CHILD BOOSTER SEAT
Instructions for Installation & Use
Series No. BL4050/A/2013
IMPORTANT:
KEEP THIS BOOK IN THE PLACE PROVIDED ON THE CHILD RESTRAINT

Advertisement

loading
Need help?

Need help?

Do you have a question about the BL4050/A/2013 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BabyLove BL4050/A/2013

Summary of Contents for BabyLove BL4050/A/2013

  • Page 1 CHILD BOOSTER SEAT Instructions for Installation & Use Series No. BL4050/A/2013 IMPORTANT: KEEP THIS BOOK IN THE PLACE PROVIDED ON THE CHILD RESTRAINT...
  • Page 2 SEATBELT QUICK SETUP...
  • Page 3 SEATBELT QUICK SETUP...
  • Page 4 INTRODUCTION To be used with a lap-sash seatbelt by a child whose shoulders are above the lower shoulder height marker (approximately 4 years of age) until the child’s shoulders reach the upper shoulder height marker (approximately 6 to 8 years of age). Continue to use this booster seat until the child reaches this limit.
  • Page 5 INTRODUCTION Được sử dụng với dây nịt an toàn quàng qua vai của em nào có vai ở trên vạch ghi độ cao của vai ở dưới cùng (khoảng 4 tuổi) cho đến khi vai của em cao tới vạch ghi độ...
  • Page 6 INTRODUCTION 應與安全腰帶一同使用，適用於肩膀超過靠下的肩高標記的孩子（大約4歲大），直 至其肩膀達到靠上的肩高標記（大約6至8歲大）。 讓您的孩子一直乘坐墊高椅，直至其達到墊高椅的上限。在孩子肩膀達到墊高椅靠 上的肩高度標記之前，使用墊高椅是最安全的做法。 在孩子肩膀超過靠下的肩高標記前，切勿使用此墊高椅。 若孩子在汽車座椅邊無法自然曲膝，請繼續使用墊高椅。 孩子因長大超出墊高椅的上限時，不推薦僅僅使用安全帶。請使用更大尺寸的墊高 椅。# Debe utilizarse con un cinturón de seguridad de tres puntos para un niño cuyos hombros sobrepasen el marcador de altura inferior (aproximadamente a los 4 años de edad) hasta que los hombros del niño alcancen el marcador de altura superior (aproximadamente de 6 a 8 años de edad).
  • Page 7 INTRODUCTION Da usare con una cintura di sicurezza fasciante da un bambino le cui spalle superano il marcatore di altezza inferiore (circa 4 anni di età) fino a quando le spalle del bambino raggiungono il marcatore di altezza della spalla superiore (circa 6 a 8 anni di età). Continuare a utilizzare questo seggiolino fino a quando il bambino raggiunge questo limite.
  • Page 8 INTRODUCTION Carefully read all the instructions for installation. If in doubt about the method of installation, consult Babylove or agent or a child restraint fitter or, in New Zealand, consult the agent for the vehicle. THIS RESTRAINT MUST BE USED IN CARS WITH FORWARD-FACING SEATS WITH A LAP-SASH SEATBELT.
  • Page 9 INDEX PAGE WARNINGS SHOULDER HEIGHT MARKERS AND A GROWING CHILD SHOULDER HEIGHT MARKERS SHOULDER HEIGHT MARKERS AND THE NEXT STEP FEATURES HOW TO SETUP HOW TO USE CARE AND MAINTENANCE ACCESSORIES IN CASE OF CRASH...
  • Page 10 • Use the restraint exactly as shown in the instructions. • Supervision of children is needed because they may be able to undo the buckles. • DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR. • Do not alter or modify this restraint. •...
  • Page 11 IMPORTANT : • The restraint should not be purchased or sold as a second hand item. It is recommended not to use child restraints older than 10 years as the protection in an accident may be reduced. • Seatbelt extenders are not recommended to be used if the seatbelt is not long enough to secure the child restraint.
  • Page 12 SHOULDER HEIGHT MARKERS AND A GROWING CHILD Label B Label A Height label will be behind the child’s neck. SMALLER CHILD Shoulders must not be below the Lower Label A Shoulder Height Marker. From approximately 4 years of age. Front of Vehicle TALLER CHILD Shoulders must not be above the Upper Label B...

