Epson Stylus Photo R260 Supplementary Manual

Epson Stylus Photo R260 Supplementary Manual

Epson stylus photo r260: supplementary guide
Hide thumbs Also See for Stylus Photo R260:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual

Printer Parts

Sheet feeder
Paper
support
Left edge
guide
EXT. I/F
USB port
Power button
Ink button
Right edge guide
Printer cover
Front tray
Front cover
Front tray extensions
Tray lever
USB port
Cartridge
cover
Power light
Ink light
Paper out light
Paper button
CD/DVD tray
Accessories

Ink Cartridges

Cartridge
Black
Cyan
Magenta
Yellow
Light Cyan
Light Magenta
High-Capacity Black
High-Capacity Cyan
High-Capacity Magenta
High-Capacity Yellow
High-Capacity Light Cyan
High-Capacity Light Magenta
Caution: To ensure good results, use genuine Epson cartridges
and do not refill them. Other products may cause damage to your
printer not covered by Epson's warranties.
Don't use an ink cartridge beyond the expiration date on the
package.
Note: Try the High Capacity 77 cartridges available at
http://www.epson.com/highcapacity (U.S. sales) or
http://www.epson.ca (Canadian sales).
9/06
Epson Stylus Photo R260
Part number
78 (T078120)
78 (T078220)
78 (T078320)
78 (T078420)
78 (T078520)
78 (T078620)
77 (T077120)
77 (T077220)
77 (T077320)
77 (T077420)
77 (T077520)
77 (T077620)
Epson Stylus Photo R260
- 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stylus Photo R260 and is the answer not in the manual?

Questions and answers

Related Manuals for Epson Stylus Photo R260

Summary of Contents for Epson Stylus Photo R260

  • Page 1: Printer Parts

    Tray lever High-Capacity Yellow High-Capacity Light Cyan High-Capacity Light Magenta Caution: To ensure good results, use genuine Epson cartridges and do not refill them. Other products may cause damage to your printer not covered by Epson’s warranties. USB port Don’t use an ink cartridge beyond the expiration date on the package.

  • Page 2: Printer Specifications

    Ink thaws and is usable after approximately 3 hours at 77 °F (25 °C) S041405 Caution: To ensure the best results, use genuine Epson cartridges and do not refill them. Other products may cause damage to your printer not covered by Epson’s warranties. Don’t use an ink cartridge beyond the expiration date on the package.

  • Page 3: Safety Approvals

    Letter Pattern Sleep mode Approx. 1.1 W Power off Approx. 0.2 W mode Check the label on the back of the printer for its voltage. Environmental Temperature Operation 50 to 95 °F (10 to 35 °C) Storage –4 to 104 °F (–20 to 40 °C) 1 month at 104 °F (40 °C)

  • Page 4: Control Panel

    Turn the printer back on again. If the lights are still flashing, contact your dealer or Epson as described in your on-screen User’s Guide or Printer Basics book. Epson Stylus Photo R260...

  • Page 5: Removing And Installing Ink Cartridges

    If you remove a cartridge that is low (for which you have received an “Ink low” message), you cannot reuse it. 1. Make sure the CD/DVD tray is not inserted in the printer, and make sure the front tray is in the paper (lower) position.
  • Page 6 If you have installed an ink cartridge without removing the yellow tape, take the cartridge out of the printer, remove the yellow tape, and then reinstall it. Do not remove the transparent seal from the bottom of the cartridge;...

  • Page 7: Selecting The Paper Type Setting

    11. Close the cartridge cover. 12. Close the printer cover and press the H ink button. The printer begins charging the ink delivery system. The green P power light flashes and the printer makes noise. Charging takes about one and a half minutes. When it’s finished, the green P power light stops flashing and...

  • Page 8: Paper Loading Guidelines

    Your printer includes a special tray that lets you print customized text, graphics, and photos directly on any ink jet- printable CD or DVD. The Epson Print CD software makes it easy to import your own photos, add text, and modify your designs with a variety of special effects.

  • Page 9: Designing Cds And Dvds

    Epson Print CD. Designing CDs and DVDs You can use the Epson Print CD program (included on the Printer Software CD-ROM) to create and print a design with images, graphics, and text. See your on-screen User’s Guide or Printer Basics book for instructions.

  • Page 10: Cleaning The Print Head

    H ink light is off.) Before you clean the print head, make sure the CD/DVD tray is not inserted in the printer, and make sure the front tray is in the paper (lower) position. If it is not, lift the tray lever up to reposition the front tray.

  • Page 11: Running The Head Cleaning Utility

    Before you align the print head, make sure the CD/DVD tray is not inserted in the printer, and make sure the front tray is in the paper (lower) position. If it is not, lift the tray lever up to reposition the front tray.

  • Page 12: Cleaning The Printer

    Keep the printer cover closed to prevent water from getting inside. 4. If ink accidentally gets inside of the printer, wipe it off with a damp cloth in the area shown. Clean here Warning: Don’t touch the gears or any other parts inside the...

  • Page 13: Transporting The Printer

    Keep the printer level as you transport it. After transporting the printer, remove the tape securing the print head. Then plug in your printer, turn it on, and test it. If you notice a decline in print quality, clean the print head (see page 10);...
