- Page 1 Part Number: MCU025 Battery Charger Manual For your personal safety read, understand and follow the information provided in this instruction manual.
-
Page 2: Important Safety Instructions
Important Safety Instructions WARNING! To avoid any personal injury, please read the safety instructions below. This battery charger is not intended for use by children or infirm persons without supervision. • The ACID/FLUID within a battery is highly corrosive and poisonous. It can produce flammable and toxic gases when recharged and will explode if ignited, When working with batteries, always wear eye protection, remove jewellery and ensure the area is well ventilated. - Page 3 Key Charger Features The MCU025 is a sophisticated multi stage pulse charger, designed to charge most 12 Volt SLA, Lead Acid, Gel and Calcium batteries. FULLY CHARGING POWER CHARGED MULTI-STAGE CHARGER MULTI-STAGE CHARGER • Ideal for automotive & marine batteries.
-
Page 4: Operating The Charger
Operating the Charger Connecting the charger to a battery in a vehicle: Ensure the ignition and all of the accessories in the vehicle are switched off. This will maxi- mize the charge your battery receives. It will also minimize any chance of damage occurring to the vehicles on-board electronics. -
Page 5: Charging Stages
Charging Stages Boost/Absorption Stage: After connecting and turning the mains power on, the unit will commence charging. This is indicated by the illuminated “Charging” LED. The battery charger delivers a Boost current up to 2.5 amps. When the battery is 80% charged, the charger will automatically switch to the “float stage”. -
Page 6: Fault Finding
Fault Finding » Charger won’t indicate » • Charger not connected to battery. charging. • Check terminal connection. • Battery is not 12V. » No spark when charging » Charger features an inbuilt safety device to prevent sparking if clamps or terminals clamps or terminals accidentally touch together. -
Page 7: Charging Times
Charge Charge Number Rate Time* Charges Maintains Charges Maintains (amps) (Min-Max) (max) (Min-Max) (max) MCU025 7-40 AH 60 AH 80- 250 CCA 650CCA 4-24 hrs MCU080 60-100 AH 200 AH 300-700 CCA 1000 CCA 4-24 hrs MCU120 12.0 80-160 AH... -
Page 8: Warranty
Warranty Thank you for purchasing one of our quality products. Any claim against defects under this warranty must be made by the original purchaser within 12 months from the date of purchase. To make a claim under the warranty, take the product along with your proof of purchase to the store where the purchase took place.