  • Page 13: Shoulder Height Markers

    SHOULDER HEIGHT MARKERS IMPORTANT: Follow this advice. LOWER SHOULDER HEIGHT MARKER : Label A The child’s shoulders must be in-line or above this marker. Approximately 4 years of age. If the child’s shoulders are below then the child should remain in their previous child restraint.
  • Page 14 SHOULDER HEIGHT MARKERS AND AND THE NEXT STEP NEXT TYPE OF RESTRAINT THAT CAN BE USED IN THE CAR FOR YOUR CHILD. When your child has outgrown the seat, you can then use either restraint methods as follows: Just the car's lap-sash seatbelt. Lower leg must hang over the edge of the seat cushion.
  • Page 15 FEATURES Shoulder Height Markers Front of Vehicle Car seatbelt Padded cover for comfort BOOSTER SEATBELT PATH label (each side, for lap belt) BeltRight™Guide Sash Guide BOOSTER SEATBELT PATH label (each side, for sash belt)

  • Page 16: How To Set Up

    HOW TO SETUP UNFOLDING THE BOOSTER SEAT If the seat is in a folded position, grip the Booster seat back and seat base and unfold till you hear it lock into position. Check that the seat has locked into position. CAUTION: DO NOT PLACE FINGERS IN BETWEEN SEAT BACK &...
  • Page 17 HOW TO SETUP ADJUSTING THE BELTRIGHT™ GUIDE The crotch strap can be adjusted so that it fits the seatbelt correctly to the child. The crotch strap length adjuster can be found under the seat. A. Adjust the crotch straps for the BeltRight™guide so that the Lap portion of the seatbelt is sitting on the child's thighs and the clip prevents the lap belt rising on the abdomen.
  • Page 18 HOW TO SETUP ADJUSTING THE SASH GUIDE POSITION A. The sash guide needs to be positioned in-line with or just above the child's shoulders. Sash guide B. Remove trim at the top rear of the restraint, then pull the cover forward to reveal the Sash guide which is attached to a strap at the back of the seat cover.
  • Page 19 HOW TO SETUP The sash guide should be used to correctly To Lengthen position the sash portion of the lap-sash seatbelt across the child's shoulder and Hold the strap, chest. rotate and pull the sash guide Feed the adjusting strap into the slot on to lengthen the cover that is just below the child's shoulder.

  • Page 20: How To Use

    HOW TO USE WITH LAP-SASH Seatbelt A. Place the booster seat in the desired seating position. B. Seat the child in the seat. The child's shoulders must be between the lower and upper shoulder height markers. C. Pull the seatbelt out fully and place the lap belt over the child's hips and thighs, BOOSTER SEATBELT PATH across the red label, engage seatbelt buckle...
  • Page 21 HOW TO USE D. Feed the sash-belt across the child's chest and through the sash guide. The sash guide should be used to correctly position the sash portion of the lap-sash seat over the child’s shoulder and across the chest. Continue to adjust the height of the sash guide so that the guide is above the child’s shoulder as the child grows.
  • Page 22 HOW TO USE E. Hook the BeltRight™guide over the lap part of the seatbelt with the lap belt positing logo facing forward. The BeltRight™guide must be used at all times to prevent the child slumping (sliding forward at base of seat) as the lap belt on the abdomen is dangerous in the event of a crash.
  • Page 23 HOW TO USE G. The seatbelt must fit firmly but comfortably across the lap and chest. If needed, adjust the vehicle seat to improve the position of the sash on the child’s chest. It should pull to the rear of the child. H.
  • Page 24 HOW TO USE WARNING: A SASH BELT UNDER THE ARM OR BEHIND THE BACK IS DANGEROUS SEATBELT UNDER SEATBELT BEHIND THE ARM THE BACK IS DANGEROUS IS DANGEROUS NOTE: Seatbelt extenders Seatbelt fitting closely should not be used if the across the chest and seatbelt is not long enough to through the sash guide...

  • Page 25: Care And Maintenance

    Washing and care instructions are on the care label attached to the cover. Refer to the following pages for instructions on how to remove and replace the cover. VERY IMPORTANT: Only replace the cover with Babylove supplied replacement cover with identical shoulder height markers or a replacement cover meeting AS/NZS 8005.
  • Page 26 CARE & MAINTENANCE TO REMOVE COVER 1. To remove the main cover unclip clips (B and C) located at the lower back of the seat. Lift and peel away A from seat. 2. To remove the base cover unclip clips (D) and feed BeltRight™guide (E) through the cover and peel away from seat.
  • Page 27 ACCESSORIES MESSY MAT™ (IF SUPPLIED) Place ribbed or pocket end of the Messy Mat seat protector on edge of car seat, smooth back toward seat join (’A’) and fit in any excess Messy Mat into the join of the car seat (’A’). Hook and loop attachment referred in some Short Messy Mat instruction books, are no longer required to fit this...

  • Page 28: In Case Of Crash

    IN CASE OF CRASH If your restraint has been involved in a severe crash, you should destroy the restraint even if no damage is obvious. Some insurance companies offer vehicle insurance which covers or partially covers the replacement of your child restraint. Contact your insurance company for further details.
  • Page 32 We reserve the right to alter this product without notice in our constant endeavor for improvement. ©2014 Nursery Elegance Pty. Ltd. Babylove, EzyMove and BeltRight Trademarks are the property of Nursery Elegance Pty Ltd. P/No. 2201782/B...
