valve, the Ag-Nav 3-way valve does contain valve seals which will wear over time. A seal replacement kit can be purchased along instructions on how to rebuild the valve.
  • Page 18: System Specifications

    7 System Specification 2” Three Way Valve Dimensions and Weight 2” 3-Way Valve Parts list Figure 1.0.8 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 19 Exploded 2” 3-Way Valve Figure 1.0.9 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 20: 2" 3-Way Valve Dimensions And Weight

    2” 3-Way Valve Dimensions and Weight Figure 1.1.0 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 21 1.5” Three Way Valve Dimensions and Weight 1.5” 3-Way Valve Parts List AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 22 Figure 1.1.1 Exploded 1.5” 3-Way Figure 1.1.2 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 23: 3-Way Valve Dimension And Weight

    1.5” 3-Way Valve Dimensions and Weight Figure 1.1.3 AG-NAV Inc. 1-800-99 AGNAV (24628)
  • Page 24: Aap193 Controller Dimension And Weight

    AAP193 controller Dimensions and Weight Auto Boom Controller Dimensions and Weight Figure 1.1.4 AG-NAV Inc. 1-800-99 AGNAV (24628)
